2015 VOLKSWAGEN JETTA HYBRID sensor

Carefully fold the wiper arms back onto the windshield before driving! Switch the ignition on and press
the windshield wiper lever down briefly ⇒ fig. 78 (E). The wiper arms move back to their original posi-tion.
Lifting the wiper blades and tilting them away from the windshield
x Put the wiper arms in service position ⇒ .
x Do not handle the wiper blades, handle the wiper arms only at the attachment above the wiper blades.
NOTICE
x To help prevent damage to the engine hood and the windshield wiper arms, lift the wiper arms away from the windshield only when they are in the service position.
x Always carefully fold the windshield wiper arms down against the windshield before driving the vehicle.
The windshield wiper arms can be moved to the service position only when the vehicle is not moving.
Rain sensor

Fig. 80 Windshield wiper lever: Adjusting the rain sensor 1 (if equipped).

Fig. 81 Inside the front windshield above the inside mirror: Sensitive rain sensor surface.

When switched on, the rain sensor automatically shortens or lengthens the time between wiping
intervals depending on how hard it is raining ⇒ . The rain sensor's sensitivity can be adjusted
manually. Manual wiping (vehicles without rain sensors), see ⇒  Windshield wiper lever.
Push the lever into the desired position ⇒ fig. 80:
(A) Rain sensor off (windshield wiper lever home position).
(B) Rain sensor active – automatic wiping as needed.
(1) Adjust the sensitivity of the rain sensor:
– Move switch to the right – high sensitivity.
– Move switch to the left – low sensitivity.
After switching the ignition off and back on again, the rain sensor stays on and works again when the wiper lever is in position (B).
Possible reasons for changes in the way the rain sensor works
The rain sensor may misread what is happening in the detection zone of its sensitive rain-sensor
surface ⇒ fig. 81 (arrow) and not work for a number of reasons, which may include:
x Worn out wiper blades: Worn out wiper blades may leave a film of water or wiping streaks; this can cause the wipers to run longer, to wipe more often, or to wipe continuously at high speed.
x Insects: Insects hitting the windshield may trigger the wipers.
x Salt streaks: Salt streaks on the windshield from winter driving can cause wiping more often or continuously on glass that is almost dry.
x Dirt: Caked-on dust, wax, any other buildup on the windshield (lotus effect), or car-wash detergent residue can lower the rain sensor's sensitivity and cause it to react too slowly or not at all.
x Crack or chip in the windshield: If a stone hits and chips the windshield while the rain sensor is on, this will trigger a wiper cycle. After that, the rain sensor will recognize the change and recalibrate itself to respond to the sensitive surface's reduced detection zone. Depending on the size of the chip, the sensor's reaction pattern may or may not change.
WARNING
The rain sensor cannot always recognize rain and activate the wipers.
x Switch the wipers on manually when water on the windshield reduces visibility.
Clean the rain sensor's sensitive surface ⇒ fig. 81 (arrows) regularly and check the wiper blades for wear or damage.
To remove wax and coats of polish safely, we recommend using an alcohol-based windshield cleaner.

The self-dimming feature can be switched on and off with the switch on the inside mirror (2) A or (2) B. When self-dimming is activated, the indicator light (1) is on.
There are two sensors in the interior mirror housing:
x One sensor on the side facing the interior to measure light from the rear of the vehicle ⇒ fig. 83 A
(3) or ⇒ fig. 83 B (3).
x One sensor on the side facing the windshield to measure light from the front of the vehicle ⇒ fig. 83 C (4).
If the ignition is switched on, the mirror automatically darkens depending on the amount of light shining into the vehicle from the rear.
The self-dimming feature is deactivated when you shift the transmission into reverse or switch on the interior lights or the reading light.
Do not attach external navigation devices to the windshield or in the vicinity of the self-dimming inside
mirror ⇒ .
WARNING
The illuminated display on an external navigation device can cause the self-dimming inside mirror to malfunction, which can result in crashes and serious injuries.
x Malfunctions in the self-dimming function can result in the inside mirror being unable to evaluate the exact distance of vehicles in the rear or other objects.
If the light striking the sensor is filtered or blocked (such as by a sunshade), the self-dimming inside mirror will not work properly or may not work at all.
Outside mirrors

Fig. 85 In the driver door: Adjusting knob for the outside mirrors.

NOTICE
x Things like trailer draw bars, thin rods, fences, trees, narrow painted vertical poles, posts, or a luggage compartment lid that is opening may not be detected by the Park Distance Control sensors and could damage the vehicle.
x If you continue driving closer to an object that the Park Distance Control has already de-tected and reported, the object may disappear from the sensor range and may no longer be detected. This is especially true for low or high objects. The system will no longer sound warn-ings about these objects. Ignoring signals from the Park Distance Control system could result in serious damage to the vehicle.
x The sensors in the bumpers can be damaged or become misaligned in low speed impacts and parking maneuvers. Damaged or misaligned sensors cannot accurately detect or report objects that might be within range of the PDC system.
x To help make sure that the system works properly, always keep the sensors in the bumpers clean and free of snow and ice; do not cover the sensors with stickers or other objects.
x When cleaning the sensors with power washers or steam cleaners, only spray the sensors directly for a very short time, and always keep the washer nozzle at least 4 inches (10 cm) from the sensors.
x Noise from rough roads, cobblestones, other vehicles and the surrounding area, for exam-ple, can prevent the Park Distance Control system from accurately detecting and reporting people and objects that may be within range of the sensors.
x Aftermarket components such as bicycle racks can impair the function of the Park Distance Control system.
Volkswagen recommends practicing with the Park Distance Control system in a location or park-ing space with no traffic in order to become familiar with the system and how it works.
Operation

Fig. 134 In the front and rear bumpers: Park Distance Control system sensors.

Special considerations when using Park Distance Control
x In some cases, the Park Distance Control interprets water and ice on the sensors as an obstacle.
x If the distance remains the same, the warning tone volume decreases after a few seconds. If a continuous tone sounds, its volume remains the same.
x If the vehicle moves away from the obstacle, the beeping sound stops automatically. The beep turns on again automatically if the vehicle approaches the obstacle again.
x For vehicles with automatic transmissions, there is no beeping when the transmission is in Park (P).
x The volume of the audible signals can be adjusted by an authorized Volkswagen dealer or an authorized Volkswagen Service Facility.
Muting the Park Distance Control volume
You can mute the PDC beeping signals by tapping the  function key on the Radio or Navigation system screen (if applicable). Tap the function key again to reactivate the acoustic signals.
Switching Park Distance Control back on after it was switched off reactivates the volume. System malfunction warning signals cannot be switched off.
If you manually deactivate the display, PDC remains on and the sound is reactivated.
WARNING
Never rely completely on the PDC for information about people and objects that might be in the way of the vehicle and could be struck by the vehicle causing serious personal injury.
x The PDC sensors have blind spots where they cannot detect people or objects.
x Always watch for people, especially small children and animals, because the sensors may not always be able to detect them.
If you hear a long beep lasting about 3 seconds when you first turn PDC on or the indicator light in the button starts blinking, this means there is a malfunction in the Park Distance Control system. Switch off the Park Distance Control system with the button and have it immediately checked by an authorized Volkswagen dealer or an authorized Volkswagen Service Facility.
PDC signal chimes and displays

Fig. 136 PDC display of the area surrounding the vehicle.

Vehicles with PDC at the front and rear
Area of the vehicle
fig. 136
Distance of the
vehicle from an
obstacle
Signal
tone
Segment color
if an obstacle
has been de-
tected
Rear side about 12 – 23 in.
(31 – 60 cm)
(B) Front cen-
ter
about 12 – 47 in.
(31 – 120 cm)
Front side about 12 – 23 in.
(31 – 60 cm)
(A) and (B) Obstacle
close to
the vehicle
about 0 – 12 in.
(0 – 30 cm)
Continuous
tone
Red

WARNING
x Never pay so much attention to the graphics shown on the screen that you fail to notice what is going on around you.
It can take a few seconds before the area scanned by the sensors activates the acoustic or visual signals.

NOTICE
x The radar sensors in the rear bumper can be damaged or become misaligned in low-speed impacts and parking maneuvers. The system can switch itself off or may be impaired as a result.
x Always keep the rear bumper clean and free of snow and ice so that the radar sensors can function properly. Do not cover the radar sensor area.
x The rear bumper may only be painted with vehicle paint that is approved by Volkswagen. Other paints may impair the function of the Blind Spot Monitor or cause it to malfunction.
x Sunlight may reduce the visibility of the indicator light in the outside mirror.
If the system does not function as described in this chapter or if your vehicle was involved in a collision, do not use the Blind Spot Monitor with Rear Traffic Alert. See an authorized Volkswagen dealer or an authorized Volkswagen Service Facility to have the system checked.
Indicator lights

When the ignition is switched on, several warning and indicator lights come on briefly for a function check. They go out after a few seconds.
If the indicator light in the outside mirror does not light up, the Blind Spot Monitor does not currently
detect a vehicle in the monitored area around your vehicle ⇒ 
The brightness of the indicator lights in the outside mirrors are dimmed when the headlights are switched on (night mode).
WARNING
Failure to heed warning and indicator lights and instrument cluster text messages can result in a collision and serious personal injury.
x Never ignore warning and indicator lights or text WARNINGS.
x Always heed warning and indicator lights and take action where necessary.
NOTICE
Failure to heed warning and indicator lights or text WARNINGS can result in vehicle damage.
Blind Spot Monitor

Fig. 137 In the outside mirrors: Indicator lights for the Blind Spot Monitor.

Fig. 138 Rear of the vehicle: Radar sensor areas.
