Please perform these steps only in the order listed.
Step Vehicles without Keyless Ac-
cess Vehicles with Keyless Access
6. Manual transmission: Shift into 1st gear (vehicle on flat surface or
pointing uphill) or Reverse (R) (vehicle pointing downhill).
7.
Removing the vehicle key from
the ignition switches off electrical
equipment and activates the
steering column lock.
Opening the doors switches off
electrical equipment and acti-
vates the steering column lock.

WARNING
Never stop the engine before the vehicle has come to a complete stop. You can lose control of the vehicle, crash, and be seriously injured.
x The airbags and safety belt pretensioners will not work when the ignition is switched off.
x The brake booster does not work when the engine is not running. More brake pedal pres-sure will be needed to stop the vehicle.
x The power steering system does not work when the engine is not running, and you will need more force to steer the vehicle.
x Never remove the key from the ignition switch or turn off the ignition with the starter but-ton while the vehicle is moving or rolling to a stop. The electronic steering column could suddenly lock, and you would not be able to steer the vehicle.
NOTICE
If the vehicle has been driven hard for a long time, the engine could overheat when it is stopped. To reduce the risk of engine damage, let the engine idle in Neutral for about 2 minutes before you switch off the ignition.
If the ignition is switched on or the engine is running and the driver door is opened, a chime sounds. The chime is also a reminder to switch off the engine and turn off the ignition before leaving and locking the vehicle from the outside.
On vehicles with automatic transmissions, the vehicle key can only be removed from the ignition when the transmission is in Park (P).
After the engine has been switched off, the radiator fan in the engine compartment may keep running for several minutes, or may start running after the vehicle has been parked for a while, even if the ignition is switched off and the vehicle key has been removed. The radiator fan shuts off automati-cally when the engine has cooled down enough.

WARNING
Improper use of the parking brake can cause accidents and severe injuries.
x Never use the parking brake to slow down the vehicle when it is moving, except in an emergency. Braking distance is much longer, since only the rear wheels are braked. Always use the foot brake.
x Never drive with the parking brake partially engaged. This can cause the brake to overheat and negatively affect the brake system. It will also cause the rear brake pads to wear prema-turely.
x Never activate the throttle manually from the engine compartment when the engine is running and the automatic transmission is in gear. The vehicle will start to move even if the parking brake is engaged.
NOTICE
Even though the transmission is in Park (P), the vehicle may move a couple of inches (a few centimeters) forwards or backwards if you take your foot off the brake pedal after stopping the vehicle without first firmly setting the parking brake.
A warning signal sounds if you drive faster than about 4 mph (6 km/h) with the parking brake engaged.
Parking

Key for displays ⇒ fig. 146
Symbol Meaning
O Close the current display.
Depending on vehicle equipment: Switch the PDC
sound on or off.
Setting display: brightness, contrast, color.
Depending on vehicle equipment: Display PDC.

Switching the camera on and off.
The Rear View Camera system switches on and off automatically.

Function Action with the ignition on
Vehicles without Park
Distance Control
Vehicles with Park Dis-
tance Control
Switch on the
display automati-
cally:
Shift into Reverse (R).
Switch off the
display automati-
cally:
Switch off the ignition.
OR: Drive forward faster than 6 mph (10 km/h) or for
longer than 10 seconds.
OR: Shift out of Reverse
(R) and wait about
10 seconds.
OR: Shift out of Reverse
(R) (display switches off
immediately).
Switch off the
display manually:
Press one of the Infotainment system buttons or tap
the O function key on the screen.

OR: Tap the function key
.

x If you continue driving closer to an object that the Park Distance Control has already de-tected and reported, the object may disappear from the sensor range and may no longer be detected. This is especially true for low or high objects. The system will no longer sound warn-ings about these objects. Ignoring signals from the Park Distance Control system could result in serious damage to the vehicle.
x The sensors in the bumpers can be damaged or become misaligned in low speed impacts and parking maneuvers. Damaged or misaligned sensors cannot accurately detect or report objects that might be within range of the PDC system.
x To help make sure that the system works properly, always keep the sensors in the bumpers clean and free of snow and ice; do not cover the sensors with stickers or other objects.
x When cleaning the sensors with power washers or steam cleaners, only spray the sensors directly for a very short time, and always keep the washer nozzle at least 4 inches (10 cm) from the sensors.
x Noise from rough roads, cobblestones, other vehicles and the surrounding area, for exam-ple, can prevent the Park Distance Control system from accurately detecting and reporting people and objects that may be within range of the sensors.
x Aftermarket components such as bicycle racks can impair the function of the Park Distance Control system.
Volkswagen recommends practicing with the Park Distance Control system in a location or park-ing space with no traffic in order to become familiar with the system and how it works.
Operation

Fig. 149 In the front and rear bumpers: Park Distance Control system sensors.

Fig. 150 In the center console: Button to switch the Park Distance Control system on or off.

The Park Distance Control (PDC) uses ultrasonic sensors to determine the distance from the front or rear bumpers to an obstacle. There are 4 sensors for the PDC located in rear bumper (B) and addi-
tional sensors in the front bumper (A) ⇒ fig. 149 (arrows).
The intermittent and permanent signal chimes given by the front PDC sensors are of a higher pitch than those given by the rear PDC sensors. This is a standard feature.
The warning signals can be adjusted in the Infotainment system menu ⇒  Infotainment system.
Switching the Park Distance Control (PDC) system on and off

In order to Operation (when the ignition is switched on)
Manually activate
PDC:
Press the  button once.
Manually deactivate
PDC: Push the  button again.
Manually deactivate
the display (sound
stays active):
Press a function selection button on the factory-
installed Infotainment system ⇒ page 27.
OR: Tap the O function key on the screen.
Automatically acti-
vate PDC:
Shift into Reverse (R).
OR: Depending on vehicle equipment, when the
vehicle rolls backwards.
Automatically deac-
tivate PDC:
Shift into Park (P).
OR: Drive forward faster than about 5–10 mph (10–
15 km/h).
Mute the PDC vol-
ume:
Tap the  function key.
Switch from mini
PDC display to full-
screen mode.
Press the  button once.
OR: Shift into Reverse (R).
OR: Depending on vehicle equipment, when the
vehicle rolls backwards.

In order to Operation (when the ignition is switched on)
OR: Tap the mini PDC function key.
Switch to the Rear
View Camera sys-
tem display (if
equipped):
Shift into Reverse (R).
OR: Tap the Z function key.

The indicator light in the  button ⇒ fig. 150 lights up and stays on as long as the feature is active.
Automatic activation
When the PDC is activated automatically, a mini PDC display appears on the left-hand side of the
screen ⇒ fig. 152.
Automatic activation of the PDC when driving slowly towards an obstacle located in front of the vehicle only works when the speed falls below about 6–9 mph (10–15 km/h) for the first time. If the PDC was switched off using the  button, performing one of the following actions with the ignition switched on can automatically reactivate the PDC:
x If the vehicle accelerates to a speed greater than 6–9 mph (10–15 km/h) and then drops below that speed again.
x OR: If the selector lever is moved to Park (P) and then out of that position again.
x OR: If automatic activation is turned off and on again in the Infotainment system.
Automatic activation of the mini PDC display can be turned on or off in the Infotainment system ⇒  Infotainment system.
When the box in the automatic activation function key is checked =, signal chimes sound from a distance of about 20 inches (50 cm) from the obstacle.
WARNING
Never rely completely on the PDC for information about people and objects that might be in the way of the vehicle and could be struck by the vehicle causing serious personal injury.
x The PDC sensors have blind spots where they cannot detect people or objects.
x Always watch for people, especially small children and animals, because the sensors may not always be able to detect them.
If you hear a long beep of about 3 seconds when you first turn PDC on or the indicator light in the button starts blinking, this means there is a malfunction in the Park Distance Control system. Switch off the Park Distance Control system with the button and have it immediately checked by an author-ized Volkswagen dealer or an authorized Volkswagen Service Facility.

Key to elements in the color display
fig. 151 and
fig. 152
Meaning
c The grey segment represents an obstacle outside of
the vehicle's path.

When the factory-installed Infotainment system is switched on, the areas to the front, rear, and side of
the vehicle that are scanned by ultrasonic sensors are shown on the screen ⇒ fig. 151. The positions
of potential obstacles are displayed relative to the vehicle ⇒ .
Signal chimes
When the vehicle approaches an obstacle located in the range of the ultrasonic sensors, there are audible signal chimes. An intermittent signal chime means that a sufficiently short distance between the vehicle and an obstacle is detected. The shorter the distance, the shorter the intervals between the chimes. The signal chime will sound continuously if the obstacle is very close.
When there is an imminent risk of collision at the front area of the vehicle, the signal chimes beep at the front of the vehicle. When there is a risk of imminent collision at the rear area of the vehicle, the signal chimes beep at the rear of the vehicle.
If you continue to drive the vehicle closer to the obstacle despite a continuous signal chime, the sys-tem will no longer be able to measure the distance.
The intermittent signal chime volume decreases after a few seconds if the distance remains the same. The volume remains constant if the signal chime is continuous. As soon as the vehicle moves away from an obstacle again, the intermittent signal chime switches off automatically. If the vehicle moves towards an obstruction again, the intermittent signal chimes beep automatically.
Display
The graphic on the screen displays the scanned areas in several segments. The closer the vehicle drives towards an obstacle, the closer the segment will move to the vehicle in the display. The collision area has been reached at the latest when the second to last segment is displayed. Do not keep driving!

Vehicles with PDC at the front and rear
Area of the vehicle Distance of
the vehicle
from an ob-
stacle
Signal
tone
Segment color
if an obstacle
has been de-
tected
color display
only)
(A) Rear
center
Obstacle
not in
the ve-
about 12 –
63 in.
(31 – 160 cm)
– Grey

Function button: action
Rear pitch : Set different pitches for the rear signal chimes by tapping the -
or + function keys or by adjusting the control.
Audio lowering : Set the level to which the Infotainment system volume
should be lowered when the PDC is active.
Off: The Infotainment system volume is not lowered.
Low: The Infotainment system volume is lowered slightly.
Medium: The Infotainment system volume is lowered to medium.
Strong: The Infotainment system volume is lowered to a minimum.

Muting the Park Distance Control volume
You can mute the PDC beeping signals by tapping the  function key on the Infotainment system screen (if applicable). Tap the function key again to turn the beeping signals back on.
Switching Park Distance Control back on after it was switched off reactivates the volume. System malfunction warning signals cannot be switched off.
If you manually deactivate the display, PDC remains on and the sound is reactivated.
The mute setting is active if the PDC was switched on using the  button when the selector lever is in Park (P).
