2015 VOLKSWAGEN E GOLF light

WARNING
Clothes or other items on the luggage compartment cover behind the rear seat backrest may limit visibility and cause accidents and severe personal injuries.
x Always hang clothes so that they do not limit visibility.
x Always use the built-in coat hooks only for lightweight clothing. Never leave any heavy or sharp-edged items in the pockets that may interfere with airbag deployment and can cause personal injury in a collision.

WARNING
The electric drive can get very hot. It can cause fires and serious personal injury.
x Never park the vehicle if oil, fuel, or other flammable substances are under or around the vehicle.
x Never leave the vehicle unattended with the electric motor drive ready, especially when it is in gear. The vehicle could move suddenly or some other unexpected event could occur, resulting in property damage, fire, or personal injury.
Indicator lights

Lights
up
Warning text in the instru-
ment cluster display / Pos-
sible meaning
Proper response

Flashes Possible cause Proper response
K
The release button in the
selector lever did not engage.
Vehicle movement is pre-
vented.
Engage the selector lever re-
lease button

When the ignition is switched on, several warning and indicator lights come on briefly for a function check. They go out after a few seconds.
WARNING
Failure to heed warning lights and instrument cluster text messages can cause the vehicle to break down in traffic and result in a collision and serious personal injury.
x Never ignore warning lights or text WARNINGS.
x Always stop the vehicle as soon as it is safe to do so.
x Whenever stalled or stopped for repair, move the vehicle a safe distance off the road, turn on the emergency flashers, stop the electric motor, and use other warning devices to warn approaching traffic.
NOTICE
Failure to heed warning lights or text WARNINGS can result in vehicle damage.
General notes on the electric drive

Fig. 119 WARNING labels: A: On every high-voltage component, B: General warning sign for high-voltage

Please perform these steps only in the order listed.
Step Vehicles without Keyless Ac-
cess
Vehicles with Keyless Access
7. Release the parking brake when you are ready to start driving

Noises before driving
A clicking noise may be heard when activating the electric motor.
Recognizing that the vehicle is ready to drive
The electric motor does not make any perceptible noise either when starting or when switched on. It is therefore not possible to tell that the vehicle is ready to drive based on vehicle noise. Instead, the following features indicate that the vehicle is ready to drive:
x The needle in the power display ⇒ fig. 9 (1) is positioned at .
x The illumination of the needles in the instrument cluster is switched on regardless of whether the vehicle's exterior lighting is switched on.
x The text message READY appears in the instrument cluster display ⇒ fig. 9 (3).
x An acoustic signal will sound.
Automatic deactivation of the electric motor
The electric motor is automatically deactivated if the vehicle is left with the electric motor still switched on after driving. In vehicles with Keyless Access, the ignition switches off automatically with a delay of about 30 seconds, to protect the vehicle against unauthorized usage.
Reactivating the electric motor
When the electric motor has been automatically switched off once the driver has left the vehicle, it can be switched back on again within 30 seconds.
The driver door must be closed, the brake pedal depressed and one of the following conditions ful-filled:
x Move the selector lever to position D/B/N or P and lock the safety belt.
x OR: move the selector lever to position D/B/N or P and manually release the electronic parking brake.
When the driver door is closed and no pedals are depressed, the electric motor is reactivated by applying the safety belt if one of the following additional conditions is also fulfilled:
x The selector lever is in position P or N and the electronic parking brake is switched on.
x OR: the selector lever is in position D or B, the vehicle is not crawling and the electronic parking brake is switched on.
WARNING
Never leave the vehicle unattended with the electric motor activated, especially when it is in gear. The vehicle could move suddenly or some other unexpected event could occur, result-ing in property damage, fire, or personal injury.

x (B) Maximum power no longer available ⇒ .
x (C) Currently available power is very limited. The indicator light

Lights up Warning text in the
instrument cluster
display
Proper response
- Please charge
battery! Limited
conv. funct.
The remaining range is
just a few miles. The
power is reduced and,
if necessary, electrical
consumers are shut
down. The Eco driving
profile is activated.
Charge the high-
voltage battery as soon
as possible
- Battery almost
drained! Limited
function.
The vehicle can only
be driven with limited
power in reserve mode.
The Eco+ driving pro-
file is activated. Charge
the high-voltage battery
as soon as possible

The procedure can be repeated a second time, but the possible driving distance and the power will be reduced considerably. Please contact an authorized Volkswagen dealer , Volkswagen service facility or roadside assistance if the vehicle cannot be moved any further.
Charge the high-voltage battery as soon as possible
WARNING
Driving when the high-voltage battery charge is too low can lead to stalling in traffic, colli-sions and serious personal injury.
x Always make sure that the high-voltage battery has a sufficient charge level to get where you are going and that the high-voltage battery can be charged when you get there.
WARNING
If the maximum power reserve is not available or the charge level of the high-voltage battery has reached the “reserve range”, the driving characteristics can change, for example, the acceleration performance of the vehicle.
x Always adapt your speed and driving style to suit visibility, weather, road and traffic con-ditions as well as the charge level of the high-voltage battery.
WARNING
Failure to heed warning lights and instrument cluster text messages can cause the vehicle to break down in traffic and result in a collision and serious personal injury.
x Never ignore warning lights or text WARNINGS.
x Always stop the vehicle as soon as it is safe to do so.
x A broken down vehicle presents a high accident risk for itself and others. Switch on emergency flashers and set up a warning triangle or other device to warn oncoming traffic.
NOTICE
If the vehicle is parked for a long period with a drained high-voltage battery, irreversible dam-age can be caused to the high-voltage battery.
x Always charge the high-voltage battery as soon as possible .
NOTICE
Failure to heed warning lights or text WARNINGS can result in vehicle damage.
Stopping the electric motor
