2015 VOLKSWAGEN E GOLF Condition

Heating and air conditioning

WARNING
Poor visibility increases the risk of collisions and other accidents that cause serious person-al injuries.
x Always make sure all windows are clear of ice, snow and condensation for good visibility to the front, sides, and rear.
x Always make sure you know how to properly use the climate control system as well as the rear window defroster that you will need for good visibility.
x Never use air recirculation for long periods of time. When the air conditioner is off and recirculation mode is on, condensation can quickly form on the windows and greatly reduce visibility.
x Always switch off recirculation mode when it is not needed.
WARNING
Stale air causes driver fatigue and reduces driver alertness, which can cause accidents, colli-sions and serious personal injury.
x Never switch off the fan for a long period of time and never use air recirculation for a long period of time because no fresh air will enter the passenger compartment.
NOTICE
x If you think the air conditioner is not working properly or may be damaged, switch it off to help prevent more damage. Have the air conditioner checked by an authorized Volkswagen dealer or an authorized Volkswagen Service Facility.
x Air conditioner repair requires specialized knowledge and special tools. Volkswagen rec-ommends that you see an authorized Volkswagen dealer or an authorized Volkswagen Service Facility.
x Do not smoke when air recirculation is switched on. Smoke drawn into the ventilation sys-tem can leave residue on the evaporator and on the dust and pollen active carbon filter, result-ing in permanent odors whenever the air conditioner is switched on.
If the air conditioner is switched off, the fresh outside air will not be dehumidified. To help keep the windows from fogging over, Volkswagen recommends leaving the air conditioner (compressor) switched on. Press the !

Manual controls

Fig. 149 In the center console: Manual air conditioning controls.

Button/Knob More information: Manual air conditioning ⇒ fig. 149
L Air distribution to the footwells.
u Air distribution to the windshield and footwells.
=
Rear window defroster: Works only when the electric motor
is activated and switches off automatically after 10 minutes
or less.
3 Air recirculation mode
A, [ Buttons for seat heating
!

Opening the Air conditioning menu
x Press the -%.5 ⇒ fig. 150 button.
The current air conditioning settings are displayed in the upper section of the screen, for example, the temperatures that are currently set for the driver and passenger sides. Set temperatures up to +72 °F (+22 °C) are shown with blue arrows, while temperatures above +72 °F (+22 °C) are shown with red arrows.
Tap the corresponding function key to switch a function on or off, or to select a submenu.

Function
key
Effect
/&& Switch off the Climatronic.
/. Switch on the Climatronic.
Setup

The air recirculation mode helps prevent outside air from entering the vehicle interior.
In very hot outside temperatures, temporarily switch to manual air recirculation in order to cool the vehicle interior faster.
For safety reasons, air recirculation is switched off in the following situations ⇒ .
x Manually: The  button is pushed (Climatronic) or the air distribution knob is turned to < (manual air conditioning).
x Automatically: A sensor detects conditions that could cause the windows to fog up.
Switching manual air recirculation on and off
Switching on: Press the 3 button. The indicator light under the button lights up.
Switching off: Press the 3 button. The indicator light under the button goes out.
Switching the automatic air recirculation mode on and off: Climatronic
x Press the -%.5 button.
x Touch the

Under normal driving conditions, the needle should be in the middle of the gauge. The temperature may go higher when the electric motor is working hard, especially in hot weather.
When the ignition is switched on, several warning and indicator lights come on briefly for a function check. They go out after a few seconds.
The following table explains what to do if the electric motor coolant temperature warning light ~ does not go out a few seconds after the electric motor is started or starts flashing while driving.

Flashes8 Possible cause Proper response
~
Electric motor coolant
temperature too high.

WARNING
Hot steam and hot electric motor coolant can cause serious burns.
x Never open the hood if you see steam or coolant escaping from the electric motor com-partment. Always wait until you no longer see or hear steam or coolant escaping from the electric motor.
x Always let the electric motor cool down completely before carefully opening the hood. Hot components will burn skin on contact.
x When the electric motor has cooled down and you are ready to open the hood:
– Firmly apply the parking brake and shift the transmission into Park (P) (automatic) or Neutral (manual only).
– Take the vehicle key out of the ignition.
– On vehicles with Keyless Access, make sure that the remote control vehicle key is out of range of the vehicle and that the vehicle cannot be started by depressing the starter
button ⇒  Starter button.
– Always keep children and others away from the electric motor compartment and never leave them unsupervised.
x The electric motor coolant system is under pressure when the electric motor is hot. Never unscrew the coolant expansion tank cap when the electric motor is hot. Hot coolant can spray out and cause severe burns and other serious injuries.
– Turn the cap slowly and very carefully in a counterclockwise direction while applying light downward pressure on the top of the cap.
– Always protect your face, hands, and arms from hot escaping coolant or steam by covering the cap with a large, thick rag.
x Never spill fluids on the electric motor when refilling. Spilling fluids onto hot parts of the electric motor can cause a fire. Under some conditions, the ethylene glycol in electric motor coolant can catch fire.
NOTICE
x Use distilled water only when adding coolant! All other types of water contain chemical compounds that can cause extensive corrosion damage to the electric motor. This can even lead to electric motor failure. If you have added non-distilled water, take the vehicle immediate-ly to an authorized Volkswagen dealer or an authorized Volkswagen Service Facility to have the coolant system drained, flushed, and refilled completely with the proper coolant.
x Refill electric motor coolant only up to the top edge of the marked fill range ⇒ fig. 154. Ex-cess electric motor coolant may be forced out of the electric motor cooling system when it gets hot and cause damage.
x In the case of significant electric motor coolant loss, refill electric motor coolant only when the electric motor is completely cooled down. Significant electric motor coolant loss is a sign of leaks in the cooling system. Have the electric motor cooling system checked immediately by an authorized Volkswagen dealer or an authorized Volkswagen Service Facility. Otherwise the electric motor may be damaged!
x Do not refill electric motor coolant if there is no coolant in the expansion tank. Air could enter the cooling system. Do not drive the vehicle! Get expert assistance. Failure to do so can result in electric motor damage.
x When changing or topping off operating fluids, make sure that you pour the fluids into the correct reservoirs. Serious malfunctions and electric motor damage can result if you pour operating fluids into the wrong reservoir.
