2015 VOLKSWAGEN CC light

WARNING
Using the cruise control when it is not possible to drive safely
at a constant speed can be dangerous and can lead to an acci-
dent and serious personal injuries.
Never use cruise control when driving in heavy or varying
traffic or when you cannot keep a safe distance between you
and the vehicles ahead of you.
Never use cruise control on steep, winding, or slippery roads
(such gravel roads, wet roads, or snowy or icy roads) or on
roads with standing water.
Never use cruise control when driving off-road or on unpaved
roads.
Always adjust your speed and the distance you keep between
you and the vehicles ahead of you to the road, traffic, weather,
and visibility conditions.
To help prevent unintended operation of cruise control,
switch the system off when it is not being used.
It is dangerous to use the Resume feature when the previous-
ly set speed is too high for the existing road, traffic, or weather
conditions.
When going downhill, the cruise control may not be able to
maintain a constant speed. The vehicle will speed up because
of its own weight. Downshift and/or use the foot brake to slow
the vehicle.
Indicator lights

Fig. 149 In the instrument cluster display: Cruise control status indi-
cations.

Display
Different cruise control versions are available. The stored speed is
shown in the instrument cluster display on some equipment versions.
Status fig. 149
(A) Cruise control temporarily deactivated. Stored speed in small
numbers.
(B) System malfunction. See an authorized Volkswagen dealer or an
authorized Volkswagen Service Facility.
(C) Cruise control activated. No speed stored in memory.
(D) Cruise control is active. Stored speed in large numbers.
Indicator lights

Lights up Possible cause
%
Cruise control is regulating the vehicle speed.
#25)3%

When the ignition is switched on, several warning and indicator lights
come on briefly for a function check. They go out after a few seconds.
WARNING
Failure to heed warning lights and instrument cluster text mes-
sages can cause the vehicle to break down in traffic and result
in a collision and serious personal injury.
Never ignore warning lights or text WARNINGS.
Always stop the vehicle as soon as it is safe to do so.
NOTICE
Failure to heed warning lights or text WARNINGS can result in
vehicle damage.

WARNING
Rear Assist is not able to give you a clear and undistorted view
of all areas behind the vehicle.
The camera has blind spots in which it cannot detect people
and objects.
Always be careful and look around you when parking. The
camera cannot show people, animals, and objects in certain
situations. Watch out for small children and animals in particu-
lar.
Due to the screen resolution or in low-light conditions, the
camera may not pick up thin posts, chain-link fences and simi-
lar fences, and other objects, or it may not show them clearly.
The camera lens enlarges and distorts the field of vision and
causes objects on the screen to appear altered and imprecise.
Always keep the camera lens clean and free of snow and ice;
do not cover the lens.
WARNING
Rear Assist technology cannot overcome the laws of physics
and the limits of the system. Careless or unintentional use of
Rear Assist may result in accidents and severe injuries.
Always adjust your speed and driving style to road, traffic,
weather, and visibility conditions.
Always keep an eye on the parking direction and the vehicle
surroundings. The front of the vehicle swings out more than the
rear of the vehicle.
Never pay so much attention to the graphics shown on the
screen that you fail to notice what is going on around you.
Always watch for people, especially small children, animals,
and objects, because the camera may not always be able to de-
tect them.
The system may not be able to clearly show everything be-
hind the vehicle.
Use Rear Assist only when the luggage compartment lid is
completely closed.

In order to Operation
view camera dis-
play (if equipped): OR: Tap the function key Z or 26# on the dis-
play.

The indicator light in the button  ⇒ fig. 157 comes on and stays on
as long as the feature is active.
A chime sounds to tell you that the system is on. If the chime does
not sound, PDC is not working. Have the system inspected by an
authorized Volkswagen dealer or an authorized Volkswagen Service
Facility.
Special considerations when using Park Distance Control
In some cases, the Park Distance Control interprets water and ice
on the sensors as an obstacle.
If the distance remains the same, the warning tone volume de-
creases after a few seconds. If a continuous tone sounds, its volume
remains the same.
If the vehicle moves away from the obstacle, the beeping sound
stops automatically. The beep turns on again automatically if the ve-
hicle approaches the obstacle again.
For vehicles with automatic transmissions, there is no beeping
when the transmission is in Park (P) and the electronic parking brake
is engaged.
The volume of the audible signals can be adjusted by an author-
ized Volkswagen dealer or an authorized Volkswagen Service Facili-
ty.
Muting the Park Distance Control volume
You can mute the PDC beeping signals by tapping the  function
key on the Radio or Navigation system screen (if applicable). Tap the
function key again to reactivate the acoustic signals.
Switching Park Distance Control back on after it was switched off re-
activates the volume. System malfunction warning signals cannot be
switched off.
If you manually deactivate the display, PDC remains on and the
sound is reactivated.

WARNING
Never rely completely on the PDC for information about people
and objects that might be in the way of the vehicle and could be
struck by the vehicle causing serious personal injury.
The PDC sensors have blind spots where they cannot detect
people or objects.
Always watch for people, especially small children and ani-
mals, because the sensors may not always be able to detect
them.
If you hear a long beep lasting about 3 seconds when you first
turn PDC on or the indicator light in the button starts blinking, this
means there is a malfunction in the Park Distance Control system.
Switch off the Park Distance Control system with the button and have
it immediately checked by an authorized Volkswagen dealer or an
authorized Volkswagen Service Facility.

Air recirculation is not automatically activated under the following
outside temperatures and conditions:
The air conditioning is on (indicated by the light in the !

substances that can severely damage the fuel system and the
engine if the engine is started.
Fuels can pollute the environment. Spilled fuel must be collected
and disposed of properly, following all applicable environmental regu-
lations.
There is no emergency release for the fuel filler flap. Contact an
authorized Volkswagen dealer or an authorized Volkswagen Service
Facility for assistance.
Indicator lights and fuel gauge

Fig. 160 In the instrument cluster: Fuel gauge.

When the ignition is switched on, several warning and indicator lights
come on briefly for a function check. They go out after a few seconds.
Fuel filler cap not properly closed
