2015 VAUXHALL CORSA Index

Introduction.................................... 2
In brief ............................................ 6
Keys, doors and windows ............20
Seats, restraints ........................... 34
Storage ........................................ 56
Instruments and controls .............74
Lighting ...................................... 108
Climate control ........................... 118
Driving and operating .................128
Vehicle care ............................... 176
Service and maintenance ..........222
Technical data ........................... 225
Customer information ................239
Index .......................................... 242Contents

Introduction3Vehicle specific data
Please enter your vehicle's data on
the previous page to keep it easily
accessible. This information is
available in the sections "Service and maintenance" and "Technical data"
as well as on the identification plate.
Introduction
Your vehicle is a designed
combination of advanced technology, safety, environmental friendliness
and economy.
This Owner's Manual provides you
with all the necessary information to
enable you to drive your vehicle
safely and efficiently.
Make sure your passengers are
aware of the possible risk of accident
and injury which may result from
improper use of the vehicle.
You must always comply with the
specific laws and regulations of the
country that you are in. These laws
may differ from the information in this Owner's Manual.When this Owner's Manual refers to aworkshop visit, we recommend your
Vauxhall Authorised Repairer.
All Vauxhall Authorised Repairers
provide first-class service at
reasonable prices. Experienced
mechanics trained by Vauxhall work
according to specific Vauxhall
instructions.
The customer literature pack should
always be kept ready to hand in the
vehicle.
Using this manual ■ This manual describes all options and features available for this
model. Certain descriptions,
including those for display and
menu functions, may not apply to
your vehicle due to model variant,
country specifications, special
equipment or accessories.
■ The "In brief" section will give you an initial overview.
■ The table of contents at the beginning of this manual and withineach section shows where the
information is located.■ The index will enable you to search
for specific information.
■ This Owner's Manual depicts left- hand drive vehicles. Operation is
similar for right-hand drive vehicles.
■ The Owner's Manual uses the factory engine designations. The
corresponding sales designations
can be found in the section
"Technical data".
■ Directional data, e.g. left or right, or
front or back, always relate to the
direction of travel.
■ The vehicle display screens may not support your specific language.
■ Display messages and interior labelling are written in bold letters.
Danger, Warnings and
Cautions9 Danger
Text marked 9 Danger provides
information on risk of fatal injury.
Disregarding this information may
endanger life.

Vehicle care199Wheels and tyresTyre condition, wheel condition
Drive over edges slowly and at right
angles if possible. Driving over sharp
edges can cause tyre and wheel
damage. Do not trap tyres on the kerb
when parking.
Regularly check the wheels for
damage. Seek the assistance of a
workshop in the event of damage or
unusual wear.
We recommend not swapping the
front wheels with the rear wheels and vice versa, as this can affect vehicle
stability. Always use less worn tyres
on the rear axle.
Winter tyres Winter tyres improve driving safety attemperatures below 7 °C and shouldtherefore be fitted on all wheels.
All tyre sizes are permitted as winter
tyres 3 237.
Tyre size 185/60 R 15 is only
permitted as winter tyre.In accordance with country-specific
regulations, affix the speed sticker in
the driver's field of view.
Tyre designations E.g. 195/55 R 16 95 H195=tyre width, mm55=cross-section ratio (tyre height
to tyre width), %R=belt type: RadialRF=type: RunFlat16=wheel diameter, inches95=load index e.g. 95 is equivalent
to 690 kgH=speed code letter
Speed code letter:
Q=up to 100 mphS=up to 112 mphT=up to 118 mphH=up to 130 mphV=up to 150 mphW=up to 168 mphDirectional tyres
Directional tyres must be mounted so that they rotate in the correct
direction. The proper rotation
direction is indicated by a symbol
(e.g. an arrow) on the sidewall.
Tyre pressure
Check the pressure of cold tyres at least every 14 days and before any
long journey. Do not forget the spare
wheel.
This also applies to vehicles with tyre pressure monitoring system.
Unscrew the valve cap.

242IndexAAccessories and vehicle modifications .......................... 176
Adjustable air vents ...................126
Airbag and belt tensioners ...........88
Airbag deactivation ................46, 88
Airbag label................................... 41 Airbag system .............................. 41
Air conditioning regular operation ................................ 127
Air conditioning system .............. 119
Air intake .................................... 126
Air vents...................................... 126
Antilock brake system ................ 143
Antilock brake system (ABS) .......89
Anti-theft alarm system ................26
Anti-theft locking system .............. 26
Appearance care ........................219
Ashtrays ....................................... 81
Automatic anti-dazzle ..................29
Automatic light control ...............109
Automatic locking ........................24
Automatic transmission .............136
Autostop ....................................... 92
B Battery discharge protection ......117
Battery voltage ........................... 103 Belts.............................................. 38Bicycle rack .................................. 58
Bonnet ....................................... 178
Brake and clutch fluid .................223
Brake and clutch system .............89
Brake assist ............................... 144
Brake fluid .................................. 181
Brakes ............................... 143, 181
Breakdown.................................. 217
Bulb replacement ....................... 184
C Capacities .................................. 236
Car Pass ...................................... 20
Catalytic converter .....................135
Central locking system ................22
Centre high-mounted brake light 192
Changing tyre and wheel size ...205
Charging system .......................... 88
Child locks ................................... 24
Child restraint installation locations ................................... 50
Child restraints.............................. 48
Child restraint systems ................48
Cigarette lighter ........................... 81
City mode ................................... 146
Climate control ............................. 15 Climate control systems .............118
Clock ............................................ 79
Code ........................................... 100
Colour-Info-Display .......................98
