5428-2. Steps to take in an emergency
SIENNA_OM_01999-08001_(U)■
When a tire is replaced with a spare tire (vehicles with compact spare
tire)
The compact spare tire is not equipped with a tire pressure warning valve
and transmitter. If a tire goes flat,
the tire pressure warning light will not
turn off even though the flat tire has been replaced with the spare tire.
Replace the spare tire with the repaired tire and adjust the tire inflation
pressure. The tire pressu re warning light will go off after a few minutes.
■Conditions that the tire pressure warning system may not function
properly
 P. 4 9 3
■If the tire pressure warning light frequently comes on after blinking
for 1 minute
If the tire pressure warning light frequently comes on after blinking for 1
minute when the engine switch is turned to the “ON” position (vehicles
without a smart key system) or IGNI TION ON mode (vehicles with a
smart key system), have it checked by your Toyota dealer.
■ Customization that can be co nfigured at Toyota dealer
The vehicle speed linked seat belt reminder buzzer can be disabled.
(Customizable features P. 626) However, Toyota recommends that the seat
belt reminder buzzer be operational to alert the driver and front passenger
when seat belts are not fastened.
■ Warning buzzer
In some cases, the buzzer may not be heard because of noisy place or an
audio sound.

5848-2. Steps to take in an emergency
SIENNA_OM_01999-08001_(U)
Connect a positive jumper cable clamp to the positive (+) battery
terminal on your vehicle
Connect the clamp on the other end of the positive cable to the
positive (+) battery terminal on the second vehicle
Connect a negative cable clamp to the negative (-) battery termi-
nal on the second vehicle
Connect the clamp at the other end of the negative cable to a
solid, stationary, unpainted metallic point away from the battery
and any moving parts, as shown in the illustration.
Start the engine of the second vehicle. Increase the engine speed
slightly and maintain at that le vel for approximately 5 minutes to
recharge the batter y of your vehicle.
Vehicles with a smart key system only: Open and close any of the
doors of your vehicle with the engine switch off.
Maintain the engine speed of t he second vehicle and start the
engine of your vehicle by turni ng the engine switch to the “ON”
position (vehicles without a smart key system) or turning the engine
switch to IGNITION ON mode (v ehicles with a smart key system).
Once the vehicle’s engine has started, remove the jumper cables in
the exact reverse order from which they were connected.
To install the engine cover, conduct the removal procedure in
reverse. After installing, check that the fixed pins are inserted
securely.
Once the engine starts, have the vehicle inspected at your Toyota
dealer as soon as possible.1
2
3
4
4
5
6
7
8

598
SIENNA_OM_01999-08001_(U)
9-1. Specifications
Cooling system
Capacity
Without towing package
11.0 qt. (10.4 L, 9.2 Imp.qt.)
With towing package
11.7 qt. (11.1 L, 9.8 Imp.qt.)
Coolant type Use either of the following.
• “Toyota Super Long Life Coolant”
• A similar high-quality ethylene glycol-based non-silicate, non-amine, non-nitrite, and non-
borate coolant with long-life hybrid organic
acid technology
Do not use plain water alone.
Ignition system
Spark plug
Make
Gap DENSO FK20HR11
0.043 in. (1.1 mm)
NOTICE
■
Iridium-tipped spark plugs
Use only iridium-tipped spark plugs. Do not adjust spark plug gap.
Electrical system
Battery
Open voltage* at
68 F (20 C): 12.6
 12.8 V Fully charged
12.2  12.4 V Half charged
11 . 8  12.0 V Discharged
(
*: Voltage checked 20 minutes after the engine
and all the lights turned off)
Charging rates 5 A max.

647What to do if... (Troubleshooting)
SIENNA_OM_01999-08001_(U)
●The seat belt reminder light is flashing
Are the driver and the front passenger wearing the seat belts? (P. 539)
●The brake system warning light is on
Is the parking brake released? (P. 236)
Depending on the situation, other types of warning buzzer may also sound.
( P. 537, 546)
●Did anyone inside the vehicle open a door during setting the alarm?
The sensor detects it and the alarm sounds. ( P. 77)
To stop the alarm, turn the engine switch to the “ON” position (vehicles with-
out a smart key system) or IGNITION ON mode (vehicles with a smart key
system) or start the engine.
●Is the message displayed on the multi-information display?
Check the message on the multi-information display. ( P. 546)
A warning buzzer sounds during driving
An alarm is activated and the horn sounds (if equipped)
A warning buzzer sounds when leaving the vehicle
(vehicles with a smart key system)

653Alphabetical index
SIENNA_OM_01999-08001_(U)
Emergency, in case ofIf a warning buzzer
sounds ................................ 537
If a warning light turns on...... 537
If a warning message is displayed ............................ 546
If the battery is discharged.... 583
If the electronic key does not operate properly ........... 581
If the engine will not start ...... 578
If the shift lever cannot be shifted from P ..................... 580
If you have a flat tire .... 562, 564
If you lose your keys ............. 107
If you think something is wrong.................................. 535
If your vehicle becomes
stuck ................................... 590
If your vehicle has to be stopped in an emergency ... 529
If your vehicle needs to be towed .................................. 531
If your vehicle overheats ....... 587
Engine “ACC” position ...................... 223
Accessory mode ................... 227
Compartment ........................ 478
Engine switch................ 223, 226
Hood ..................................... 475
How to start the engine......................... 223, 226
Identification number ............ 595
If the engine will not start ...... 578
Ignition switch (engine switch) ........... 223, 226
Overheating .......................... 587 Engine coolant
Capacity................................ 598
Checking............................... 481
Preparing and checking before winter ...................... 311
Engine coolant temperature gauge ....................................... 88
Engine immobilizer system ...... 75
Engine oil
Capacity................................ 596
Checking............................... 479
Oil pressure warning light ..... 537
Oil pressure warning message............................. 553
Preparing and checking before winter ...................... 311
Engine switch .................. 223, 226
EPS (Electronic Power Steering)
Function ................................ 291
Warning light......................... 538
Warning message................. 549
Event data recorder (EDR)........ 10
*: Refer to “NAVIGATION AND MULTIMEDIA
SYSTEM OWNER’S MANUAL”

661Alphabetical index
SIENNA_OM_01999-08001_(U)
Tachometer ................................ 88
Tail lightsLight switch ........................... 237
Replacing light bulbs ................... 520, 522, 523
Wattage ................................ 602
Talk switch
*............................. 400
Telephone switch
*.................. 379
Theft deterrent system Alarm ...................................... 77
Engine immobilizer system ..... 75
Theft prevention labels ............. 80
Tire inflation pressure ............. 496 Maintenance data ................. 600
Warning light ......................... 539
Tire pressure warning system
Function ................................ 489
Initializing .............................. 489
Installing tire pressure warning valves and
transmitters......................... 489
Registering ID codes ............ 490
Tire pressure warning reset switch ........................ 489
Warning light ......................... 539
Warning message ................. 550 Tires
Chains .................................. 312
Checking............................... 488
Glossary ............................... 612
If you have a flat tire ..... 562, 564
Inflation pressure .................. 496
Information............................ 606
Replacing.............................. 564
Rotating tires ........................ 488
Size....................................... 600
Snow tires ............................. 311
Tire identification number ..... 608
Tire pressure warning system .......... ...................... 489
Uniform Tire Quality Grading .............................. 610
Warning light......................... 539
Tools ......................................... 567
Total load capacity .................. 594
Towing Dinghy towing ....................... 222
Emergency towing ................ 531
Trailer towing ........................ 208
Traction control ....................... 291
TRAC (Traction Control) Function ................................ 291
TRAC OFF switch................. 292
Trailer towing ........................... 208
Trip meter ................................... 88
Turn signal lights Replacing light bulbs........... 517, 521, 518, 523
Turn signal lever ................... 235
Wattage ................................ 602
T

5HIHUWR³1$9,*$7,21$1'08/7,0(',$
6<67(02:1(5¶60$18$/´

662Alphabetical index
SIENNA_OM_01999-08001_(U)
USB memory ............................ 347
USB port ................................... 322
Valet key ................................... 104
Vanity lightsVanity lights .......................... 435
Wattage ................................ 602
Vanity mirrors .......................... 435 Vanity lights .......................... 435
VDIM (Vehicle Dynamics
Integrated Management)....... 292
Vehicle data recordings .............. 9
Vehicle identification number ................................... 595
Vehicle stability control (VSC) ...................................... 291
Voice command system
*....... 400
VSC (Vehicle Stability Control) .................................. 291
Warning buzzers Brake system ....... ................. 537
Electric power steering system ......... ....................... 538
Key reminder ........................ 560
Low engine oil pressure ........ 537
Open door ............................. 539
Seat belt reminder ................ 539 Warning lights
ABS ...................................... 538
Brake system ....... ................. 537
Charging system................... 537
Electric power steering system .......... ...................... 538
Low engine oil pressure........ 537
Low fuel level ........................ 539
Malfunction indicator lamp .... 537
Master warning light ............. 539
Open door............................. 539
Pre-collision system.............. 538
Seat belt reminder light......... 539
Slip indicator light ................. 538
SRS airbags ......................... 538
Third seat warning light ........ 539
Tire pressure warning light ... 539
Warning messages.................. 546
Washer Checking............................... 487
Low washer fluid warning
message............................. 555
Preparing and checking
before winter ...................... 311
Switch ........................... 248, 252
Washing and waxing ............... 460
Weight Cargo capacity...................... 207
Load limits ............................ 594
Weight .................................. 594
Wheels ...................................... 499 Replacing wheels ................. 564
Size....................................... 600
Window glasses ..................... 183
Window lock switch ................ 183
U
V
W
