2015 TOYOTA SIENNA lock

624
SIENNA_OM_01999-08001_(U)
9-2. Customization
■Power sliding door* ( P. 121)
*: If equipped
■
Driving position memory* (  P. 168)
*: If equipped
FunctionDefault settingCustomized
setting
Operation signal (buzzer)OffOn – – O
Opening and closing
operationPress and hold
Press twice
––O
One short press
123
FunctionDefault settingCustomized
setting
Driver’s seat movement
when exiting the vehicleFullOff O–O
Partial
Selecting the door linking
driving position memory
with door unlock operation
Driver’s doorAll doors – – O
123

626
SIENNA_OM_01999-08001_(U)
9-2. Customization
■Illumination (P. 419)
*: If equipped
■
Seat belt reminder ( P. 539)
FunctionDefault settingCustomized
setting
Time elapsed before the
interior lights turn off 15 secondsOff
O–O
7.5 seconds
30 seconds
Operation after the engine
switch is turned to the
“LOCK” position (vehicles
without a smart key sys-
tem) or off (vehicles with a
smart key system) On Off – – O
Operation when the doors
are unlocked On Off – – O
Operation when you
approach the vehicle with
the electronic key on your
person
*
On Off – – O
Ambient lights
*On Off – – O
Time elapsed before the
outer foot lights turn off
*15 seconds Off
O–O
7.5 seconds
30 seconds
Operation of the outer foot
lights when you approach
the vehicle with the elec-
tronic key on your person
*
On Off – – O
Operation of the outer foot
lights when the doors are
unlocked
*
On Off – – O
123
FunctionDefault settingCustomized
setting
Vehicle speed linked seat
belt reminder buzzer On Off – – O
123

SIENNA_OM_01999-08001_(U)
6279-2. Customization
9
Vehicle specifications
■Vehicle customization
●When the speed-detecting automatic door lock and shift-linked automatic
door lock are both on, the door lock operates as follows:
• When shifting the shift position to any position other than P, all the doors
will be locked.
• If the vehicle is started with all the doors locked, the Speed linked door locking function would not operate.
• If the vehicle is started with any door unlocked, the Speed linked door locking function will operate.
● When the smart key system is off, the entry unlock function cannot be cus-
tomized.
● When the doors remain closed after unlocking the doors and the timer acti-
vated automatic door lock function activates, signals will be generated in
accordance with the operation buzzer volume and operational signal
(Emergency flashers) function settings.
■ When customizing on the audio system screen
Stop the vehicle in a safe place, apply the parking brake, and shift the shift
lever to P. Also, to prevent battery discharge, leave the engine running while
customizing the features.
WARNING
■ During customization
As the engine needs to be running during customization, ensure that the
vehicle is parked in a place with adequate ventilation. In a closed area such
as a garage, exhaust gases including harmful carbon monoxide (CO) may
collect and enter the vehicle. This may lead to death or a serious health
hazard.
NOTICE
■During customization
To prevent battery discharge, ensure that the engine is running while cus-
tomizing features.

644What to do if... (Troubleshooting)
SIENNA_OM_01999-08001_(U)
What to do if... (Troubleshooting)
●If you lose your keys or mechanical keys, new genuine keys or mechanical
keys can be made by your Toyota dealer. (P. 107)
●If you lose your keys or electronic keys, the risk of vehicle theft increases
significantly. Contact your Toyota dealer immediately. ( P. 109)
●Is the key battery weak or depleted? (P. 503)
●Vehicles with a smart key system
Is the engine switch in IGNITION ON mode?
When locking the doors, turn the engine switch off. ( P. 227)
●Vehicles with a smart key system
Is the electronic key left inside the vehicle?
When locking the doors, make sure that you have the electronic key on
your person.
●The function may not operate properly due to the condition of the radio
wave. ( P. 107, 144)
●Is the child-protector lock set?
The sliding door cannot be opened from inside the vehicle when the lock is
set. Open the sliding door from outside and then unlock the child-protector
lock. (P. 125)
If you have a problem, check the following before contacting
your Toyota dealer.
The doors cannot be locked, unlocked, opened or closed
You lose your keys
The doors cannot be locked or unlocked
The sliding door cannot be opened

645What to do if... (Troubleshooting)
SIENNA_OM_01999-08001_(U)
●Is the shift lever in P? (P. 223)
●Is the steering wheel unlocked? ( P. 224)
●Is the battery discharged? (P. 583)
●Did you press the engine switch while firmly depressing the brake pedal?
(P. 226)
●Is the shift lever in P? ( P. 226)
●Is the electronic key anywhere detectable inside the vehicle? ( P. 142)
●Is the steering wheel unlocked? ( P. 229)
●Is the electronic key battery weak or depleted?
In this case, the engine can be started in a temporary way. ( P. 581)
●Is the battery discharged? (P. 583)
●Is the engine switch in the “ON” position (vehicles without a smart key sys-
tem) or IGNITION ON mode (vehicles with a smart key system)?
If you cannot release the shift lever by depressing the brake
pedal with the engine switch in the “ON” position (vehicles without a smart
key system) or IGNITION ON mode (vehicles with a smart key system).
(P. 580)
If you think something is wrong
The engine does not start
(vehicles without a smart key system)
The engine does not start
(vehicles with a smart key system)
The shift lever cannot be shifted from P even if you depress
the brake pedal

646What to do if... (Troubleshooting)
SIENNA_OM_01999-08001_(U)
●Vehicles without a smart key system:
It is locked to prevent theft of the vehicle if the key is removed from the
engine switch. (P. 224)
●Vehicles with a smart key system:
It is locked automatically to prevent theft of the vehicle. ( P. 229)
●Is the window lock switch pressed?
The power window except for the one at the driver’s seat cannot be oper-
ated if the window lock switch is pressed. (P. 183)
●The auto power off function will be operated if the vehicle is left in ACCES-
SORY or IGNITION ON mode (the engine is not operating) for a period of
time. ( P. 228)
The steering wheel cannot be turned after the engine is
stopped
The windows do not open or close by operating the power
window switches
The engine switch is tu rned off automatically
(vehicles with a smart key system)

649Alphabetical index
SIENNA_OM_01999-08001_(U)
Alphabetical index
A/C .................................... 404, 413Air conditioning filter ............. 501
Front automatic air
conditioning system ............ 404
Rear automatic air
conditioning system ............ 413
ABS (Anti-lock Brake System) .................................. 291
Function ................................ 291
Warning light ......................... 538
Warning message ................. 549
Active head restraint ............... 149
Active Torque Control 4WD system ........................... 291
Function ................................ 291
Warning message ......... 553, 554
Air conditioning filter .............. 501
Air conditioning system
Air conditioning filter ............. 501
Front automatic air conditioning system ............ 404
Rear automatic air conditioning system ............ 413 Airbags ....................................... 36
Airbag operating
conditions ............................. 45
Airbag precautions for your child......................... 39
Airbag warning light .............. 538
Correct driving posture ........... 26
Curtain shield airbag operating conditions ............. 46
Curtain shield airbag precautions........................... 39
Front passenger occupant classification syst em ............ 50
General airbag
precautions........................... 39
Locations of airbags ............... 36
Modification and disposal of airbags ............... 44
Side and curtain shield airbags operating
conditions ............................. 46
Side and curtain shield airbags precautions .............. 39
SRS airbag instructions for Canadian owners .......... 633
SRS airbags ........................... 36
A

650Alphabetical index
SIENNA_OM_01999-08001_(U)
AlarmAlarm ...................................... 77
Warning buzzer..................... 537
Anchor brackets ........................ 60
Antenna Smart key system ................. 142
Radio .................................... 336
Anti-lock brake system
(ABS) ...................................... 291 Function ................................ 291
Warning light ......................... 538
Warning message ................. 549
Approach warning ................... 266
Armrest ..................................... 440
Assist grips .............................. 441
Audio input
*............................ 322
Audio system
*......................... 316
Antenna ................................ 336
A/V input port
*
Audio input*.......................... 322
Audio visual input
*
AUX port/USB port*............. 322
Blu-ray Disc™
*
CD player*............................ 337
DVD disc
*
DVD player*
HDMI port*
iPod*.................................... 343
MP3/WMA disc
*................... 337
Optimal use
*........................ 334
Portable music player
*......... 352
Radio
*.................................. 335
Rear seat entertainment
system
*
Steering wheel audio switch
*............................... 320
USB memory
*...................... 347
Audio visual input
*
Automatic High Beam ............. 242 Warning message ................. 554
Automatic light control system .................................... 240 Automatic transaxle
Automatic transaxle .............. 231
If the shift lever cannot be
shifted from P ..................... 580
S mode ................................. 232
AUX port
*................................. 322
Auxiliary box ........................... 430
A/V input port
*
Back door ................................. 132
Back-up lights Replacing light bulbs ............ 522
Wattage ................................ 602
Battery Battery checking ................... 484
If the vehicle has discharged battery.............. 583
Preparing and checking before winter ...................... 311
Warning light......................... 537
Warning message................. 551
Blind Spot Monitor (BSM) ....... 303
Bluetooth
®
Audio system*...................... 364
Hands-free system
*
(for cellular phone) ............. 366
Bottle holder ............................ 428
Brake Fluid ...................................... 483
Parking brake ....................... 236
Warning light......................... 537
Warning message......... 550, 554
Brake assist ............................. 291
Break-in tips............................. 193
Brightness control Instrument light control ........... 89
BSM (Blind Spot Monitor) ....... 303 Blind Spot Monitor
function............................... 306
Rear Cross Traffic Alert function............................... 308
B
