2015 TOYOTA SIENNA fuse box

SIENNA_OM_01999-08001_(U)
5177-3. Do-it-yourself maintenance
7
Maintenance and care
■Front turn signal/parking and front side marker lights (vehicles
without daytime running lights or with bulb type daytime run-
ning lights)
For left side only:
Open the fuse box cover. ( P. 506)
Turn the bulb base counter-
clockwise.
Remove the light bulb.
1
2
3

518
SIENNA_OM_01999-08001_(U)
7-3. Do-it-yourself maintenance
■Front turn signal lights (vehicles with LED type daytime run-
ning lights)For left side only:
Open the fuse box cover. ( P. 506)
Turn the bulb base counter-
clockwise.
Remove the light bulb.
1
2
3

SIENNA_OM_01999-08001_(U)
5197-3. Do-it-yourself maintenance
7
Maintenance and care
■Front side marker lights (vehicles with LED type daytime run-
ning lights)
For left side only:
Open the fuse box cover. ( P. 506)
Turn the bulb base counter-
clockwise.
Remove the light bulb.
1
2
3

654Alphabetical index
SIENNA_OM_01999-08001_(U)
Flat tire.............................. 562, 564
Floor mats .................................. 24
FluidAutomatic transaxle .............. 599
Brake .................................... 483
Transfer ................................ 599
Washer ................................. 487
Fog lights
Light switch ........................... 247
Replacing light bulbs............. 515
Wattage ................................ 602
Front automatic air conditioning system ............. 404
Front doors .............................. 110
Front passenger occupant
classification system .............. 50
Front seats ............................... 148
Adjustment ............................ 148
Cleaning................................ 463
Correct driving posture ........... 26
Driver’s seat position memory .............................. 168
Head restraints ..................... 172
Power easy access
system ......... ....................... 168
Seat heaters ......................... 416
Seat position memory ........... 168
Front side marker lights Light switch ........................... 237
Replacing light bulbs..... 517, 519
Wattage ................................ 602
Front turn signal lights Replacing light bulbs..... 517, 518
Turn signal lever ................... 235
Wattage ................................ 602 Fuel
Capacity................................ 596
Fuel gauge.............................. 88
Fuel pump shut off system ... 536
Gas station information......... 664
Information............................ 603
Refueling .............................. 254
Type...................................... 596
Warning light......................... 539
Warning message................. 555
Fuel consumption
information ............................ 100
Fuel filler door ......................... 254 Refueling .............................. 254
Fuel pump shut off system..... 536
Fuses ........................................ 506
Garage door opener ................ 444
Gauges ....................................... 87
Glove box ................................. 423
Grocery bag hooks.................. 443
F
G
