2015 TOYOTA SEQUOIA navigation

527
4-3. Do-it-yourself maintenance
4
Maintenance and care
13 POWER NO.4 25 A Power windows
14 FOG 15 A Front fog lights
15 STOP 15 A
Stop lights, high mounted stop-
light, vehicle stability control sys-
tem, anti-lock brake system, shift
lock system, multiport fuel injection
system/sequential multiport fuel
injection system, towing converter
16 TOW BRK 30 A Trailer brake controller
17 IMB 7.5 A Multiport fuel injection system/
sequential multiport fuel injection
system
18 AM2 7.5 A Starting system
19 TOWING 30 A Towing converter
20 AI-HTR 10 A Air injection pump heaters
21 ALT-S 5 A Charging system
22 TURN-HAZ 15 A Turn signal lights, emergency
flashers, towing converter
23 F/PMP 25 A Fuel pump
24 ETCS 10 A Multiport fuel injection system/
sequential multiport fuel injection
system, electric throttle control sys-
tem
25 MET-B 5 A Gauges and meters
26 AMP 30 A Audio system, rear view monitor,
navigation system, rear seat enter-
tainment system
27 RAD NO.1 15 A Audio system, rear view monitor,
navigation system, rear seat enter-
tainment system
FuseAmpereCircuit

533
4-3. Do-it-yourself maintenance
4
Maintenance and care
26 PANEL
7.5 AInstrument panel lights, glove box
light, ashtray, accessory meter,
audio system, rear view monitor,
navigation system, rear seat enter-
tainment system, gauges and
meters, air conditioning system,
seat heater or heated and venti-
lated switches, BSM main switch
27 ACC 7.5 AAccessory meter, audio system,
rear seat entertainment system,
rear view monitor, navigation sys-
tem, back-up lights, trailer lights
(back-up lights), multiplex commu-
nication system, power outlet, out-
side rear view mirror
28 BK/UP LP 10 A Back-up light, gauges and meters
29 CIG 15 A Cigarette lighter
30 POWER No.1 30 A Power windows, power back win-
dow
■ After a fuse is replaced
●If the lights do not turn on even after the fuse has been replaced, a bulb
may need replacement. ( P. 535)
● If the replaced fuse blows again, have the vehicle inspected by your
Toyota dealer.
■ If there is an overload in the circuits
The fuses are designed to blow, protecting the wiring harness from damage.
FuseAmpereCircuit

5
When trouble arises
583
5-2. Steps to take in an emergency
CAUTION
■Speed limit when using the temporary spare tire
Do not drive at speeds in excess of 50 mph (80 km/h) when a temporary
spare tire is installed on the vehicle.
The temporary spare tire is not designed for driving at high speeds. Fail-
ing to observe this precaution may lead to an accident causing death or
serious injury.
■Driving with tire chains and the temporary spare tire
Do not fit tire chains to the temporary spare tire.
Tire chains may damage the vehicle body and adversely affect driving
performance.
■When the temporary spare tire is attached
The vehicle speed may not be correctly detected, and the following sys-
tems may not operate correctly:
●ABS & Brake assist
●VSC
●TRAC
●A-TRAC
●AUTO LSD
●Cruise control
●Navigation system (if equipped)
Also, not only can the following syste m not be utilized fully, it may actu-
ally negatively effect t he drive-train components:
●4WD system

Index
647
Abbreviation list ..................... 648
Alphabetical index .................. 650
What to do if... ........................ 661
For vehicles with Entune Audio Plus or Entune Premium
Audio, refer to the “NAVIGATION SYSTEM OWNER’S
MANUAL” for information regarding the multimedia
system.
Multimedia system types: P. 318

651
Alphabetical index
Battery
Checking .............................. 499
If the vehicle has discharged
battery ................................ 589
Preparing and checking
before winter ...................... 275
Blind Spot Monitor .................. 236
Bluetooth
® audio..................... 377
Bluetooth® phone ................... 378
Bottle holder ............................ 428
Brake assist ............................. 255
Brakes Fluid...................................... 496
Parking brake ....................... 164
Break-in tips ............................ 147
BSM .......................................... 236
Card holder .............................. 414
Care Exterior ................................. 472
Interior .................................. 474
Seat belts ............................. 475
Cargo capacity ........................ 268
Cargo hooks ............................ 457
CD player ................................. 336
Chains ...................................... 275
Child restraint system Booster seats, definition ....... 128
Booster seats, installation .... 139
Convertible seats, definition............................. 128
Convertible seats, installation .......................... 138
Front passenger occupant
classification system .......... 123
Infant seats, definition .......... 128
Infant seats, installation ........ 137
Installing CRS with LATCH system................................ 134
Installing CRS with seat
belts ................................... 137 Installing CRS with top
tether straps ........................140
Child safety Airbag precautions ................118
Battery precautions .......500, 591
Child restraint system............128
Child-protectors .......................37
How your child should wear the seat belt ..........................75
Installing child restraints ........132
Moon roof precautions ............99
Power window lock switch.......90
Power window precautions .....92
Removed key battery precautions .........................522
Seat belt extender precautions ...........................78
Seat belt precautions ..............75
Seat heater precautions ........447
Child-protectors .........................37
Cigarette lighter .......................437
Cleaning Exterior ..................................472
Interior ...................................474
Seat belts ..............................475
Climate control seat.................448
Clock ........................................ 433
Coin holder ...............................410
Compass ...................................467
Condenser ................................496
Console box .....................411, 419
Conversation mirror ................438
Cooling system
Engine overheating ...............592
CRS ...........................................128
C
*: Refer to “NAVIGATION SYSTEM OWNER’S MANUAL”.

653
Alphabetical index
Engine coolant
Capacity ............................... 605
Checking .............................. 494
Preparing and checking before winter ...................... 275
Engine coolan t temperature
gauge ..................................... 166
Engine immobilizer system .... 104
Engine oil
Capacity ............................... 604
Checking .............................. 490
Preparing and checking before winter ...................... 275
Engine switch .......................... 156
Event data recorder .................. 25
FFV ................................... 100, 611
Flex-fuel ........................... 100, 611
Flexible fuel vehicle ........ 100, 611
Floor mat .................................. 454
Fluid Brake .................................... 496
Washer ................................. 502
Fog lights Replacing light bulbs ............ 535
Switch ................................... 191
Wattage ................................ 610
Four-wheel drive system ........ 248
Front air conditioning
system ................................... 302
Front passenger occupant
classification system............ 123
Front passenger’s seat belt reminder light ........................ 559
Front seats Adjustment ............................. 48
Front side marker lights
Replacing light bulbs ............ 535
Switch ................................... 185
Wattage ................................ 610 Front turn signal lights
Replacing light bulbs .............535
Wattage .................................610
Fuel Capacity ................................603
Fuel gauge ............................166
Fuel pump shut off system ....556
Gas station information .........664
Information ............................611
Refueling ...............................100
Type ......................................603
Fuel filler door ..........................100
Fuel pump shut off system .....556
Fuses.........................................523
Garage door opener.................461
Gas station information...........664
Gauges ......................................166
Glove box..................................409
Hands-free system (for cellular phone) ................378
Hazard lights Switch....................................548
Head restraints Adjusting ................................65
Headlight cleaner .....................199
Headlights
Replacing light bulbs .............535
Switch....................................185
Wattage .................................610
Heaters Seat heaters ..................445, 448
Side mirror.............................315
Height control Electronically modulated air
suspension..........................242
Hood ..........................................488
F
*: Refer to “NAVIGATION SYSTEM OWNER’S MANUAL”.
G
H

655
Alphabetical index
Mirrors
Conversation mirror .............. 438
Inside rear view mirror ............ 81
Side mirror heaters ............... 315
Side mirrors ............................ 84
Vanity mirrors ....................... 432
Moon roof................................... 96
MP3 disc................................... 336
Multi-information display ................................... 176
Noise from under vehicle ......... 23
Odometer ................................. 166
Off-road precautions............... 263
Oil Engine oil.............................. 490
Opener
Back door ............................... 40
Fuel filler door....................... 100
Hood ..................................... 488
Outside rear view mirror indicator................................. 236
Outside rear view mirrors
Adjusting and folding .............. 84
Indicator................................ 236
Outside temperature
display ................................... 434
Overhead console ................... 422
Overheating, Engine ............... 592 Parking assist...........................218
Parking brake ...........................164
Parking lights
Replacing light bulbs .............535
Switch....................................185
Wattage .................................610
Pen holder ................................417
Personal lights Switch....................................406
Wattage .................................610
Power back door ........................41
Power back window ...................93
Power outlet .............................439
Power windows ..........................90
N
O
P
*: Refer to “NAVIGATION SYSTEM OWNER’S MANUAL”.

657
Alphabetical index
Service reminder
indicators .............................. 171
Shift lever Automatic transmission ....................... 159
If the shift lever cannot be shifted from P ................ 587
Shift lock system..................... 587
Shopping bag hooks............... 458
Side airbags ............................. 111
Side marker lights
Replacing ............................. 535
Switch ................................... 185
Wattage ................................ 610
Side mirrors Adjusting and folding .............. 84
Spare tire
Inflation pressure .................. 609
Storage location ................... 574
Spark plug................................ 606
Specifications .......................... 600
Speedometer ........................... 166
Steering
Column lock release ............... 79
Steering wheel Adjustment ....................... 79, 80
Audio switches
*
Steering wheel memory.......... 62
Telephone switches
*
Stop lights
Replacing light bulbs ............ 535
Wattage ................................ 610
Storage feature ........................ 408
Storage precautions ............... 270 Stuck
If your vehicle becomes
stuck ...................................595
Sun visors.................................431
Sunshade ..................................451
Switch BSM main switch...................236
Emergency flasher switch .....548
Engine switch ........................156
Fog light switch .....................191
Hazard light switch ................548
Ignition switch........................156
Light switches........................185
Power back door switch ....31, 41
Power back window switch .....93
Power door lock switch ...........35
Power window switch ..............90
Rear window wiper and washer switch .....................197
Seatback folding/returning
switch ..............................54, 60
Window lock switch .................90
Wiper and washer switch .......................... 193, 197
Tachometer...............................166
Tail lights Replacing light bulbs .............535
Switch....................................185
Wattage .................................610
Talk switch
*
Telephone switch*
Theft deterrent system Alarm .....................................106
Engine immobilizer system ... 104
Tire inflation pressure .............511
T
*: Refer to “NAVIGATION SYSTEM OWNER’S MANUAL”.
