2015 TOYOTA PRIUS PLUG-IN HYBRID fuses

1
2
3
4
5
6
7
5
PRIUS PHV_OM_OM47A11U_(U)
4-1. Maintenance and careCleaning and protecting the vehicle exterior............ 430
Cleaning and protecting the vehicle interior............. 433
4-2. Maintenance Maintenance requirements ..................... 436
General maintenance.......... 439
Emission inspection and maintenance (I/M)
programs........................... 444
4-3. Do-it-yourself maintenance Do-it-yourself service precautions ....................... 445
Hood ................................... 448
Positioning a floor jack ........ 451
Replacing the tire ................ 454
Engine compartment ........... 464
12-volt battery ..................... 476
Tires .................................... 481
Tire inflation pressure ......... 490
Wheels ................................ 494
Electronic key battery.......... 497
Checking and replacing fuses ................................. 499
Light bulbs........................... 511 5-1. Essential information
Emergency flashers............ 528
If your vehicle needs to be towed................................ 529
If you think something is wrong ............................... 536
5-2. Steps to take in an emergency If a warning light turns on or a warning buzzer
sounds.............................. 537
If a warning message is displayed .......................... 550
If you have a flat tire ........... 574
If the hybrid system will not start ...................... 596
If you lose your keys........... 598
If the electronic key does not operate properly ......... 599
If the 12-volt battery is discharged........................ 601
If your vehicle overheats .... 607
If the vehicle becomes stuck ................................. 613
If your vehicle has to be stopped in an
emergency ....................... 615
4Maintenance and care5When trouble arises

Maintenance and care4
429
PRIUS PHV_OM_OM47A11U_(U)
4-1. Maintenance and careCleaning and protecting the vehicle exterior ......... 430
Cleaning and protecting the vehicle interior .......... 433
4-2. Maintenance Maintenance requirements .................. 436
General maintenance....... 439
Emission inspection and maintenance (I/M)
programs........................ 444
4-3. Do-it-yourself maintenance Do-it-yourself service precautions .................... 445
Hood ................................ 448
Positioning a floor jack ..... 451
Replacing the tire ............. 454
Engine compartment ........ 464
12-volt battery .................. 476
Tires ................................. 481
Tire inflation pressure ...... 490
Wheels ............................. 494
Electronic key battery....... 497
Checking and replacing fuses .............................. 499
Light bulbs........................ 511

446 4-3. Do-it-yourself maintenance
PRIUS PHV_OM_OM47A11U_(U)
ItemsParts and tools
Engine oil level (P. 465)
• “Toyota Genuine Motor Oil” or
equivalent
• Rag or paper towel
• Funnel (used only for adding engine oil)
Fuses (P. 499)• Fuse with same amperage rating
as original
Light bulbs (P. 511)
• Bulb with same number and watt-
age rating as original
• Phillips-head screwdriver
• Flathead screwdriver
• Wrench
Radiator and condenser (P. 471)
Tire inflation pressure ( P. 490)• Tire pressure gauge
• Compressed air source
Washer fluid ( P. 474)
• Water or washer fluid containing
antifreeze (for winter use)
• Funnel (used only for adding water or washer fluid)

499
4-3. Do-it-yourself maintenance
PRIUS PHV_OM_OM47A11U_(U)
4
Maintenance and care
Checking and replacing fuses
If any of the electrical components do not operate, a fuse may have
blown. If this happens, check and replace the fuses as necessary.
Turn the “POWER” switch off.
Vehicles with Solar Ventilation Sy stem: Turn the Solar Ventilation
System off and make sure not to operate the Remote Air Condi-
tioning System.
Open the fuse box cover.
Engine compartment
Push the tab in and lift the lid
off.
When closing, first hook the lid
onto the two rear tabs.
Left side instrument panelRemove the lid.
After a system failure, see “Fuse layout and amperage rat-
ings” ( P. 502) for details about which fuse to check.
STEP 1
STEP 2
ITO43P127
STEP 3

509
4-3. Do-it-yourself maintenance
PRIUS PHV_OM_OM47A11U_(U)
4
Maintenance and care
■
After a fuse is replaced
●If the lights do not turn on even after the fuse has been replaced, a bulb
may need replacement. ( P. 511)
● If the replaced fuse blows again, have the vehicle inspected by your
Toyota dealer.
■ If there is an overload in a circuit
The fuses are designed to blow, protecting the wiring harness from damage.
■ When replacing light bulbs
Toyota recommends that you use genuine Toyota products designed for this
vehicle. Because certain bulbs are connected to circuits designed to prevent
overload, non-genuine parts or parts not designed for this vehicle may be
unusable.
CAUTION
■To prevent system breakdowns and vehicle fire
Observe the following precautions.
Failure to do so may cause damage to the vehicle, and possibly a fire or
injury.
●Never use a fuse of a higher amperage rating than that indicated, or use
any other object in place of a fuse.
● Always use a genuine Toyota fuse or equivalent.
Never replace a fuse with a wire, even as a temporary fix.
● Do not modify the fuses or fuse boxes.
■ Fuse box near the power control unit
Never check or replace the fuses as there are high voltage parts and wiring
near the fuse box.
Doing so may cause electric shock, resulting in death or serious injury.

510 4-3. Do-it-yourself maintenance
PRIUS PHV_OM_OM47A11U_(U)
NOTICE
■Before replacing fuses
Have the cause of electrical overload determined and repaired by your
Toyota dealer as soon as possible.

680 Alphabetical index
PRIUS PHV_OM_OM47A11U_(U)
EngineAccessory mode.................... 244
Compartment ........................ 464
Hood...................................... 448
How to start the hybrid system ................................ 242
Identification number ............. 620
If the hybrid system will not start ..................................... 596
Ignition switch........................ 242
Overheating........................... 607
“POWER” switch ................... 242
Engine coolant Capacity ................................ 625
Checking ............................... 469
Preparing and checking before winter ....................... 355
Engine/power control
unit coolantCapacity ................................ 625
Checking ............................... 469
Preparing and checking before winter ....................... 355
Engine oil Capacity ................................ 622
Checking ............................... 465
Preparing and checking before winter ....................... 355
Enhanced VSC ......................... 333
EPS ............................................ 333
EV driving ratio indicator ........ 276
EV driving range ................58, 273
Event data recorder ...................25
EV/HV mode selection switch .......................................37 Floor mats ................................ 407
Fluid
Brake..................................... 627
Washer.................................. 474
Fog lights Replacing light bulbs ............. 511
Switch ................................... 303
Wattage................................. 628
Foot lights ................................ 388
Front fog lights
Replacing light bulbs ............. 511
Switch ................................... 303
Wattage................................. 628
Front passenger occupant classification system ............ 202
Front passenger’s seat belt reminder light ........................ 541
Front seats
Adjustment ............................ 150
Front side marker light Replacing light bulbs ............. 511
Wattage................................. 628
Front turn signal lights Replacing light bulbs ............. 511
Switch ................................... 259
Wattage................................. 628
Fuel Capacity ................................ 621
Fuel gauge ............................ 262
Information ............................ 629
Refueling ............................... 178
Type ...................................... 629
Fuel door .................................. 178
Fuel filler door .......................... 178
Fuses ........................................ 499F

683
Alphabetical index
PRIUS PHV_OM_OM47A11U_(U)
Odometer ................................. 278
Oil
Engine oil.............................. 465
Opener Back door ............................. 144
Fuel filler door....................... 178
Hood ..................................... 448
Outside rear view mirrors Adjusting and folding ............ 173
Outside rear view mirror defogger switch .................... 381
Outside temperature
display ................................... 400
Overheating ............................. 607
Parking brake .......................... 260
Parking lights Switch ................................... 297
PCS ........................................... 340
Personal lights Switch ................................... 389
Wattage ................................ 628
Plug-in hybrid system Driving tips.............................. 68
EV driving range ..................... 58
EV mode................................. 35
EV/HV mode selection
switch ................................... 37
Features ................................. 32
How to charge ........................ 85
HV mode ................................ 36
Plug-in Hybrid Applications .... 75
Power outlets........................... 401
Power sources........................... 82
“POWER” switch ..................... 242
Power windows ....................... 175
Pre-collision system ............... 340 Radar cruise control
system ....................................317
Radiator ....................................471
Radio
*
Radio data system*
RDS*
Rear seats
Adjustment ............................153
Folding down .........................154
Rear turn signal lights Replacing light bulbs .............511
Wattage .................................628
Rear view mirror...............170, 173
Rear view monitor system
*
Rear window and outside rear view mirror
defoggers ...............................381
Rear window wiper and
washer ....................................309
Remote Air C onditioning
System ....................................377
Replacing
Electronic key battery ............497
Fuses ....................................499
Light bulbs .............................511
Tires ......................................454
Reporting safety defects for U.S. owners ............................658
Resetting the message indicating maintenance is
required ..................................437
O
P
R
*: Refer to “DISPLAY AUDI O SYSTEM OWNER’S MANUAL”
or “NAVIGATION SYSTEM OWNER’S MANUAL”.
