2015 TOYOTA PRIUS PLUG-IN HYBRID tire type

634 6-1. Specifications
PRIUS PHV_OM_OM47A11U_(U)
Typical DOT and Tire Identification Number (TIN)DOT symbol
*
Tire Identification Number
(TIN)
Tire manufacturer’s identifica-
tion mark
Tire size code
Manufacturer’s optional tire
type code (3 or 4 letters)
Manufacturing week
Manufacturing year
*: The DOT symbol certifiesthat the tire conforms to
applicable Federal Motor
Vehicle Safety Standards.
Load limit at maximum cold tire inflation pressure ( P. 485)
Maximum cold tire in flation pressure ( P. 627)
This means the pressure to which a tire may be inflated.
Uniform tire quality grading
For details, see “Uniform Tire Quality Grading” that follows.

640 6-1. Specifications
PRIUS PHV_OM_OM47A11U_(U)
Tire related termMeaning
Normal occupant
weight 150 lb. (68 kg) times the number of occupants
specified in the second column of Table 1
* that
follows
Occupant distribution Distribution of occupants in a vehicle as speci-
fied in the third column of Table 1
* below
Production options
weight The combined weight of installed regular pro-
duction options weighing over 5 lb. (2.3 kg) in
excess of the standard items which they
replace, not previously considered in curb
weight or accessory weight, including heavy
duty brakes, ride levelers, roof rack, heavy duty
12-volt battery, and special trim
Rim A metal support for a tire or a tire and tube
assembly upon which the tire beads are seated
Rim diameter
(Wheel diameter) Nominal diameter of the bead seat
Rim size designation Rim diameter and width
Rim type designation The industry manufacturer’s designation for a
rim by style or code
Rim width Nominal distance between rim flanges
Vehicle capacity
weight (Total load
capacity) The rated cargo and luggage load plus 150 lb.
(68 kg) times the vehicle’s designated seating
capacity

692
PRIUS PHV_OM_OM47A11U_(U)GAS STATION INFORMATION
Fuel filler door
P. 178Auxiliary catch lever P. 4 4 8
Fuel filler door opener P. 178Tire inflation pressureP. 627Hood lock release lever P. 448
Fuel tank capacity
(Reference)10.6 gal. (40 L, 8.8 Imp.gal.)
Fuel type Unleaded gasoline only P. 621
Cold tire inflation
pressure P. 6 2 7
Engine oil capacity
(Drain and refill

reference) qt. (L, Imp.qt.)
With filter 4.4 (4.2, 3.7)
Without filter 4.1 (3.9, 3.4)
Engine oil type Toyota Genuine Motor Oil or equivalent
Oil grade: ILSAC GF-5 multigrade engine oil
P. 6 2 2
