2015 TOYOTA PRIUS dimensions

572
PRIUS_OM_OM47A17U_DVD_(U)
6-1. Specifications
Maintenance data (fuel, oil level, etc.)
Dimensions and weight
*1: Unladen vehicle
*2: Vehicles without moon roof with Solar Panel
*3: Vehicles with moon roof with Solar Panel
*4: Vehicles with 15-inch tires
*5: Vehicles with 17-inch tires
Overall length176.4 in. (4480 mm)
Overall width68.7 in. (1745 mm)
Overall height*158.7 in. (1490 mm)*2
59.3 in. (1505 mm)*3
Wheelbase106.3 in. (2700 mm)
Tread
Front60.0 in. (1525 mm)*4
59.6 in. (1515 mm)*5
Rear59.8 in. (1520 mm)*4
59.4 in. (1510 mm)*5
Vehicle capacity weight
(Occupants + luggage) 825 lb. (370 kg)

590 6-1. Specifications
PRIUS_OM_OM47A17U_DVD_(U)
Tire size■ Typical tire size information
The illustration indicates typical tire size. Tire use
(P = Passenger car,
T = Temporary use)
Section width (millimeters)
Aspect ratio
(tire height to section width)
Tire construction code
(R = Radial, D = Diagonal)
Wheel diameter (inches)
Load index (2 digits or 3 digits)
Speed symbol
(alphabet with one letter)
■ Tire dimensions
Section width
Tire height
Wheel diameter
ITO61P106
ITO61P103

632 Alphabetical index
PRIUS_OM_OM47A17U_DVD_(U)
Child safetyAirbag precautions ................150
Back door precautions ............96
Child restraint system............ 162
Child-protectors .......................89
How your child should wear the seat belt ........................ 112
Installing child restraints ........ 167
Power window lock switch..... 125
Power window precautions ... 127
Removed electronic key battery precautions ......................... 465
Seat belt extender precautions ......................... 117
Seat belt precautions ............ 113
Seat heater precautions ........ 376
12-volt battery precautions .... 443
Child-protectors .........................89
Cleaning
Exterior .................................. 404
Interior ................................... 407
Seat belts .............................. 408
Clock ......................................... 233
Condenser ................................ 435
Console box ............................. 365
Cooling system Engine overheating ............... 561
Hybrid system overheating.... 561
Cruise control Cruise control ........................ 269
Dynamic radar cruise control ................................. 273
Cup holders .............................. 366
Curtain shield airbags ............. 141
Customizable features............. 602 Daytime running light
system .................................... 256
Deck board ............................... 381
Defogger
Rear window ......................... 352
Side mirrors........................... 352
Dimensions .............................. 572
Dinghy towing .......................... 329
Display Dynamic radar cruise control ................................. 273
Multi-information ................... 226
Warning messages ............... 517
Do-it-yourself maintenance .... 419
Door lock Back door ................................ 94
Side doors ............................... 88
Smart key system .. ................. 63
Wireless remote control .......... 86
Doors Back door ................................ 94
Door glasses ......................... 125
Door lock ..................... 63, 86, 88
Rear door child-protector ........ 89
Side doors ............................... 88
Driver’s seat belt reminder light ......................................... 508
Driving
Break-in tips .......................... 183
Correct posture ..................... 139
Procedures............................ 182
Winter driving tips ................. 323D
