2015 TOYOTA AVALON stop start

3556-3. Do-it-yourself maintenance
6
Maintenance and care
AVALON (U)_(OM41456U)7 ST/AM2 30 A Starter system
8 H-LP-MAIN 30 A
H-LP LH-LO, H-LP RH-LO, headlights
(low beam)
9 ABS NO.1 50 A Vehicle stability control system
10 EPS 80 A Electric power steering 11 S-HORN 7.5 A S-HORN
12 HORN 10 A Horns
13 EFI NO.2 15 A Multiport fuel injection system/sequential
multiport fuel injection system, electronic
controlled transmission
14 EFI NO.3 10 A Multiport fuel injection system/sequential
multiport fuel injection system
15 INJ 7.5 A Multiport fuel injection system/sequential
multiport fuel injection system
16 ECU-IG2 NO.3 7.5 A Multiport fuel injection system/sequential
multiport fuel injection system, steering
lock system, electronic controlled trans-
mission, stop lights, high-mounted stop
light
17 IGN 15 A Starter system
18 D/L-AM2 20 A No circuit
19 IG2-MAIN 25 A IGN, INJ, METER-IG2, ECU-IG2 NO.3,
A/B, ECU-IG2 NO.2, ECU-IG2 NO.1
20 ALT-S 7.5 A Charging system
21 MAYDAY 5 A MAYDAY
22 TURN&HAZ 15 A Turn signal lights, emergency flashers,
gauge and meters
23 STRG LOCK 10 A Steering lock system
24 AMP 15 A Audio system
25 H-LP LH-LO 20 A
*1
Left-hand headlight (low beam)
15 A*2
26 H-LP RH-LO 20 A*1
Right-hand headlight (low beam)
15 A*2
FuseAmpereCircuit

3596-3. Do-it-yourself maintenance
6
Maintenance and care
AVALON (U)_(OM41456U)33 TAIL 10 A
Parking lights, side marker lights, stop/tail
lights, rear turn signal lights, back up
lights, license plate lights, fog lights
34 PANEL 10 A Switch illumination, air conditioning sys-
tem, glove box light, interior lights, per-
sonal lights, audio system, navigation
system, rear sunshade, seat heater,
Blind Spot Monitor, driving mode select
switch, steering wheel switch, ambient
light, trunk opener switch, vehicle stability
control off switch, emergency flashers,
outside rear view mirrors
35 ECU-IG1 NO.1 10 A Vehicle stability control system, electric
cooling fans, steering sensor, multiport
fuel injection system/sequential multiport
fuel injection system, charging system,
rear window defogger, outside rear view
mirror defoggers, rain-sensing windshield
wipers, Blind Spot Monitor, rear sun-
shade, dynamic radar cruise control, mul-
tiplex communication system, rear seat
heater, backup lights, fog lights, headlight
(high beam), daytime running light, pre-
collision system
36 ECU-IG1 NO.2 10 A Shift lock control system, seat heaters,
smart key system, tire pressure warning
system, wireless remote control, multi-
plex communication system, audio sys-
tem, navigation system, moon roof, auto
anti-glare inside rear view mirror, outside
rear view mirrors, pre-collision system,
air conditioning controls, rain-sensing
windshield wipers, starting system,
dynamic radar cruise control
FuseAmpereCircuit

379
When trouble arises7
AVALON (U)_(OM41456U)7-1. Essential information
Emergency flashers .......... 380
If your vehicle has to be stopped in an
emergency ...................... 381
7-2. Steps to take in an emergency
If your vehicle needs to be towed ......................... 382
If you think something is wrong .......................... 386
Fuel pump shut off system ............................ 387
If a warning light turns on or a warning buzzer
sounds ............................ 388
If a warning message is displayed ..................... 399
If you have a flat tire.......... 400
If the engine will not start ................................. 413
If the shift lever cannot be shifted from P............. 415
If the electronic key does not operate properly........ 416
If the vehicle battery is discharged ...................... 419
If your vehicle overheats ........................ 423
If the vehicle becomes stuck ............................... 426

3877-2. Steps to take in an emergency
7
When trouble arises
AVALON (U)_(OM41456U)
Follow the procedure below to restart the engine after the system is
activated.Turn the engine switch to ACCESSORY mode or turn it off.
Restart the engine.
Fuel pump shut off system
To minimize the risk of fuel leakage when the engine stalls or
when an airbag inflates upon collision, the fuel pump shut off
system stops the supply of fuel to the engine.
NOTICE
■Before starting the engine
Inspect the ground under the vehicle.
If you find that fuel has leaked onto the ground, the fuel system has been
damaged and is in need of repair. Do not restart the engine.
1
2

3977-2. Steps to take in an emergency
7
When trouble arises
AVALON (U)_(OM41456U)
CAUTION
■Maintenance of the tires
Each tire, including the spare (if provided), should be checked monthly
when cold and inflated to the inflation pressure recommended by the
vehicle manufacturer on the vehicle placard or tire inflation pressure
label (tire and load information label). (If your vehicle has tires of a dif-
ferent size than the size indicated on the vehicle placard or tire inflation
pressure label [tire and load information label], you should determine
the proper tire inflation pressure for those tires.)
As an added safety feature, your vehicle has been equipped with a tire
pressure monitoring system (TPMS-ti re pressure warning system) that
illuminates a low tire pre ssure telltale (tire pressure warning light) when
one or more of your tires is significantly under-inflated. Accordingly,
when the low tire pressure telltale (tire pressure warning light) illumi-
nates, you should stop and check your tires as soon as possible, and
inflate them to the proper pressure. Driving on a significantly under-
inflated tire causes the tire to overheat and can lead to tire failure.
Under-inflation also reduces fuel effi ciency and tire tread life, and may
affect the vehicle’s hand ling and stopping ability.
Please note that the TPMS (tire pres sure warning system) is not a sub-
stitute for proper ti re maintenance, and it is the driver’s responsibility to
maintain correct tire pressure, even if under-inflation has not reached
the level to trigger illumina tion of the TPMS low tire pressure telltale (tire
pressure warning light).
Your vehicle has also been equipped with a TPMS (tire pressure warn-
ing system) malfunction indicator to indicate when the system is not
operating properly. The TPMS (tire pressure warning system) malfunc-
tion indicator is combined with the lo w tire pressure telltale (tire pressure
warning light). When the system dete cts a malfunction, the telltale will
flash for approximately one minute and then remain continuously illumi-
nated. This sequence will continue up on subsequent vehicle start-ups
as long as the malfunction exists. When the malfunction indicator is illu-
minated, the system may not be able to detect or signal low tire pres-
sure as intended.

4187-2. Steps to take in an emergency
AVALON (U)_(OM41456U)
■Stopping the engine
Shift the shift lever to P and press the engine switch as you normally do when
stopping the engine.
■ Replacing the key battery
As the above procedure is a temporary measure, it is recommended that the
electronic key battery be replaced immediately when the battery is depleted.
(P. 350)
■ Changing engine switch modes
Release the brake pedal and press the engine switch in step above.
The engine does not start and modes will be changed each time the switch is
pressed.( P. 160)
■ When the electronic key does not work properly
●Make sure that the smart key system has not been deactivated in the cus-
tomization setting. If it is off, turn the function on.
(Customizable features P. 455)
● Check if battery-saving mode is set. If it is set, cancel the function.
(P. 101)
3

4247-2. Steps to take in an emergency
AVALON (U)_(OM41456U)
Add engine coolant if neces-
sary.
Water can be used in an emer-
gency if engine coolant is unavail-
able.
Start the engine and turn the air conditioning system on to check
that the radiator cooling fans oper ate and to check for coolant leaks
from the radiator or hoses.
The fans operate when the air conditioning system is turned on immedi-
ately after a cold start. Confirm that the fans are operating by checking the
fan sound and air flow. If it is difficult to check these, turn the air condition-
ing system on and off repeatedly. (The fans may not operate in freezing
temperatures.)
If the fans are not operating:
Stop the engine immediately and contact your Toyota dealer.
If the fans are operating:
Have the vehicle in spected at the nearest Toyota dealer.
5
6
7

4267-2. Steps to take in an emergency
AVALON (U)_(OM41456U)
Stop the engine. Set the parking brake and shift the shift lever to P.
Remove the mud, snow or sand from around the front wheels.
Place wood, stones or some other material under the front wheels
to help provide traction.
Restart the engine.
Shift the shift lever to D or R and release the parking brake. Then,
while exercising caution, depress the accelerator pedal.
■ When it is difficult to free the vehicle
If the vehicle becomes stuck
Carry out the following procedures if the tires spin or the vehicle
becomes stuck in mud, dirt or snow:
Press to turn off TRAC.
CAUTION
■When attempting to free a stuck vehicle
If you choose to push the vehicle back and forth to free it, make sure the
surrounding area is clear to avoid striking other vehicles, objects or people.
The vehicle may also lunge forward or lunge back suddenly as it becomes
free. Use extreme caution.
■ When shifting the shift lever
Be careful not to shift the shift lever with the accelerator pedal depressed.
This may lead to unexpected rapid acceleration of the vehicle that may
cause an accident resulting in death or serious injury.
1
2
3
4
5
