2015 TOYOTA 4RUNNER spare tire location

3646-3. Do-it-yourself maintenance
4RUNNER (U)_(OM35B18U)
New tread
Treadwear indicator
Worn tread
The location of treadwear indica-
tors is shown by the “TWI” or “”
marks, etc., molded on the side-
wall of each tire.
Check spare tire condition and
pressure if not rotated.
Vehicles without P245/60R20 tires
Rotate the tires in the order
shown.
To equalize tire wear and extend
tire life, Toyota recommends that
tire rotation is carried out at the
same interval as tire inspection.
Vehicles with P245/60R20 tires
Rotate the tires in the order
shown.
To equalize tire wear and extend
tire life, Toyota recommends that
tire rotation is carried out at the
same interval as tire inspection.
Tires
Replace or rotate tires in acco rdance with maintenance sched-
ules and treadwear.
Checking tires
1
2
3
Tire rotation
Front
Front

4187-2. Steps to take in an emergency
4RUNNER (U)_(OM35B18U)■
If the tire pressure warning system is not functioning
The tire pressure warning system will be disabled in the following condi-
tions:
(When the condition be
comes normal, the system will work properly.)
●If tires not equipped with tire pressure warning valves and transmitters
are used
●If the ID code on the tire pressure warning valves and transmitters is not
registered in the tire pressure warning computer
●If the tire inflation pressure is 73 psi (500 kPa, 5.1 kgf/cm2 or bar) or
higher
The tire pressure warning system may be disabled in the following condi-
tions:
(When the condition be comes normal, the system will work properly.)
●If electronic devices or facilities using similar radio wave frequencies are
nearby
●If a radio set at a similar frequency is in use in the vehicle
●If a window tint that affects the radio wave signals is installed
●If there is a lot of snow or ice on the vehicle, particularly around the
wheels or wheel housings
●If non-genuine Toyota wheels are used (Even if you use Toyota wheels,
the tire pressure warning system may not work properly with some types
of tires.)
●If tire chains are used
●Vehicles with P245/60R20 tires: If th e spare tire is in a location subject
to poor radio wave signal reception
●Vehicles with P245/60R20 tires: If a large metallic object which can
interfere with signal reception is put in the luggage compartment
■If the tire pressure warning light frequently comes on after blinking
for 1 minute
If the tire pressure warning light frequently comes on after blinking for 1
minute when the engine switch is turned on, have it checked by your
Toyota dealer.
■ Customization that can be co nfigured at Toyota dealer
The vehicle speed linked seat belt reminder buzzer can be disabled.
(Customizable features P. 481) However, Toyota recommends that the seat
belt reminder buzzer be operational to alert the driver and front passenger
when seat belts are not fastened.

4297-2. Steps to take in an emergency
7
When trouble arises
4RUNNER (U)_(OM35B18U)
Spa re ti r e
Jack
Tool bag
Location of the spare tire, jack and tools
1
2
3

520Alphabetical index
4RUNNER (U)_(OM35B18U)
Side mirrors ............................. 143Adjusting and folding ............ 143
Side turn signal lights ............. 202
Smart key system .................... 103 Antenna location ................... 103
Entry functions ........................ 96
Starting the engine................ 194
Snow tires ................................ 271
Slide deck ................................. 306
Spare tire .................................. 428 Inflation pressure .................. 464
Storage location .................... 429
Spark plug ................................ 460
Specifications .......................... 456
Speedometer .............................. 81
Steering lock ............................ 196 Column lock release ............. 197
Steering lock system
warning message ............... 427
Steering wheel ......................... 139
Adjustment ............................ 139
Storage feature ........................ 296
Storage precautions ................ 171 Stuck
If the vehicle becomes
stuck ................................... 453
Sun visors ................................ 308
Switches Cruise control switch ............ 221
“DISP” button .......................... 84
Door lock switches.................. 98
Driving position memory switches ............................. 132
Emergency flashers switch ... 400
Engine switch ............... 191, 194
Fog light switch ..................... 210
Garage door opener
switches ............................. 320
Ignition switch ............... 191, 194
Light switches ....................... 204
Moon roof switches............... 152
Outside rear view mirror switches ............................. 143
Power back window switch ................................. 148
Power door lock switch ........... 98
Power window switches........ 145
Rear window wiper and
washer switch..................... 215
