2015 TOYOTA 4RUNNER warning lights

481-1. For safe use
4RUNNER (U)_(OM35B18U)■
Unoccupied
Indicator/
warning light
“AIR BAG ON” and “AIR BAG OFF” indicator lightsNot illuminated
SRS warning light
Off
Seat belt reminder light
Devices
Front passenger airbagDeactivated
Side airbag on the front passenger seat
ActivatedCurtain shield airbag in the front passenger side
Front passenger knee airbagDeactivated
Front passenger's seat belt pretensioner
Activated*6
or
deactivated
*7

491-1. For safe use
1
For safety and security
4RUNNER (U)_(OM35B18U)■
There is a malfunction in the system
*1: The system judges a person of adult size as an adult. When a smaller
adult sits in the front passenger seat, the system may recognize him/her
as a child depending on his/her physique and posture.
*2: In the event the front passenger does not wear a seat belt.
*3: When a larger child who has outgrown a child restraint system sits in thefront passenger seat, the system may recognize him/her as an adult
depending on his/her physique or posture.
*4: Never install a rear-facing child restraint system on the front passengerseat. A forward-facing child restraint system should only be installed on
the front passenger seat when it is unavoidable.
(P. 53)
*5: In case the indicator light is not illuminated, consult this manual on how
to install the child restraint system properly. ( P. 57)
*6: In the event of a side collision.
*7: In the event of a frontal collision or vehicle rollover.
Indicator/
warning light
“AIR BAG ON” and “AIR BAG OFF” indicator lights“AIR BAG OFF”
SRS warning lightOn
Seat belt reminder lightFlashing
Devices
Front passenger airbagDeactivated
Side airbag on the front passenger seat
ActivatedCurtain shield airbag in the front passenger side
Front passenger knee airbagDeactivated
Front passenger's seat belt pretensionerActivated

75
Instrument cluster2
4RUNNER (U)_(OM35B18U)2. Instrument cluster
Warning lights and indicators .......................... 76
Gauges and meters ............ 81
Multi-information display ..... 83

76
4RUNNER (U)_(OM35B18U)
2. Instrument cluster
The units used on the speedometer and some indicators may differ
depending on where the vehicle is sold.
Warning lights and indicators
The warning lights and indicators on the instrument cluster and
center panel inform the driver of the status of the vehicle’s vari-
ous systems.
For the purpose of explanation, the following illustration dis-
plays all warning lights a nd indicators illuminated.

772. Instrument cluster
2
Instrument cluster
4RUNNER (U)_(OM35B18U)
Warning lights inform the driver of malfunctions in the indicated vehi-
cle’s systems.
Warning lights
*1
(U.S.A.)
Brake system warning
light ( P. 412)*2
Cruise control indicator
light (P. 413)
*1
(Canada)
Brake system warning
light (P. 412)*1
Slip indicator ( P. 413)
*1
Charging system warn-
ing light (P. 412)*3
(if equipped)
Four-wheel drive indica-
tor light (P. 413)
*1
(U.S.A.)
Malfunction indicator
lamp (P. 412)*3
(if equipped)
Low speed four-wheel
drive indicator light
(P. 414)
*1
(Canada)
Malfunction indicator
lamp ( P. 412)*3
(if equipped)
Rear differential lock
indicator light ( P. 413)
*1
SRS warning light
(P. 413)*3
(if equipped)
Center differential lock
indicator light ( P. 414)
*1
(U.S.A.)
ABS warning light
(P. 413)*4
(if equipped)
Multi-terrain Select indi-
cator light ( P. 414)
*1
(Canada)
ABS warning light
(P. 413)
(if equipped)
Smart key system warn-
ing light ( P. 415)

782. Instrument cluster
4RUNNER (U)_(OM35B18U)
*1: These lights turn on when the engine switch is turned to IGNITION ONmode (vehicles with a smart key system) or the engine switch is turned to
the “ON” position (vehicles without a smart key system) to indicate that a
system check is being performed. They will turn off after the engine is
started, or after a few seconds. There may be a malfunction in a system if
the lights do not come on, or do not turn off. Have the vehicle inspected by
your Toyota dealer.
*2: The light flashes to indicate a malfunction.
*3: The light flashes rapidly to indicate a malfunction.
*4: The light flashes continuously to indicate a malfunction.
Open door warning light
(P. 414)*1Master warning light
(P. 421)
Low fuel level warning
light ( P. 414)*1Tire pressure warning
light (P. 415)
Seat belt reminder light
(P. 415)
(if equipped)
Unengaged “Park” warn-
ing light ( P. 414)
*1
Low engine oil pressure
warning light ( P. 412)*1
(if equipped)
KDSS warning light
(P. 414)
*1
Power steering warning
light ( P. 414)*1, 2
(if equipped)
Automatic running
boards indicator light
(P. 414)

802. Instrument cluster
4RUNNER (U)_(OM35B18U)
*1: These lights turn on when the engine switch is turned to the “ON” position(vehicles without a smart key system) or the engine switch is turned to
IGNITION ON mode (vehicles with a smart key system) to indicate that a
system check is being performed. They will turn off after the engine is
started, or after a few seconds. There may be a malfunction in a system if
the lights do not come on, or do not turn off. Have the vehicle inspected by
your Toyota dealer.
*2: The light flashes to indicate that the system is operating.
*3: The light does not turn on when the system is disabled.
*4: This light illuminates on the center panel.
(if equipped)
“A-TRAC” indicator
(P. 239)*1
(if equipped)
Crawl Control indicator
(P. 249)
*1
(if equipped)
“AUTO LSD” indicator
(P. 241)*1, 2
(if equipped)
Automatic running
boards indicator
(P. 111 )
(if equipped)
Multi-terrain Select indi-
cator (P. 252)
CAUTION
■ If a safety system warning light does not come on
Should a safety system light such as the ABS and SRS warning light not
come on when you start the engine, this could mean that these systems are
not available to help protect you in an accident, which could result in death
or serious injury. Have the vehicle inspected by your Toyota dealer immedi-
ately if this occurs.

4127-2. Steps to take in an emergency
4RUNNER (U)_(OM35B18U)
If a warning light turns on or a warning
buzzer sounds
Calmly perform the following actions if any of the warning lights
comes on or flashes. If a light comes on or flashes, but then
goes off, this does not necessarily indicate a malfunction in the
system. However, if this continues to occur, have the vehicle
inspected by your Toyota dealer.
Warning light and warning buzzer list
Warning lightWarning light/Details/Actions
(U.S.A.)
(Canada)
Brake system warning light (warning buzzer)*1
• Low brake fluid
• Malfunction in the brake system
This light also comes on when the parking brake is not
released. If the light turns off after the parking brake is
fully released the system is operating normally.
 Immediately stop the vehicle in a safe place and
contact your Toyota dealer. Continuing to drive
the vehicle may be dangerous.
Charging system warning light
Indicates a malfunction in the vehicle’s charging sys-
tem
 Immediately stop the vehicle in a safe place and
contact your Toyota dealer.
Low engine oil pressure warning light
Indicates that the engine oil pressure is too low
 Immediately stop the vehicle in a safe place and
contact your Toyota dealer.
(U.S.A.)
(Canada)
Malfunction indicator lamp Indicates a malfunction in:
• The emission control system;
• The electronic engine control system;
• The electronic throttle control system; or
• The electronic automatic transmission control sys-tem
 Have the vehicle inspected by your Toyota dealer
immediately.
