2015 TOYOTA 4RUNNER seat adjustment

1313-3. Adjusting the seats
3
Operation of each component
4RUNNER (U)_(OM35B18U)
CAUTION
■When folding the rear seatbacks down
Observe the following precautions. Failure to do so may result in death or
serious injury.
● Do not fold the seatbacks down while driving.
● Stop the vehicle on level ground, set the parking brake and shift the shift
lever to P.
● Do not allow anyone to sit on a folded seatback or in the luggage compart-
ment while driving.
● Do not allow children to enter the luggage compartment.
■ Seat adjustment
● To reduce the risk of sliding under the lap belt during a collision, do not
recline the seat more than necessary.
If the seat is too reclined, the lap belt may slide past the hips and apply
restraint forces directly to the abdomen, or your neck may contact the
shoulder belt, increasing the risk of death or serious injury in the event of
an accident.
Adjustments should not be made while driving as the seat may unexpect-
edly move and cause the driver to lose control of the vehicle.
● Take care when adjusting the seat position to ensure that other passen-
gers are not injured by the moving seat.
● Do not put your hands under the seat or near the moving parts to avoid
injury.
Fingers or hands may become jammed in the seat mechanism.
■ After returning the rear seat back to the upright position
Observe the following precautions. Failure to do so may result in death or
serious injury.
● Make sure the seatback is securely locked by pushing it forward and rear-
ward on the top.
● Check that the seat belts are not twisted or caught in the seatback.
NOTICE
■Stowing the seat belts
The seat belts and the buckles must be stowed before you fold down the
rear seatbacks.

1333-3. Adjusting the seats
3
Operation of each component
4RUNNER (U)_(OM35B18U)
■To stop the position recall operation part-way through
Perform any of the following:
●Press the “SET” button.
● Press button “1” or “2”.
● Operate any of the seat adjustment switches (only cancels seat position
recall).
■ Seat positions that can be memorized ( P. 119)
All adjusted positions can be recorded.
■ Operating the driving position memory after turning the engine switch
off
Recorded seat positions can be activated up to 180 seconds after the driver’s
door is opened and another 60 seconds after it is closed again.
■ In order to correctly use the dr iving position memory function
If a seat position is already in the furthest possible position and the seat is
operated in the same direction, the recorded position may be slightly different
when it is recalled.
Each electronic key can be registered to recall your preferred driving
position.
■Registering procedure
Record your driving position to button “1” or “2” before performing
the following:
Carry only the key you want to re gister, and then close the driver’s
door.
If 2 or more keys are in the vehicle, the driving position cannot be
recorded properly.
Check that the shift lever is in P.
Turn the engine switch to IGNITION ON mode.
Recall the driving position that you want to record.
Memory recall function
1
2
3

1353-3. Adjusting the seats
3
Operation of each component
4RUNNER (U)_(OM35B18U)
CAUTION
■Seat adjustment caution
Take care during seat adjustment so that the seat does not strike the rear
passenger or squeeze your body against the steering wheel.

1363-3. Adjusting the seats
4RUNNER (U)_(OM35B18U)
Vertical adjustmentUp
Pull the head restraints up.
Down
Push the head restraint down while
pressing the lock release button.
Vertical adjustmentUp
Pull the head restraints up.
Down
Push the head restraint down while
pressing the lock release button.
Folding the head restraints (vehi-
cle without third row seats)To u s e
Lift up the head restraint until it
locks.
To f o l d
Pull the head restraint lock release
lever to fold the head restraint.
Head restraints
Head restraints are provided for all seats.
Front seats
Lock release button
1
2
Second seats
Lock release button
1
2
1
2

514Alphabetical index
4RUNNER (U)_(OM35B18U)
Flat tire...................................... 428
Floor mats .................................. 26
FluidAutomatic transmission......... 463
Brake .................................... 463
Power steering ...................... 464
Washer ................................. 362
Fog lights ................................. 210 Replacing light bulbs............. 383
Switch ................................... 210
Wattage ................................ 465
Four-wheel drive system ............................ 231, 235
Front passenger occupant classification system .............. 46
Front personal lights ............... 294
Front seats ............................... 119
Adjustment ............................ 119
Cleaning................................ 336
Correct driving posture ........... 28
Driving position memory ....... 132
Head restraints ..................... 136
Seat heaters ......................... 291
Seat position memory ........... 132
Seat ventilators ..................... 291
Front side marker lights.......... 204
Light switch ........................... 204
Replacing light bulbs............. 390
Wattage ................................ 465 Front turn signal lights ........... 202
Replacing light bulbs ............ 388
Turn signal lever ................... 202
Wattage ................................ 465
Fuel ........................................... 218
Capacity................................ 458
Fuel gauge.............................. 81
Fuel pump shut off system ... 411
Information............................ 466
Refueling .............................. 218
Type.............................. 218, 458
Warning light......................... 414
Fuel filler door ......................... 218 Refueling .............................. 218
Fuel pump shut off system..... 411
Fuses ........................................ 380
Garage door opener ................ 320
Gauges ....................................... 81
Glove box ................................. 297
Grocery bag hooks.................. 306
F
G

518Alphabetical index
4RUNNER (U)_(OM35B18U)
Parking brake ........................... 203Operation .............................. 203
Parking brake engaged warning buzzer ................... 412
Parking lights ........................... 204 Light switch ........................... 204
Replacing light bulbs............. 388
Wattage ................................ 465
Pen holder ................................ 301
Personal lights ......................... 294
Power back window ................ 148 Jam protection function......... 150
Operation .............................. 148
Power outlets ................... 311, 316
Power steering Fluid ...................................... 358
Warning light ......................... 414
Power windows........................ 145 Door lock linked
window operation ............... 147
Jam protection function......... 146
Operation .............................. 145
Window lock switch............... 145 Radiator .................................... 355
Rear differential lock
system.................................... 243
Rear seats
Adjustment............................ 122
Folding down ........ 124, 126, 128
Rear step bumper .................... 115
Rear turn signal lights ............ 202
Replacing light bulbs ............ 394
Turn signal lever ................... 202
Wattage ................................ 465
Rear view mirror Inside rear view mirror .......... 141
Outside rear view mirrors ..... 143
Rear view monitor system
*
Rear window ............................ 148
Rear window defoggers....................... 280, 286
Rear window wiper .................. 215
Refueling .................................. 218
Capacity................................ 458
Fuel types ............................. 458
Opening the fuel tank cap..... 220
Replacing Fuses .................................... 380
Key battery ........................... 377
Light bulbs ............................ 383
Tires...................................... 428
Reporting safety defects
for U.S. owners...................... 490
Reset the maintenance data ... 340
Roof luggage carrier ............... 168
PR

519Alphabetical index
4RUNNER (U)_(OM35B18U)
Safety Connect ........................ 327
Seat belt reminder light........... 415
Seat belts.................................... 30Adjusting the seat belt ............ 30
Automatic Locking
Retractor (ALR) .................... 31
Child restra int system
installation ............................ 62
Cleaning and maintaining the seat belt ........................ 337
Emergency Locking Retractor (ELR) .................... 31
How to wear your seat belt ..... 30
How your child should wear
the seat belt .......................... 31
Pregnant women, proper
seat belt use ......................... 32
Reminder light and buzzer .... 415
Seat belt extender................... 31
Seat belt pretensioners ........... 31
SRS warning light ................. 413
Seat heaters ............................. 291
Seat position memory ............. 132
Seat ventilators ........................ 291
Seating capacity ...................... 173 Seats ................................. 119, 122
Adjustment.................... 119, 122
Adjustment
precautions................. 121, 131
Child seats/child restraint
system installation ................ 57
Cleaning ............................... 336
Driving position memory ....... 132
Head restraints ..................... 136
Properly sitting in the seat ...... 28
Seat heaters ......................... 291
Seat position memory ........... 132
Seat ventilators ..................... 291
Sensor
Automatic headlight system .......... ...................... 208
Inside rear view mirror .......... 142
Intuitive parking assist .......... 225
Service reminder indicators ..... 76
Shift lever ................................. 199 Automatic transmission ........ 199
If the shift lever cannot be shifted from P .... 443
Shift lock system ..................... 443
Side airbags ............................... 35
Side marker lights ................... 204 Light switch ........................... 204
Replacing light bulbs ............ 390
Wattage ................................ 465
S
*: Refer to the “NAVIGATION AND MULTIMEDIA SYSTEM OWNER’S MANUAL”.
