2015 TOYOTA 4RUNNER fold seats

1313-3. Adjusting the seats
3
Operation of each component
4RUNNER (U)_(OM35B18U)
CAUTION
■When folding the rear seatbacks down
Observe the following precautions. Failure to do so may result in death or
serious injury.
● Do not fold the seatbacks down while driving.
● Stop the vehicle on level ground, set the parking brake and shift the shift
lever to P.
● Do not allow anyone to sit on a folded seatback or in the luggage compart-
ment while driving.
● Do not allow children to enter the luggage compartment.
■ Seat adjustment
● To reduce the risk of sliding under the lap belt during a collision, do not
recline the seat more than necessary.
If the seat is too reclined, the lap belt may slide past the hips and apply
restraint forces directly to the abdomen, or your neck may contact the
shoulder belt, increasing the risk of death or serious injury in the event of
an accident.
Adjustments should not be made while driving as the seat may unexpect-
edly move and cause the driver to lose control of the vehicle.
● Take care when adjusting the seat position to ensure that other passen-
gers are not injured by the moving seat.
● Do not put your hands under the seat or near the moving parts to avoid
injury.
Fingers or hands may become jammed in the seat mechanism.
■ After returning the rear seat back to the upright position
Observe the following precautions. Failure to do so may result in death or
serious injury.
● Make sure the seatback is securely locked by pushing it forward and rear-
ward on the top.
● Check that the seat belts are not twisted or caught in the seatback.
NOTICE
■Stowing the seat belts
The seat belts and the buckles must be stowed before you fold down the
rear seatbacks.

1363-3. Adjusting the seats
4RUNNER (U)_(OM35B18U)
Vertical adjustmentUp
Pull the head restraints up.
Down
Push the head restraint down while
pressing the lock release button.
Vertical adjustmentUp
Pull the head restraints up.
Down
Push the head restraint down while
pressing the lock release button.
Folding the head restraints (vehi-
cle without third row seats)To u s e
Lift up the head restraint until it
locks.
To f o l d
Pull the head restraint lock release
lever to fold the head restraint.
Head restraints
Head restraints are provided for all seats.
Front seats
Lock release button
1
2
Second seats
Lock release button
1
2
1
2

1373-3. Adjusting the seats
3
Operation of each component
4RUNNER (U)_(OM35B18U)
To u s e
Lift up the head restraint until it
locks.
To f o l d
Pull the strap to fold the head
restraint.
■Removing the head restraints (except third row seats)
■ Installing the head restraints (except third row seats)
■ Adjusting the height of the head restraints (except third row seats)
■ Adjusting the second center seat head restraint
Always raise the head restraint one level from the stowed position when
using.
Third seats (vehicle with third row seats)
1
2
Pull the head restraint up while pressing
the lock release button.
Align the head restraint with the installa-
tion holes and push it down to the lock
position.
Press and hold the lock release button
when lowering the head restraint.
Make sure that the head restraints are
adjusted so that the center of the head
restraint is closest to the top of your ears.
Lock release button
Lock release
button

1714-1. Before driving
4
Driving
4RUNNER (U)_(OM35B18U)
■When using the roof rails (if equipped)
●To use the roof rails as a roof luggage
carrier, you must fit the roof rails with
two or more genuine Toyota cross rails
or their equivalent.
●When there is no luggage on the roof
luggage carrier Toyota recommends
that the front and rear cross rails be
secured in the positions indicated in
the illustration. This may reduce wind
noise while driving.
CAUTION
■Things that must not be carried in the luggage compartment
The following things may cause a fire if loaded in the luggage compart-
ment:
●Receptacles containing gasoline
●Aerosol cans
■Storage precautions
Observe the following precautions.
Failure to do so may prevent the pedals from being depressed properly,
may block the driver’s vision, or may result in items hitting the driver or
passengers, possibly causing an accident.
●Stow cargo and luggage in the luggage compartment whenever possi-
ble.
●Do not stack cargo and luggage in the luggage compartment higher
than the seatbacks.
●Do not place cargo or luggage in or on the following locations.
• At the feet of the driver
• On the front passenger or rear seats (when stacking items)
• On the instrument panel
• On the dashboard
●Secure all items in the occupant compartment.
●When you fold down the rear seats, long items should not be placed
directly behind the front seats.
●Never allow anyone to ride in the luggage compartment. It is not
designed for passengers. They should ride in their seats with their seat
belts properly fastened. Otherwise, they are much more likely to suffer
death or serious bodily injury, in the event of sudden braking, sudden
swerving or an accident.
Roof railsCross rails

3035-3. Using the storage features
5
Interior features
4RUNNER (U)_(OM35B18U)■
Cargo hooks
Vehicles with third seats
Fold down the third seats. ( P. 128)
Raise the hook to use.
The cargo hooks are provided
for securing loose items.
Vehicles without third seats
Raise the hook to use.
The cargo hooks are provided
for securing loose items.
Luggage compartment features
1
2

3045-3. Using the storage features
4RUNNER (U)_(OM35B18U)■
Cargo net hooks
The cargo net itself is not included as original equipment.
Vehicles with third seats (pattern 1)
Raise the rear cargo hook to
use.
Vehicles with third seats (pattern 2)
Fold down the third seats. ( P. 128)
Raise the cargo hook to use.
Vehicles without third seats (pattern 1)
Raise the rear cargo hook to
use.
1
2

518Alphabetical index
4RUNNER (U)_(OM35B18U)
Parking brake ........................... 203Operation .............................. 203
Parking brake engaged warning buzzer ................... 412
Parking lights ........................... 204 Light switch ........................... 204
Replacing light bulbs............. 388
Wattage ................................ 465
Pen holder ................................ 301
Personal lights ......................... 294
Power back window ................ 148 Jam protection function......... 150
Operation .............................. 148
Power outlets ................... 311, 316
Power steering Fluid ...................................... 358
Warning light ......................... 414
Power windows........................ 145 Door lock linked
window operation ............... 147
Jam protection function......... 146
Operation .............................. 145
Window lock switch............... 145 Radiator .................................... 355
Rear differential lock
system.................................... 243
Rear seats
Adjustment............................ 122
Folding down ........ 124, 126, 128
Rear step bumper .................... 115
Rear turn signal lights ............ 202
Replacing light bulbs ............ 394
Turn signal lever ................... 202
Wattage ................................ 465
Rear view mirror Inside rear view mirror .......... 141
Outside rear view mirrors ..... 143
Rear view monitor system
*
Rear window ............................ 148
Rear window defoggers....................... 280, 286
Rear window wiper .................. 215
Refueling .................................. 218
Capacity................................ 458
Fuel types ............................. 458
Opening the fuel tank cap..... 220
Replacing Fuses .................................... 380
Key battery ........................... 377
Light bulbs ............................ 383
Tires...................................... 428
Reporting safety defects
for U.S. owners...................... 490
Reset the maintenance data ... 340
Roof luggage carrier ............... 168
