“Electronic Vehicle Information Center (EVIC)” in ”Un-
derstanding Your Instrument Panel” for further informa-
tion. Tighten the gas cap until aclickingsound is heard.
This is an indication that the gas cap is properly tight-
ened.
Push the odometer reset button to turn the message off. If
the problem persists, the message will appear the next
time the vehicle is started. This might indicate a damaged
cap. If the problem is detected twice in a row, the system
will turn on the MIL. Resolving the problem will turn the
MIL light off.EMISSIONS INSPECTION AND MAINTENANCE
PROGRAMS
In some localities, it may be a legal requirement to pass
an inspection of your vehicle’s emissions control system.
Failure to pass could prevent vehicle registration.
For states that require an Inspection and Mainte-
nance (I/M), this check verifies the “Malfunction
Indicator Light (MIL)” is functioning and is not
on when the engine is running, and that the OBD II
system is ready for testing.
Normally, the OBD II system will be ready. The OBD II
system may notbe ready if your vehicle was recently
serviced, recently had a dead battery or a battery replace-
ment. If the OBD II system should be determined not
ready for the I/M test, your vehicle may fail the test.
7
MAINTAINING YOUR VEHICLE 331

Your vehicle has a simple ignition actuated test, which
you can use prior to going to the test station. To check if
your vehicle’s OBD II system is ready, you must do the
following:
1. Cycle the ignition switch to the ON position, but donot crank or start the engine.
NOTE: If you crank or start the engine, you will have to
start this test over.
2. As soon as you cycle the ignition switch to the ON position, you will see the Malfunction Indicator Light
(MIL) symbol come on as part of a normal bulb check.
3. Approximately 15 seconds later, one of two things will happen:
• The MIL will flash for about 10 seconds and then
return to being fully illuminated until you turn OFF the ignition or start the engine. This means that your
vehicle’s OBD II system is
not readyand you should
not proceed to the I/M station.
• The MIL will not flash at all and will remain fully
illuminated until you place the ignition in the off
position or start the engine. This means that your
vehicle’s OBD II system is readyand you can proceed
to the I/M station.
If your OBD II system is not ready,you should see your
authorized dealer or repair facility. If your vehicle was
recently serviced or had a battery failure or replacement,
you may need to do nothing more than drive your
vehicle as you normally would in order for your OBD II
system to update. A recheck with the above test routine
may then indicate that the system is now ready.
Regardless of whether your vehicle’s OBD II system is
ready or not, if the MIL is illuminated during normal
vehicle operation you should have your vehicle serviced
332 MAINTAINING YOUR VEHICLE

MAINTENANCE SCHEDULE
Your vehicle is equipped with an automatic oil change
indicator system. The oil change indicator system will
remind you that it is time to take your vehicle in for
scheduled maintenance.
Based on engine operation conditions, the oil change
indicator message will illuminate in the instrument clus-
ter. This means that service is required for your vehicle.
Operating conditions such as frequent short-trips, trailer
tow, and extremely hot or cold ambient temperatures will
influence when the “Oil Change Required” message is
displayed. Severe Operating Conditions can cause the
change oil message to illuminate as early as 3,500 miles
(5,600 km) since last reset. Have your vehicle serviced as
soon as possible, within the next 500 miles (805 km).
Your authorized dealer will reset the oil change indicator
message after completing the scheduled oil change. If a
scheduled oil change is performed by someone otherthan your authorized dealer, the message can be reset by
referring to the steps described under “Electronic Vehicle
Information Center (EVIC)” in “Understanding Your
Instrument Panel” for further information.
NOTE:
Under no circumstances should oil change inter-
vals exceed 10,000 miles (16,000 km) or twelve months,
whichever comes first.
Severe Duty All Models
Change Engine Oil at 4,000 miles (6,500 km) if the vehicle
is operated in a dusty and off road environment. This
type of vehicle use is considered Severe Duty.
Once A Month Or Before A Long Trip:
• Check engine oil level
• Check windshield washer fluid level
• Check the tire inflation pressures and look for unusual
wear or damage
388 MAINTENANCE SCHEDULES

Carbon Monoxide Warning...................64
Cargo Light ..............................96
Car Washes ............................ .356
Cellular Phone .......................... .182
Certification Label ........................ .269
Chains, Tire ............................ .254
Chart, Tire Sizing ........................ .232
Check Engine Light (Malfunction Indicator Light) ............128, 331
Checking Your Vehicle For Safety ...............63
Checks, Safety ............................63
Child Restraint ............................52
Child Restraints Booster Seats ...........................57
Child Restraints .........................52
Infants And Child Restraints ................55
Older Children And Child Restraints ..........55
Cigar Lighter ............................118
Clean Air Gasoline ........................262 Climate Control
..........................183
Manual ............................. .183
Cold Weather Operation ....................201
Compact Disc (CD) Maintenance ..............182
Compact Spare Tire ........................249
Console, Overhead ........................114
Contract, Service ..........................399
Coolant Pressure Cap (Radiator Cap) ...........349
Cooling System .......................... .346
Adding Coolant (Antifreeze) ...............348
Coolant Capacity .......................382
Coolant Level ..................... .346, 350
Disposal Of Used Coolant .................350
Drain, Flush, And Refill ...................346
Inspection ............................350
Points To Remember .....................350
Pressure Cap ..........................349
Radiator Cap ..........................349
Selection Of Coolant (Antifreeze) ......347, 382, 383
408 INDEX

Exterior...............................67
Fog ................................ .128
Hazard Warning Flasher ..................287
Headlights .............................92
High Beam ........................ .94, 128
High Beam Indicator .....................128
Illuminated Entry ........................16
Instrument Cluster ..................... .128
Low Fuel ............................ .128
Map Reading ........................95, 114
Oil Pressure .......................... .128
Park .................................94
Passing ...............................94
Seat Belt Reminder ..................... .128
Service ...............................378
Tire Pressure Monitoring (TPMS) ............128
Traction Control ........................226
Turn Signal ..........................67, 91
Warning (Instrument Cluster Description) ......128Loading Vehicle
.......................269, 271
Capacities ............................271
Tires ............................... .237
Locks Automatic Door .........................22
Door .................................20
Lubrication, Body ........................ .344
Lug Nuts ...............................288
Maintenance Free Battery ....................340
Maintenance, General ..................... .128
Maintenance Procedures ....................333
Maintenance Schedule ..................... .388
Malfunction Indicator Light (Check Engine) .......331
Manual, Service ..........................401
Map/Reading Lights ....................95, 114
Methanol ...............................263
Mirrors .................................72
Electric Remote .........................73
414 INDEX

Heated...............................85
Security Alarm ............................15
Selection Of Coolant (Antifreeze) ..............383
SENTRY KEY® FCC General Information ..................14
Sentry Key (Immobilizer) ....................13
Service Assistance ........................ .397
Service Contract ..........................399
Service Manuals ..........................401
Service Reminder Indicator ..................128
Shift Lever Override .......................324
Shoulder Belts ............................27
Signals, Turn ..........................67, 128
Snow Chains (Tire Chains) ...................254
Snow Tires ............................. .247
Spare Tire .......................... .249, 250
Spark Plugs ............................ .383
Speed Control (Cruise Control) ................101
Speedometer ............................ .128Starting
............................... .200
Automatic Transmission ..................200
Cold Weather ..........................201
Engine Fails To Start .....................201
Steering Column Lock ..........................100
Power ............................217, 218
Steering Wheel Audio Controls ...............181
Steering Wheel Mounted Sound System Controls . . .181
Storage ............................... .375
Storage, Vehicle .......................... .375
Storing Your Vehicle .......................375
Supplemental Restraint System - Air Bag .........38
Sway Control, Trailer .......................227
Synthetic Engine Oil .......................336
Tachometer ............................. .128
Telescoping Steering Column .................100
Tire And Loading Information Placard .......237, 238
418 INDEX

Tire Markings............................230
Tires............................ .67, 242, 403
Aging (Life Of Tires) .....................252
Air Pressure .......................... .242
Chains ...............................254
Compact Spare ........................ .249
General Information .....................242
High Speed .......................... .245
Inflation Pressures .......................243
Life Of Tires .......................... .252
Load Capacity ..................... .237, 239
Pressure Monitor System (TPMS) ............257
Pressure Warning Light ...................128
Quality Grading ........................403
Radial ...............................245
Replacement .......................... .253
Rotation ............................. .256
Safety ............................230, 242
Sizes ............................... .232Snow Tires
............................247
Spinning ............................ .250
Trailer Towing ........................ .278
Tread Wear Indicators ....................251
Tire Safety Information .....................230
Tire Service Kit .......................... .290
Tongue Weight/Trailer Weight ................275
Torque Converter Clutch ....................213
Towing ............................ .271, 324
Disabled Vehicle ........................324
Guide ...............................275
Recreational .......................... .283
Weight ...............................275
Towing Vehicle Behind A Motorhome ...........283
Traction ............................... .214
Traction Control ..........................222
T raction

Control Switch .....................222
Trailer Sway Control (TSC) ..................227
Trailer Towing .......................... .27110
INDEX 419

Cooling System Tips.....................282
Hitches ............................. .274
Minimum Requirements ..................276
Tips................................ .282
Trailer And Tongue Weight ................275
Wiring ...............................280
Trailer Towing Guide .......................275
Trailer Weight ............................275
Transaxle Automatic .............................11
Transmission Automatic ............................202
Fluid ............................ .353, 385
Transmitter Battery Service (Remote Keyless Entry) . .18
Transporting Pets ..........................61
Tread Wear Indicators ..................... .251
Trip Odometer .......................... .128
Turn Signals ............................ .128Uniform Tire Quality Grades
.................403
Unleaded Gasoline ........................262
Untwisting Procedure, Seat Belt ................31
Upholstery Care ..........................358
Vehicle Certification Label ...................269
Vehicle Identification Number (VIN) .............6
Vehicle Loading ....................239, 269, 271
Vehicle Modifications/Alterations ...............7
Vehicle Storage .......................... .375
Viscosity, Engine Oil .......................336
Warning Lights (Instrument Cluster Description) . . .128
Warnings And Cautions ......................6
Warranty Information ..................... .400
Washer Adding Fluid ..........................345
Washing Vehicle ..........................356
Water
420 INDEX
