Page 386 of 671

(if equipped) and the VES™ mode is selected and the
disc is stopped, push the SETUP button to access the
Blu-ray™ Setup menu.
7. – Push and release to jump to the next available
audio track or video chapter. Push and hold to fast
forward through the current audio track or video
chapter.
8. /(Play/Pause) – Begin/resume or pause disc play.
9. Four Colored Buttons – Push to access Blu-ray™ Disc features.
10. POPUP/MENU – Push to access the Blu-ray™ main menu when in Blu-ray™ or DVD mode. Push to start
Scan or start Random track functions in CD or HDD
modes.
11. KEYPAD – Push to navigate chapters or titles.
12. ▪(Stop) – Stops disc play. 13.
– Push and release to jump to the previous audio
track or video chapter. Push and hold to fast rewind
through the current audio track or video chapter.
14.
– Mutes headphone audio.
15. BACK – Push to exit out of menus or return to source selection screen.
16. – Push to navigate menus.
17. OK – Push to select the highlighted option in a menu.
18. – Push to navigate menus.
19. – Push to navigate menus.
Remote Control Storage
The video screen(s) come with a built in storage compart-
ment for the remote control which is accessible when the
screen is opened. To remove the remote, use your index
finger to pull and rotate the remote towards you. Do not
384 UNDERSTANDING YOUR INSTRUMENT PANEL
Page 399 of 671

•Maximum frame rate for progressive source 30
frames per second
• Maximum field rate for interlaced source 60 fields
per second
• To change the current chapter, use the remote control’s
or Blu-Ray™ Player ’s “Fast Forward” button to ad-
vance to the next chapter, or the “Fast Rewind” button
to return to the start of the current or previous chapter.
DVD/Blu-ray™/BD Region Codes
The DVD player/Blu-ray™ Player and many DVD/Blu-
ray™ Discs are coded by geographic region. These region
codes must match in order for the disc to play. If the
region code for the DVD/Blu-ray™ Disc does not match
the region code for the player, the disc will stop playing
and a warning will be displayed. DVD Audio Support
When a DVD-Audio disc is inserted in the DVD player,
the DVD-Audio title on the disc is played by default
(most DVD-Audio discs also have a Video title, but the
Video title is ignored). All multi - channel program
material is automatically mixed down to two channels,
which may result in a lowered apparent volume level. If
you increase the volume level to account for this change
in level, remember to lower the volume before changing
the disc or to another mode.
Recorded Discs
The DVD player will play CD-R and CD-RW discs
recorded in CD-Audio or Video-CD format, or as a
CD-ROM containing MP3, WMA or AAC (Blu-ray™ Disc
Player only) files. The player will also play DVD-Video
content recorded to a DVD-R or DVD-RW disc. DVD-
ROM discs (either pressed or recorded) are not sup-
ported.
4
UNDERSTANDING YOUR INSTRUMENT PANEL 397
Page 402 of 671

•To change the current directory, use the remote con-
trol’s PROG UP and Down buttons or Rewind/skip
back and fast fwd/skip forward.
Disc Errors
If the DVD player is unable to read the disc, a Disc Error
message is displayed on the Radio display and the disc is
automatically ejected. A dirty, damaged, or incompatible
disc format are all potential causes for a Disc Error
message.
If a disc has a damaged track which results in audible or
visible errors that persists for 2.0 seconds, the DVD
player will attempt to continue playing the disc by
skipping forward 1.0 to 3.0 seconds at a time. If the end
of the disc is reached, the DVD player will return to the
beginning of the disc and attempt to play the start of the
first track. The DVD player may shut down during extremely hot
conditions, such as when the vehicle’s interior tempera-
ture is above 120° F (49° C). The Blu-ray™ Player may
shut down when the vehicle’s interior temperature ex-
ceeds 140° F (60° C). When this occurs, the DVD/Blu-
ray™ Player will display
High Tempand will shut off
the display until a safe temperature is reached. This
shutdown is necessary to protect the optics of the DVD/
Blu-ray™ Player.
The Blu-ray™ player may require additional reading
time during extremely cold weather conditions. When
this occurs, allow the vehicles interior temperature to
warm, then insert disc into player.
400 UNDERSTANDING YOUR INSTRUMENT PANEL
Page 654 of 671

DipsticksAutomatic Transmission ..................601
Oil (Engine) .......................... .580
Power Steering ........................ .459
Disabled Vehicle Towing ....................569
Disposal Antifreeze (Engine Coolant) ................596
Door Locks Door Locks ............................35
KeyFob...............................35
Remote ...............................35
Remote Keyless Entry (RKE) ................35
Door Opener, Garage ...................... .232
Driving Through Flowing, Rising, or Shallow Standing
Water ............................... .456
Driving to Achieve Maximum Fuel Economy ......314
DVD Player (Video Entertainment System™) ......362E-85 Fuel
.............................. .516
Economy (Fuel) Mode ..................... .445
Electrical Power Outlets .....................244
Electric Remote Mirrors .....................119
Electronic Brake Control System ...............463
Brake Assist System .....................466
Electronic Speed Control (Cruise Control) ........212
Electronic Stability Control (ESC) ..............467
Electronic Vehicle Information Center (EVIC) ......303
Emergency, In Case of Hazard Warning Flasher ..................540
Jacking .............................. .543
Jump Starting ......................... .562
Overheating .......................... .540
Emission Control System Maintenance ..........577
Engine Air Cleaner .......................... .583
Block Heater ......................... .442
Break-In Recommendations ................105
652 INDEX
Page 663 of 671

Reformulated Gasoline.....................512
Refrigerant ............................. .588
Reminder, Seat Belt .........................63
Remote Keyless Entry (RKE) ..................20
FCC General Information ..................30
Programming Additional Key Fobs ...........17
Programming Additional Transmitters .........17
Remote Sound System (Radio) Controls .........409
Remote Starting System ......................30
Removable Floor Console ...................265
Replacement Bulbs ....................... .618
Replacement Keys .........................16
Replacement Parts ........................ .579
Replacement Tires ........................ .498
Reporting Safety Defects ....................643
Resetting Oil Change Indicator ................289
Restraint, Head .......................... .170
Restraints, Child ...........................94
Rocking Vehicle When Stuck .................566Roof Rack (Luggage Rack)
...................272
Rotation, Tires .......................... .501
Safety Checks Inside Vehicle .................107
Safety Checks Outside Vehicle ................110
Safety Defects, Reporting ....................643
Safety, Exhaust Gas ....................... .106
Safety Information, Tire .....................475
Safety Tips ............................. .105
Satellite Radio Antenna .....................352
Schedule, Maintenance .....................630
Seat Belt Disengage The Automatic Locking Mode .......73
Energy Management Feature ................71
Engage The Automatic Locking Mode .........73
Lap/Shoulder Belt Operation ................67
Lap/Shoulder Belts .......................64
Lap/Shoulder Belt Untwisting ...............69
Pregnant Women ........................70
10
INDEX 661
Page 665 of 671

Sliding Door.............................49
Snow Chains (Tire Chains) ...................500
Snow Tires ............................. .492
Spare Tire .............................. .494
Spark Plugs ............................ .625
Speed Control (Cruise Control) ................212
Starting ............................... .439
Automatic Transmission ..................439
Cold Weather ......................... .440
Engine Fails to Start .....................440
Remote ...............................30
Starting and Operating .....................439
Starting Procedures ....................... .439
Steering Power .............................. .458
Tilt Column .......................... .208
Wheel, Heated ........................ .209
Wheel, Tilt ........................... .208
Steering Wheel Audio Controls ...............409Steering Wheel Mounted Sound System Controls . . .409
Storage
............................... .617
Storage Bin ............................. .254
Storage, Vehicle .......................... .431
Storing Your Vehicle ...................... .617
Stow n Go (Fold in Floor) Seats ...............174
Sunglasses Storage ....................... .229
Sun Roof .............................. .241
Sway Control, Trailer ...................... .471
Synthetic Engine Oil ...................... .583
System, Remote Starting .....................30
Tachometer ............................. .289
Telescoping Steering Column .................208
Temperature Control, Automatic (ATC) ..........420
Tilt Steering Column ...................... .208
Tire and Loading Information Placard ...........482
Tire Markings ........................... .475
T
ires ..................................110
10
INDEX 663
