Chassis56 | DynamicsChassisDynamics | 57
Life can’t be truly intense without some twists and turns.
Porsche Torque Vectoring Plus
(PTV Plus).
Sports car makers adore corners. With
our technologies, we are forever fanning
the flames of the relationship. PT V Plus
is an optional system for enhancing both
driving dynamics and stability.
Operating in conjunction with an
electronically regulated rear differential
lock, it works by varying the torque
distribution to the rear wheels. When the
car is driven into a corner, moderate
brake pressure is applied to the inside
rear wheel as the situation demands.
Consequently, a greater amount of drive
force is distributed to the outside rear
wheel, inducing an additional rotational
pulse (yaw movement) around the
vehicle’s vertical axis. The effect is a
direct and sport y steering action. And
considerable driving pleasure at every
t wist and turn. At low and medium vehicle speeds, PT V
Plus significantly increases agilit y and
steering precision. At high speeds on the
straight, and in fast corners where the
wheels threaten to spin, the electronically
controlled rear differential lock provides
added driving stability. Stability is also
improved on road surfaces with varying
grip as well as in the wet and snow.
Optional for all Macan models.
Sport Chrono Package.
The Sport Chrono Package adds a
stopwatch with an analogue and a digital
display to the cockpit. The performance
display in PCM lets you view a range of
driving stats, including your total driving
time, current lap distance and lap times
recorded so far. The lateral and
longitudinal forces acting on the vehicle
are illustrated by the G -Force graphic on
the colour screen in the instrument
c l u s t e r.The centre console also comes equipped
with the SPORT PLUS but ton, which is
used to activate SPORT PLUS mode. In
this mode, the engine becomes even
more responsive and the rev limiter is
adjusted to a harder set ting. Porsche
Traction Management (PTM) is now tuned
for even sportier performance. For cars
with Porsche Active Suspension
Management (PASM), SPORT PLUS mode
results in harder damping and more
direct steering. In addition, the trigger
threshold for PSM is raised for increased
longitudinal and lateral dynamics. The
shift times of PDK, fit ted as standard,
become even shorter, the gear changes
even sportier. The optional air suspension
automatically drops to Low Level. Launch
Control is primed to deliver optimum
acceleration from a standing start.

Optional for all Macan models.
Porsche Torque Vectoring Plus (PTV Plus)
Sport Chrono Package with per formance display in PCM

Safety64 | InstinctSafetyInstinct | 65
You aren’t usually so quick to brake.
Brakes.
At Porsche, we also set ourselves high
standards for braking performance. So it
goes without saying that our brake
systems are super-sized and adapted to
the high power output of the engine.
At the front, the Macan models are
equipped with six-piston aluminium
monobloc fixed brake calipers. The brake
discs are internally vented for consistently
high braking power, even during
continuous use.
To cope with the performance capabilit y
of the Macan models, the brake discs
fit ted to the front axle are up to 360 mm
in diameter. The brake calipers of the Macan S Diesel
and Macan S are silver- coloured. On the
Macan Turbo – red.
Porsche Ceramic Composite Brake
(PCCB).
As an option, you can have your Macan
equipped with the track-proven Porsche
Ceramic Composite Brake (PCCB).
The cross- drilled ceramic brake discs
have a diameter of 396 mm at the front
axle and a thickness of 38 mm. At the
rear, they are 370 mm in diameter and
30 mm thick.
Their low thermal expansion prevents
deformation under heavy braking.
Furthermore, the ceramic brake discs are
totally resistant to corrosion and offer more favourable noise-damping
properties.
The key advantage is that the brake
discs are approximately 50
% lighter than
standard discs of similar design and size.
Enhanced performance and fuel economy
are not the only noticeable benefits:
above all, it represents a major reduction
in unsprung and rotating masses. The
results are improved handling, bet ter
roadholding and increased ride comfort.
Optional for all Macan models.
Porsche Stability Management (PSM).
PSM is an electronic control system that
maintains stability – and increases
driving safet y – even at the limits of
sporty performance. Sensors continuously monitor driving
direction, speed, yaw velocit y and lateral
acceleration. PSM
actively intervenes to
stabilise the vehicle when necessary by
strategically applying the brakes at
individual wheels. That ’s not all. If the
driver suddenly releases the accelerator
pedal, PSM primes the brake system for
a higher state of readiness. Maximum
braking power is therefore achieved
much sooner. The integral anti-lock
braking system (ABS) is optimised for
short braking distances.
Standard in all Macan models.
Macan S/Macan S Diesel brake system
Porsche Ceramic Composite Brake (PCCB) on the Macan S
Macan Turbo brake system
Porsche Ceramic Composite Brake (PCCB)

Safety66 | InstinctSafetyInstinct | 67
Airbags.
All Macan models are equipped, as
standard, with full-size airbags for the
driver and front passenger. These are
supplemented by the Porsche Side
Impact Protection System (POSIP).
It comprises side airbags in the front
seats, curtain airbags along the entire
roof frame and the side windows from
the A-pillar to the C-pillar, and side
impact protection elements in the doors.
Side airbags are available as an option
for the rear compartment.
Two auxiliary sensors in the bumper help
to detect frontal collisions. A cluster of
acceleration and yaw rate sensors
detects a threat of rollover and triggers
the curtain airbags and seat belt
pretensioners.
Engineered body design.
The use of ultra- and super-high-strength
steels makes a crucial contribution to
safet y and, at the same time, purposefully
encapsulates the principle of lightweight
construction.
The forces exerted in the event of a
frontal impact are dispersed by a system
of longitudinal and transverse members.
Reinforcements in ultra-high-strength
steel provide additional protection for
occupants in the event of a side impact.
The concept also sees the use of
multiphase steels. High strength and
clearly defined deformability are two
qualities that they have in common. The
passenger cell is a cage formed of high-
tech steels and offers a considerable
level of protection.
Passive safety, bodyshell
Passive safet y, airbags
High-strength micro-alloyed steels
Multiphase steels
Deep-drawn steels
Boron-alloyed steels
Aluminium

Environment68 | Instinct
Efficiency.
The basic premise of any Porsche is
power. It ’s been that way ever since
1948. But there has always been another
principle: efficiency. Again, since 1948.
We remain commit ted to both, and we
always will.
In addition to our pursuit of efficient
engine technologies, such as the
turbochargers used across the model
range, we routinely rely on innovative,
lightweight materials, we are constantly
developing our production techniques
and functionalities and, as we do so, we
are continuously refining our concepts.
How does this benefit you as the driver?
Greater agilit y with increased dynamic
performance – and lower fuel
consumption. Now that’s efficiency.
Exhaust emissions.
The Macan once again demonstrates that
even high-performance sports cars can
achieve comparatively moderate
emission values. The state-of-the-art
engines of the Macan model range reach
their optimum operating temperature
soon after start-up, thanks to the rapid
heating of the catalytic converter
system. Emissions are thereby reduced,
while t yres optimised for low rolling
resistance play their part by lowering fuel
consumption. All models in the Macan
range fulfil the Euro 6 emission standard.
The petrol models are equipped with
stereo Lambda control circuits. These
are used by the electronic engine
management system to determine the
optimum amount of fuel for effective
emission control.

Living for today, in the here and now.
But always caring about tomorrow.

Environment.
Emission control in the Macan S Diesel is
realised by the interaction of a diesel
particulate filter and the SCR system.
AdBlue
® technology helps to achieve a
significant reduction in nitrogen oxide
emissions.
Fuel and fuel consumption.
Doing more with comparatively less –
another philosophy that the Macan
models live and breathe. The petrol
models are designed to operate on fuels
with an ethanol content of up to 10%.
Ethanol has a positive impact on the CO
2
balance because this biofuel is
manufactured from plants, which absorb
CO
2 from the atmosphere in order to
grow.
For fuel consumption, CO
2 emissions and efficiency class, please refer to pages 126–127.

Environment70 | Instinct
Fuel system.
In the petrol models, even the emissions
of the fuel system itself are minimised
for the protection of the environment.
Evaporative emissions are significantly
reduced by the returnless supply system.
Vapour-carrying lines are made from
multi-layered plastic, while a high- capacit y
active carbon filter and the fuel tank also
feature a multi-layered construction in
order to make every thing as impermeable
as possible.
Noise reduction.
The characteristic Porsche sound may
drive our passion, but acoustics is yet
another area in which we continuously
strive for optimisation.
Stiff components and light weight,
temperature-stable materials minimise
play bet ween parts and therefore
mechanical noise. Voluminous silencers
and air induction systems reduce noise
levels further – and that ’s over the
course of the entire service life. In collaboration with t yre manufacturers,
we are managing to reduce the rolling
noise of t yres, while aerodynamic
refinements keep wind noise as low as
possible. What ’s left? The Porsche sound,
pure and simple.
Servicing.
Long-life and hard-wearing materials
reduce maintenance items to a minimum.
At the time of an oil filter change, for
example, only the recycling-friendly
paper insert needs to be exchanged and
not the entire housing.
Moving parts are adjusted automatically,
e.g. by hydraulic valve clearance
compensation.
The use of individual ignition coils in
petrol engines makes the entire ignition
system, except for the spark plugs, wear-
and maintenance-free. Advantage for
you? If it doesn’t need replacing, it
doesn’t need to be disposed of. Not only
does this support the responsible
handling of resources and a caring
at titude towards the environment, it
saves you time and money.
The maintenance intervals of the Macan
models nevertheless depend on various
factors, including the local fuel grade.
For exact information, please refer to the
price list published in your country or
consult your Porsche Centre.
Materials and recycling.
A Porsche is a source of long-lasting
pleasure for our customers and a
refreshing change for their environment.
This Porsche principle can be summed
up in one word: sustainability.
Here’s just one example: the exhaust
system of the Macan models is made
from extremely corrosion-resistant
stainless steel – and purposefully
manufactured on the principles of
lightweight construction. In addition, our cars are free from CFCs and parts
manufactured with the use of CFCs. In
all, they are over 95
% recoverable.
Naturally, all statutory recycling
requirements are fulfilled. The labelling of
materials facilitates future sorting for
excellent recycling.
On the subject of recycling, there is
plent y of time before it is even needed.
Two -thirds of all Porsche cars ever built
are still being driven today. What bet ter
way to conserve resources?
For fuel consumption, CO
2 emissions and efficiency class, please refer to pages 126–127.

Comfort80 | MultitaskingComfortMultitasking | 81
Rear seats.
The rear bench seat has a three-way
split-folding ratio – and folds down fully if
required. The versatile centre seat
doubles as a through-loading facility for
long cargo items and for the optional ski
bag. It additionally contains the folding
armrest, which features t wo extra
cupholders when combined with the
optional storage package. Operation of
the rear bench seat is totally
straightforward: release, fold – done.
Child seats.
The Porsche Tequipment range of
aftermarket accessories features a
collection of specially designed Porsche
child seats. Engineered to meet strict
safet y standards, they have been tested
and approved specifically for Porsche
cars. As a result, they provide protection
and comfort to passengers up to 12
years of age. The fabrics are breathable,
hypoallergenic and easy to clean. The
cover is removable and washable.For increased safet y, Porsche Baby Seat
and Porsche Junior Seat ISOFIX1) have an
independent five-point belt system with
central belt length adjustment.
Porsche Junior Seat ISOFIX in rear compar tment Rear bench seat folded 2/3
Rear bench seat folded 1/3
Rear bench seat fully folded
In the midst of life
there is space for five.
1) ISOFIX is a secure and user-friendly child seat mounting system that rigidly at taches the child seat to the vehicle.

Comfort90 | MultitaskingComfortMultitasking | 91
A pounding beat.
Even when the engine’s switched off.
Burmester® High-End Surround Sound
System.
As a creator of sports cars, we love
to push boundaries – sound barriers
included. This is demonstrated perfectly
by the Burmester
® High-End Surround
Sound System, which has been optimally
tuned for the Macan model range. It
converts sound waves into a unique
feast for the senses – and music into
an exclusive listening experience.
The surround sound system developed
by Burmester
® – one of the most
respected manufacturers of high-end
audio equipment worldwide – is available
as an option.
The technologies behind the system
are from the finest premium home
audio systems that Burmester
® has
to offer. State of the art and never
heard before in a vehicle of this class.
The extravagance is uncompromising,
the craftsmanship exquisite, the sound phenomenal. The system owes its
excellence to countless details, and
one goal: perfection in sound.
The figures alone sound impressive:
16 amplifier channels with a total
output of more than 1,000 wat ts,
16 loudspeakers including an active
subwoofer with 300 -wat t class D
amplifier, a total diaphragm surface
area of more than 2,400 cm
2, and a
frequency response of 30 Hz to 20 kHz.
Crossover technology has been carried
over almost unmodified from Burmester
®
high-end home audio products. Analogue
and digital filters have been optimally
defined for their installation location and
finely tuned after extensive in-car audio
testing. Ribbon
t weeters have been used
for unmistakably
fine, clear and
undistorted high-frequency sound
reproduction with excellent level stability. The elegantly pure design with galvanised
surrounds and Burmester
® logos on
selected loudspeakers make it clear that
the exclusive appeal of the Burmester
®
High-End Surround Sound System is as
much about the visual as it is the audio.
Uncompromising luxury in sound and
st yle.
Optional for all Macan models.
Burmester® High-End Surround Sound System Optimised sound distribution in the Macan (figurative illustration)

Comfort94 | MultitaskingComfortMultitasking | 95
Comfort lighting package.
The comfort lighting package comprises
dimmable ambient lighting in the door
trims, LED lights in place of bulbs,
practical LED reading lights for the rear
passengers, t wo vanit y lights, additional
courtesy lighting in both exterior mirrors
and LED illumination of the foot wells.
Optional for all Macan models.
Roll-up sunblind.
To protect against sunlight, a mechanical
roll-up sunblind is optionally available for
the rear side windows.
Optional for all Macan models.
Rain sensor.
The windscreen wiper system has three
wiper speeds and a rain sensor for
automatic operation.
Standard in all Macan models.
Porsche Entry & Drive.
Porsche Entry & Drive is designed to
minimise key use.
As soon as you touch the door handle,
Porsche Entry & Drive checks the
encrypted access code on the key in
your pocket. Once the key is validated,
the door unlocks. The engine can then be
started and switched off using the
ignition key in the normal way.
To lock the vehicle, you simply touch the
sensor on the outside of the door handle.
Porsche Entry & Drive then locks the
vehicle and simultaneously activates the
engine immobiliser.
Optional for all Macan models.
Anti-theft protection.
All Macan models are equipped with an
engine immobiliser. It works in response
to an automatic exchange of data
bet ween the key and vehicle electronics.
On correct identification, the engine start
will be authorised by the engine
electronics.
Every Macan model is also protected by
an alarm system. On request, this can be
upgraded to include ultrasonic interior
surveillance. The security system
monitors all four doors, the bonnet, the
entire rear hatch, the interior, the ignition
and any trailer that you have hitched to
the car.
Rain sensor
Comfort lighting package
Roll-up sunblind
