2015 PORSCHE 911 CARRERA 4S technical data

Contents
Sports car fascination 6
Design 14
Principle 26
Drive 38
Chassis 54
Safety and environment 66
Comfor t 76
Personalisation 96
Technical data 146

Safety and environment 73
Would you like to see more?
Scan code or go to w w w.porsche.co.uk/ lighting and star t the video.
A rest yling of the Bi-Xenon main
headlights – fit ted as standard – sees
the four-spot LED day time running lights
now incorporated into each headlight
unit. These are an innovative technical
feature of the new 911
models – and
a facet of their personality. After all,
it is the characteristic lighting design
that makes the face of the 911
so
unmistakable.
Cut ting edge LED technology is also
used for all functions of the redesigned
taillights. As well as being a powerful
lighting source, LEDs offer a fast response
to driver input. The LED brake lights
emulate the four-spot appearance of the
daytime running lights.
Porsche Dynamic Light System (PDLS).
The Porsche Dynamic Light System (PDLS)
is available as an option. Its dynamic
cornering light function swivels the main
headlights towards the inside of a bend,
based on steering angle and road speed,
so as to light up more of the road at
bends and turns. Put simply, the road
ahead is illuminated the moment you
start to corner. PDLS also features
speed-sensitive headlight range control
and the adverse weather function.
LED main headlights including Porsche
Dynamic Light System Plus (PDLS Plus).
Superior safety meets sporty design in
the form of optional LED main headlights
including PDLS Plus. In addition to being
efficient and long-lasting, LED technology
also creates a light very similar to daylight
and thus helps to reduce driver fatigue.
One special feature of PDLS Plus is the
dynamic main beam function. A camera
detects the lights of vehicles ahead as
well as those of oncoming traffic. Based
on the data from the camera, the dynamic
main beam function then adapts the
Visionary?
That’s one view.
Lights.
headlight range accordingly. This
continuous, seamless control means
that you are able to see the course of
the road, pedestrians and potential
hazards earlier without hindering other
road users.

Technical data

146 Technical data
Technical data.
1) Weight is calculated in accordance with the relevant EC Directives and is valid for vehicles with standard specification only. Optional equipment increases this figure. The figure given includes 68 kg for the driver and 7 kg for luggage. 2) Data determined in accordance with the measurement method required by law (Regulation [EC] 715/2007 as amended). The figures do not refer to an individual vehicle nor do they constitute par t of the of fer. They are intended solely as
a means of comparing different types of vehicle. Fuel consumption calculated for vehicles with standard specification only. Actual consumption and performance may vary with items of optional equipment. A vehicle's fuel consumption
and CO
2 emissions depend not only on its ef ficient use of fuel but also on driving st yle and other non -technical factors. The latest Porsche models with petrol engine are designed to operate on fuels with an ethanol content of up to 10 %.
You can obtain fur ther information about individual vehicles from your Porsche Centre.
911 Carrera / 911 Carrera Cabriolet 911 Carrera S / 911 Carrera S Cabriolet
Engine
Cylinders 6 6
Displacement 2,981 cm32,981 cm3
Max. power (DIN)
at rpm272 kW (370 hp)
6,500 309 kW (420 hp)
6,500
Max. torque
at rpm 450 Nm
1,700–5,000 500 Nm
1,700–5,000
Compression ratio 10.0 : 1 10.0 : 1
Transmission
Layout Rear-wheel drive Rear-wheel drive
Manual transmission 7-speed 7-speed
PDK (optional) 7-speed 7-speed
Chassis
Front a xleMcPherson strut suspension McPherson strut suspension
Rear axle Multi-link suspension Multi-link suspension
Steering Variable steering ratio, power-assisted (electromechanical) Variable steering ratio, power-assisted (electromechanical)
Turning circle 11 . 2   m 11 . 2   m
Brakes Four-piston aluminium monobloc fixed calipers front and rear,
discs internally vented and cross-drilled Six-piston aluminium monobloc fixed brake calipers at front,

four-piston units at rear, discs internally vented and cross-drilled
Vehicle stability system Porsche Stability Management (PSM) Porsche Stability Management (PSM)
Standard wheels Front: 8.5 J x 19 (ET 50), Rear: 11.5 J x 19 (ET 76) Front: 8.5 J x 20 (ET 49), Rear: 11.5 J x 20 (ET 76)
Standard tyres Front: 235/40 ZR 19, Rear: 295/35 ZR 19 Front: 245/35 ZR 20, Rear: 305/30 ZR 20

Technical data 147
911 Carrera911 Carrera Cabriolet911 Carrera S911 Carrera S Cabriolet
Weights
M a n u a l / P D K M a n u a l / P D K M a n u a l / P D K M a n u a l / P D K
Unladen weight (DIN) 1,4 3 0 k g / 1,45 0 k g1,500 kg /1,520 kg1,440 kg / 1,460 kg1,510 kg / 1,530 kg
Unladen weight (EC)
1)1,505 kg /1,525 kg 1,575 kg /1,595 kg 1,515 kg / 1,535 kg1,585 kg / 1,605 kg
Permissible gross weight 1,875 kg / 1,890 kg1,925 k g / 1,9 4 0 k g1,900 kg / 1,915 kg1,950 kg / 1,965 kg
PerformanceM a n u a l / P D K M a n u a l / P D K M a n u a l / P D K M a n u a l / P D K
Top speed 183 mph /182 mph 181 m p h / 18 0 m p h 191 m p h / 19 0 m p h190 mph/189 mph
0–62 mph 4.6 secs/ 4.4 secs 4.8 secs/ 4.6 secs 4.3 secs/ 4.1 secs 4.5 secs / 4.3 secs
Spor t Chrono Package
(in conjunction with PDK)
0– 62 mph with Launch Control –
/ 4.2 secs – / 4.4 secs – / 3.9 secs – / 4.1 secs
0 –99 mph 9.8 secs / 9.5 secs10.2 secs/ 9.9 secs 8.9 secs / 8.5 secs 9.3 secs/ 8.9 secs
Spor t Chrono Package
(in conjunction with PDK)
0–99 mph with Launch Control –
/ 9.2 secs – / 9.6 secs – / 8.2 secs – / 8.6 secs
Flexibilit y (49 –74 mph), 5th gear 5.5 secs / – 5.8 secs/ – 4.8 secs/ – 5.1 secs / –
Over taking acceleration (49 –74 mph) – / 2.7 secs – / 2.8 secs – / 2.3 secs – / 2.4 secs
Fuel consumption/emissions2)M a n u a l / P D K M a n u a l / P D K M a n u a l / P D K M a n u a l / P D K
Urban in mpg 24.1/ 28.523.7/28.523.2/28.02 3 . 0 / 2 7. 7
Extra urban in mpg 4 4 . 8 / 4 7. 143.5/45.642. 8/4 4.142. 2 /4 3.5
Combined in mpg 34.0/38.23 3 . 2 / 3 7. 732.5/ 3 6.732.1/ 3 6.2
CO
2 emissions in g / km 19 0/ 16919 5 / 17 219 9/ 174202/178
Dimensions/aerodynamicsM a n u a l / P D K M a n u a l / P D K M a n u a l / P D K M a n u a l / P D K
Length 4,499 mm4,499 mm4,499 mm4,499 mm
Width (including exterior mirrors) 1,808 mm (1,978 mm)1,808 mm (1,978 mm)1,808 mm (1,978 mm)1,808 mm (1,978 mm)
Height 1,294 mm1,289 mm1,296 mm / 1,295 mm 1,291 mm /1,290 mm
Wheelbase 2,450 mm2,450 mm2,450 mm2,450 mm
Luggage compartment volume
(German Car Manufacturers’ Assoc.) 14 5 l i t r e s
14 5 l i t r e s14 5 l i t r e s14 5 l i t r e s
Tank capacity (refill volume) 64 litres (64 litres)64 litres (64 litres)64 litres (64 litres)64 litres (64 litres)
Drag coefficient 0.290.300.300.30

148 Technical data
Technical data.
1) Weight is calculated in accordance with the relevant EC Directives and is valid for vehicles with standard specification only. Optional equipment increases this figure. The figure given includes 68 kg for the driver and 7 kg for luggage. 2) Data determined in accordance with the measurement method required by law (Regulation [EC] 715/2007 as amended). The figures do not refer to an individual vehicle nor do they constitute par t of the of fer. They are intended solely as
a means of comparing different types of vehicle. Fuel consumption calculated for vehicles with standard specification only. Actual consumption and performance may vary with items of optional equipment. A vehicle's fuel consumption
and CO
2 emissions depend not only on its ef ficient use of fuel but also on driving st yle and other non -technical factors. The latest Porsche models with petrol engine are designed to operate on fuels with an ethanol content of up to 10 %.
You can obtain fur ther information about individual vehicles from your Porsche Centre.
911 Carrera 4 / 911 Carrera 4 Cabriolet 911 Carrera 4S / 911 Carrera 4S Cabriolet
Engine
Cylinders 6 6
Displacement 2,981 cm32,981 cm3
Max. power (DIN)
at rpm272 kW (370 hp)
6,500 309 kW (420 hp)
6,500
Max. torque
at rpm 450 Nm
1,700–5,000 500 Nm
1,700–5,000
Compression ratio 10.0 : 1 10.0 : 1
Transmission
Layout All-wheel drive All-wheel drive
Manual transmission 7-speed 7-speed
PDK (optional) 7-speed 7-speed
Chassis
Front a xleMcPherson strut suspension McPherson strut suspension
Rear axle Multi-link suspension Multi-link suspension
Steering Variable steering ratio, power-assisted (electromechanical) Variable steering ratio, power-assisted (electromechanical)
Turning circle 11 . 2   m 11 . 2   m
Brakes Four-piston aluminium monobloc fixed calipers front and rear,
discs internally vented and cross-drilled Six-piston aluminium monobloc fixed brake calipers at front,

four-piston units at rear, discs internally vented and cross-drilled
Vehicle stability system Porsche Stability Management (PSM) Porsche Stability Management (PSM)
Standard wheels Front: 8.5 J x 19 (ET 50), Rear: 11.5 J x 19 (ET 56) Front: 8.5 J x 20 (ET 49), Rear: 11.5 J x 20 (ET 56)
Standard tyres Front: 235/40 ZR 19, Rear: 295/35 ZR 19 Front: 245/35 ZR 20, Rear: 305/30 ZR 20

Technical data 149
911 Carrera 4911 Carrera 4 Cabriolet911 Carrera 4S911 Carrera 4S Cabriolet
Weights
M a n u a l / P D K M a n u a l / P D K M a n u a l / P D K M a n u a l / P D K
Unladen weight (DIN) 1,480 kg / 1,500 kg1,550 kg /1,570 kg1,490 kg / 1,510 kg1,560 kg / 1,580 kg
Unladen weight (EC)
1)1,555 kg / 1,575 kg 1,625 k g / 1,6 45 k g1,565 kg / 1,585 kg1,635 kg / 1,655 kg
Permissible gross weight 1,925 kg / 1,940 kg1,975 k g / 1,9 9 0 k g1,950 kg / 1,965 kg2,000 kg / 2,015 kg
PerformanceM a n u a l / P D K M a n u a l / P D K M a n u a l / P D K M a n u a l / P D K
Top speed 181 m p h / 18 0 m p h17 9 m p h / 17 8 m p h189 m p h / 18 8 m p h18 8 m p h / 187 m p h
0–62 mph 4.5 secs / 4.3 secs4.7 secs / 4.5 secs4.2 secs / 4.0 secs4.4 secs / 4.2 secs
Spor t Chrono Package
(in conjunction with PDK)
0–62 mph with Launch Control –
/ 4.1 secs – / 4.3 secs – / 3.8 secs – / 4.0 secs
0 –99 mph 9.7 secs / 9.3 secs10.1 secs / 9.7 secs8.7 secs / 8.3 secs9.1 secs / 8.7 secs
Spor t Chrono Package
(in conjunction with PDK)
0–99 mph with Launch Control –
/ 9.0 secs – / 9.4 secs – / 8.0 secs – / 8.4 secs
Flexibilit y (49 –74 mph), 5th gear 5.6 secs / – 5.9 secs / – 4.9 secs / – 5.2 secs / –
Over taking acceleration (49 –74 mph) – / 2.8 secs – / 2.9 secs – / 2.4 secs – / 2.5 secs
Fuel consumption/emissions2)M a n u a l / P D K M a n u a l / P D K M a n u a l / P D K M a n u a l / P D K
Urban in mpg 23.2/28.022.8/27.422.8/27.422.4/27.2
Extra urban in mpg 42. 2 /4 4. 84 0.9/4 3.541. 5/4 2. 841. 5/4 2. 2
Combined in mpg 32.5/ 3 6.73 1 . 7/ 3 5 . 83 1 . 7/ 3 5 . 831.4/35.3
CO
2 emissions in g / km 2 01 / 17 720 6/ 18220 4/ 18 020 8/ 18 4
Dimensions/aerodynamicsM a n u a l / P D K M a n u a l / P D K M a n u a l / P D K M a n u a l / P D K
Length 4,499 mm4,499 mm4,499 mm4,499 mm
Width (including exterior mirrors) 1,852 mm (1,978 mm)1,852 mm (1,978 mm)1,852 mm (1,978 mm)1,852 mm (1,978 mm)
Height 1,295 mm1,290 mm1.298  m m1,293 mm /1,292 mm
Wheelbase 2,450 mm2,450 mm2,450 mm2,450 mm
Luggage compartment volume
(German Car Manufacturers’ Assoc.) 125 l i t re s
125 l i t re s125 l i t re s125 l i t re s
Tank capacity (refill volume) 68 litres (67 litres)68 litres (67 litres)68 litres (67 litres)68 litres (67 litres)
Drag coefficient 0.290.300.300.30

150 Technical data
Technical data.911 Ta r g a 4 911 Targa 4S
Engine
Cylinders 6 6
Displacement 2,981 cm32,981 cm3
Max. power (DIN)
at rpm272 kW (370 hp)
6,500 309 kW (420 hp)
6,500
Max. torque
at rpm 450 Nm
1,700–5,000 500 Nm
1,700–5,000
Compression ratio 10.0 : 1 10.0 : 1
Transmission
Layout All-wheel drive All-wheel drive
Manual transmission 7-speed 7-speed
PDK (optional) 7-speed 7-speed
Chassis
Front a xleMcPherson strut suspension McPherson strut suspension
Rear axle Multi-link suspension Multi-link suspension
Steering Variable steering ratio, power-assisted (electromechanical) Variable steering ratio, power-assisted (electromechanical)
Turning circle 11 . 2   m 11 . 2   m
Brakes Four-piston aluminium monobloc fixed calipers front and rear,
discs internally vented and cross-drilled Six-piston aluminium monobloc fixed brake calipers at front,

four-piston units at rear, discs internally vented and cross-drilled
Vehicle stability system Porsche Stability Management (PSM) Porsche Stability Management (PSM)
Standard wheels Front: 8.5 J x 19 (ET 50), Rear: 11.5 J x 19 (ET 56) Front: 8.5 J x 20 (ET 49), Rear: 11.5 J x 20 (ET 56)
Standard tyres Front: 235/40 ZR 19, Rear: 295/35 ZR 19 Front: 245/35 ZR 20, Rear: 305/30 ZR 20
1) Weight is calculated in accordance with the relevant EC Directives and is valid for vehicles with standard specification only. Optional equipment increases this figure. The figure given includes 68 kg for the driver and 7 kg for luggage. 2) Data determined in accordance with the measurement method required by law (Regulation [EC] 715/2007 as amended). The figures do not refer to an individual vehicle nor do they constitute par t of the of fer. They are intended solely as
a means of comparing different types of vehicle. Fuel consumption calculated for vehicles with standard specification only. Actual consumption and performance may vary with items of optional equipment. A vehicle's fuel consumption
and CO
2 emissions depend not only on its ef ficient use of fuel but also on driving st yle and other non -technical factors. The latest Porsche models with petrol engine are designed to operate on fuels with an ethanol content of up to 10 %.
You can obtain fur ther information about individual vehicles from your Porsche Centre.
