2015 PEUGEOT 5008 change wheel

13
Limit the causes of excess consumption
Spread loads throughout the vehicle; place the heaviest items in the
bottom of the boot, as close as possible to the rear seats.
Limit the loads carried in the vehicle and reduce wind resistance (roof
bars, roof rack, bicycle carrier, trailer...). Use a roof box in preference.
Remove roof bars and roof racks after use.
At the end of winter, remove snow tyres and refit your summer tyres.
Observe the recommendations on
maintenance
Check the tyre pressures regularly, when cold, referring to the label in
the door aperture, driver's side.
Carry out this check in particular:
-
b
efore a long journey,
-

a
t each change of season,
-

a
fter a long period out of use.
Don't forget the spare wheel and the tyres on any trailer or caravan.
Have your vehicle serviced regularly (engine oil, oil filter, air filter,
passenger compartment filter...) and observe the schedule of
operations recommended in the manufacturer's service schedule.
With a BlueHDi Diesel engine, if the SCR system is faulty your vehicle
becomes polluting; go to a PEUGEOT dealer or a qualified workshop
without delay to have the emissions of nitrous oxides brought back to
the legal level.
When refuelling, do not continue after the third cut-off of the nozzle to
avoid any over flow.
At the wheel of your new vehicle, it is only after the first 1 800 miles
(3
000 kilometres) that you will see the fuel consumption settle down to
a consistent average.
.
Eco-driving

138
Deactivation
In exceptional conditions (starting a vehicle
which is bogged down, stuck in snow, on soft
ground...), it may be advisable to deactivate
the DSC and ASR, so that the wheels can turn
freely and regain grip.
Reactivate the systems as soon as the level of
grip permits.
F
P
ress this button.
The indicator lamp in the button comes on.
The DSC and ASR systems no longer act
on the operation of the engine and on the
brakes in the event of a involuntary change of
trajectory.
Reactivation
The systems are reactivated automatically each
time the ignition is switched back on or from
30
mph (50 km/h).
Below 30 mph (50 km/h), you can reactivate
them manually:
Operating fault
Illumination of this warning lamp
and the lamp in the deactivation
button, accompanied by an audible
signal and a message, indicate a
fault with the system.
Contact a PEUGEOT dealer or a qualified
workshop to have the system checked. F

P

ress this button again.
The indicator lamp in the button goes off.
DSC/ASR
The DSC and ASR systems offer
increased safety in normal driving, but
they should not encourage the driver to
take extra risks or drive at high speed.
It is in conditions of reduced grip (rain,
snow, black ice) that the risk of loss of
grip increases. It is therefore important
for your safety to keep the DSC and
ASR systems activated in all conditions,
and particularly in difficult conditions.
The correct operation of these
systems depends on observation of
the manufacturer's recommendations
regarding as much the wheels (tyres
and rims), braking and electronic
components as the assembly and repair
procedures used by PEUGEOT dealers.
To benefit in full from the effectiveness
of the DSC and ASR systems in wintry
conditions, the vehicle must be fitted
with four snow tyres, allowing the the
vehicle to retain neutral handling on the
road.
After an impact, have these systems
checked by a PEUGEOT dealer or a
qualified workshop.
Safety

171
Steering mounted controls
+. Change up paddle to the right of the steering wheel.
F

P
ress the back of the "+" steering mounted
paddle to change up a gear.
-.
C

hange down paddle to the left of the
steering wheel.
F

P
ress the back of the "-" steering mounted
paddle to change down a gear.
The steering mounted paddles cannot
be used to select neutral or engage or
disengage reverse gear.
Displays in the instrument panel
Gear lever positions
When you move the lever, the symbol
corresponding to its position is displayed
in the instrument panel.
N. Neutral
R. Reverse
1, 2, 3, 4, 5, 6. Gears in sequential mode
AUTO.

T
his comes on when the automatic
mode is selected. It goes off on
changing to sequential mode.
S. Sport (Sport setting)
F

P
lace your foot on the brake
when this warning lamp flashes
(e.g.: when starting the engine).
Moving off
F Select position N .
F P ress the brake pedal down fully.
F

S
tart the engine.
F

K
eep your foot on the brake pedal, move
the gear lever to position A or M to go
for wards, or R to go backwards.
F

T
ake your foot off the brake pedal, you can
then move off.
F

T
he parking brake is released
automatically, otherwise release it
manually.
There is an audible signal when reverse
gear is engaged. If the engine does not start:
-
If N is flashing in the instrument
panel, move the lever to position A
then to position N .
-

I
f the message " Foot on brake" is
displayed, press the brake pedal
f i r m l y.
8
Driving

226
Removing a wheel
F Depending on equipment, clip the tool 4 to the finisher cap on each wheel bolt with
alloy wheels to remove them.
F

D
epending on equipment, slacken the
security bolt using the socket 3 fitted to the
wheelbrace 6 .
F

S
lacken the other bolts using the
wheelbrace 6 .
Parking the vehicle
Immobilise the vehicle where it does not
block traffic: the ground must be level,
stable and non-slippery ground.
Apply the parking brake unless it has
been programmed to automatic mode.
Switch off the ignition.
With a manual gearbox, engage first
gear to block the wheels.
With an electronic gearbox, place the
lever in position R to block the wheels.
With an automatic gearbox, place the
lever in position P to block the wheels.
Check that the braking warning lamp
and the P warning lamp in the parking
brake control come on.
If necessary, place a chock under the
wheel diagonally opposite the wheel to
be changed.
The occupants must get out of the
vehicle and wait where they are safe.
Never go underneath a vehicle raised
using a jack; use an axle stand. F

P
osition the foot of the jack 8 on the
ground and ensure that it is directly below
one of the front A or rear B jacking points
provided on the underbody, whichever is
closest to the wheel to be changed.
Wheel with wheel trim
When removing the wheel , first
remove the wheel trim using the
wheelbrace 6 by pulling at the valve
cut-out.
When refitting the wheel , refit the
wheel trim by placing its cut-out at the
valve, and press round its edge with the
palm of your hand.
Practical information

229
Following a puncture
The punctured wheel cannot be stowed
under the vehicle. It must be stowed
in the boot. Use a cover to protect the
inside of the boot.
When driving with the "space-saver"
type spare wheel fitted, do not exceed
50 mph (80 km/h).
Have the tightening of the bolts and the
pressure of the spare wheel checked
by a PEUGEOT dealer or a qualified
workshop without delay.
Have the punctured wheel repaired and
replace it on the vehicle as soon as
possible.
Tyre under-inflation detection
The space-saver type or steel spare
wheel does not have a sensor.
The punctured wheel must be repaired
by a PEUGEOT dealer or a qualified
workshop.
Snow chains must only be fitted to the
front wheels. Further, they must never
be fitted to a "space-saver" spare
wheel.
Before fitting the snow chains,
interchange the "space-saver" spare
wheel fitted at the front with the wheel
at the rear on the same side.
10
Practical information

07
306By alphabetical list
Press RADIO, select the station of your
choice and confirm.
By automatic frequency search
Press 7 or 8 for the automatic search
for a lower or higher radio frequency.
Or turn the thumb wheel at the steering
mounted controls.
By manual frequency search
Press 5 or 6 to adjust the radio
frequency step by step.
Selecting a station
The external environment (hill, building, tunnel, underground car park.\
..) may interfere with the reception, including in RDS station tracking mode.
This
phenomenon is a normal result of the way in which radio waves are transm\
itted and does not in any way indicate a fault with the audio system.
The quality of reception is represented by the number of
active waves in this symbol.
Press RADIO or OK to display the
contextual menu.
Changing waveband
Select "Change waveband".
Select "FM / DAB / AM" and confirm.
RADIO

353
Radio .................................................... 305, 333
Range .............................................................. 42
Range, AdBlue


.............................................. 206
Reading lamps, rear


........................................ 96
Rear foglamp .................................. 84, 234, 235
Rear screen (demisting)


............................64, 79
Recharging the battery
................................. 24

6
Reduction of electrical load


..........................247
Regeneration of the particle filter

.................2

02
Reinitialising the electric windows
.................. 54
R

einitialising the remote control
..................... 49
R

eminder, key in ignition ...............................150
Remote control
.......................................... 46-50
R

emovable screen (snow shield).................. 255
Removing a wheel
........................................ 226
Removing the mat


......................................... 102
Replacing bulbs


.................................... 231-236
Replacing fuses
..............................

.......2 37-24 3
Replacing the air filter


...................................202
Replacing the oil filter
................................... 2

02
Replacing the passenger compartment filter


...................................... 202
Replacing wiper blades ...........................95, 248
Resetting the service indicator


.......................29
Resetting the trip recorder


..............................31
Rev counter


..................................................... 14
R
Opening the boot .............................. ..............58
Opening the doors ............................... ...........55
Opening the panoramic sunroof blind


............................................... 10 6
Opening the retractable screen
...................... 41
O

peration indicator lamps

.........................16-18
Paint colour code
.......................................... 268
Panoramic glass sunroof


........................................................ 10 6
Parking brake, electric


.............21, 151-157 , 203
Parking sensors, audible and visual


.............185
Parking sensors, front


...................................185
Parking sensors, rear .................................... 185
Parking space sensor
..................................188
Particle filter


.......................................... 19 6, 201
P
E

UGEOT
C
onnect Assistance

...................270
P
E

UGEOT
C
onnect
Navigation (RT6)


.................................. 39, 273
P
E

UGEOT
C
onnect Packs

...........................270
P
E

UGEOT
C
onnect SOS
............................. 2

70
P
E

UGEOT
C
onnect Sound (RD5)
..........36,

329
Plates, identification ...................................... 268
Player, MP3 CD
............................. 311, 3 3 4, 335
Players, music media
.................................... 310
Port, USB

...................................... 10

1, 315 , 336
Pressures, tyres


............................................ 268
Pre-tensioning seat belts


..............................142
Priming the fuel system
................................195
P
Markings, identification .................................268
Mat ................................................................ 102
Menu, main


................................................... 332
Menu short cuts
............................................ 278
Mirror, rear view
.............................................. 80
Mirrors, door .................................................... 79
Mirror, vanity
..............................

...................10 0
Misfuel prevention
...............................

..........19 4
Modularity, seats


............................................. 78
Mountings for ISOFIX seats


.........................127
MP3 CD
................................................. 311, 335
Multimedia, rear


.................................... 101, 104
Navigation


..................................................... 279
Net


................................................................. 11 0
Net, high load retaining


.................................111
Net, luggage retaining ...................................112
Number plate lamps
............................. 23

5, 236
N
Protecting children .................115-13 4 , 142 , 14 4
Puncture ................................................ 214, 220
Oil change


..................................................... 19 9
Oil consumption


............................................ 19 9
Oil, engine
...............................

................ 30, 199
Opening the bonnet
...................................... 19

6
O
.
Alphabetical index
