2015 PEUGEOT 5008 airbag

145
Lateral airbags
System which contributes towards improving
the protection of the driver and front passenger
in the event of a serious side impact in order to
limit the risk of injury to the chest.
Each lateral airbag is fitted in the front, in the
outer side of the seat back frame.
Deployment
The lateral airbags are deployed unilaterally in
the event of a serious side impact applied to all
or part of the side impact zone B, perpendicular
to the longitudinal centreline of the vehicle on a
horizontal plane and directed from the outside
towards the inside of the vehicle.
The lateral airbag inflates between the front
occupant of the vehicle and the corresponding
door panel.
Curtain airbags
System which contributes towards improving
the protection of the driver and passengers
(with the exception of the rear centre
passenger) in the event of a serious side
impact in order to limit the risk of injury to the
side of the head.
Each curtain airbag is built into the pillars and
the upper passenger compartment area.
Deployment
The curtain airbag is deployed at the same
time as the corresponding lateral airbag in the
event of a serious side impact applied to all or
part of the side impact zone B, perpendicular
to the longitudinal centreline of the vehicle on a
horizontal plane and directed from the outside
towards the inside of the vehicle.
The curtain airbag inflates between the front or
rear occupant of the vehicle and the windows.
Impact detection zones
A. Front impact zone.
B. S ide impact zone. If this warning lamp comes on in
the instrument panel, accompanied
by an audible signal and a message
in the screen, contact a PEUGEOT
dealer or a qualified workshop to have the
system checked. The airbags may no longer be
deployed in the event of a serious impact.
Operating fault
In the event of a minor impact or bump
on the side of the vehicle or if the
vehicle rolls over, the airbag may not be
deployed.
In the event of a rear or front collision,
the airbag is not deployed.
7
Safety

146
Guidelines to follow:
Sit in a normal upright position.
Wear a correctly adjusted seat belt.
Do not allow anything to come between
the occupants and the airbags (a child, pet,
object...), do not attach or fix anything near to
the airbags or their trajectories when inflating
as this could cause injuries when the airbags
are deployed.
Never modify the original definition of your
vehicle, particularly in the area directly
around the airbags.
After an accident or if the vehicle has been
stolen or broken into, have the airbag systems
checked.
All work on the airbag system must be carried
out by a PEUGEOT dealer or a qualified
workshop.
Even if all of the precautions mentioned
are observed, a risk of injury or of minor
burns to the head, chest or arms when an
airbag is deployed cannot be ruled out. The
bag inflates almost instantly (within a few
milliseconds) then deflates within the same
time discharging the hot gas via openings
provided for this purpose.
Lateral airbags
Use only approved covers on the seats,
compatible with the deployment the lateral
airbags. For information on the range of seat
covers suitable for your vehicle, you can
contact a PEUGEOT dealer.
Refer to the "Accessories" section.
Do not fix or attach anything to the seat backs
(clothing...). This could cause injury to the
chest or arms if the lateral airbag is deployed.
Do not sit with the upper part of the body any
nearer to the door than necessary.
Front airbags
Do not drive holding the steering wheel by its
spokes or resting your hands on the centre
part of the wheel.
Passengers must not place their feet on the
dashboard.
Do not smoke as deployment of the airbags
can cause burns or the risk of injury from a
cigarette or pipe.
Never remove or pierce the steering wheel or
hit it violently.
Do not fit or attach anything to the steering
wheel or dashboard, this could cause injuries
with deployment of the airbags.
Curtain airbags
Do not fix or attach anything to the roof. This
could cause injury to the head if the curtain
airbag is deployed.
If fitted on your vehicle, do not remove the
grab handles installed on the roof, they play a
part in securing the curtain airbags.
Safety

238
Dashboard fuses
The fusebox is placed in the lower dashboard.Fuse tables
Fuse N° Rating
(A) Functions
F1 15Rear wiper.
F2 -Not used.
F3 5Airbag control unit.
F4 10Electrochrome rear view mirror, air conditioning, switching and
protection unit, rear multimedia.
F5 30Front one-touch electric windows.
F6 30Rear one-touch electric windows.
F7 5Front and rear courtesy lamps, map reading lamps, rear
reading lamps, sun visor lighting, glove box lighting, centre
armrest lighting, boot 12 V relay control.
Practical information

239
Access to the fuses
F Refer to the paragraph "Access to the to o ls". Fuse
N° Rating
(A) Functions
F8 20Audio equipment, audio/telephone, CD changer, multifunction
screen, tyre under-inflation detection, alarm siren, alarm control
unit, telematic unit.
F9 30Front 12 V socket, cigarette lighter, rear 12 V socket.
F10 15Steering mounted controls.
F11 15Low current ignition switch.
F12 15Trailer presence, rain / sunshine sensor, supply for fuses F32,
F34, F35.
F13 5Engine fusebox, airbag control unit.
F14 15Instrument panel, instrument panel screen, supply for fuse F33.
F15 30Locking and deadlocking.
F17 40Heated rear screen, supply for fuse F30.
10
Practical information

270
Emergency or assistance call
If an impact is detected by the airbag
control unit, and independently of
the deployment of any airbags, an
emergency call is made automatically.
PEUGEOT Connect SOS
In an emergency, press this
button for more than 2 seconds.
Flashing of the green LED and
a voice message confirm that
the call has been made to the
"P
E

UGEOT
C
onnect SOS" call
c e nt re*.
Pressing this button again immediately cancels
the request.
The green LED goes off.
Pressing this button for more than 8 seconds
cancels the request at any time.
The green LED remains on (without flashing)
when communication is established.
It goes off at the end of the call.
" P
E

UGEOT
C

onnect SOS" immediately locates
your vehicle, starts communication with you in
your language**, and where necessary sends
the appropriate public emergency services**. In
countries where the service is not available, or
when the locating service has been expressly
declined, the call sent directly to the emergency
services (112) without the vehicle location. * *
D

epending on the geographical cover of
" P
E

UGEOT
C
onnect SOS", "P
E

UGEOT

C

onnect Assistance" and the official national
language selected by the owner of the vehicle.
The list of countries covered and PEUGEOT
CONNECT services is available from dealers
or at www.peugeot.co.uk.
*

S
ubject to the general conditions for the
service available from dealers and to
technological and technical limitations. If you benefit from the P
E

UGEOT

C

onnect Packs offer with the SOS and
assistance pack included, there are
additional services available to you in
your MyP
E

UGEOT
p
ersonal space, via
the PEUGEOT Internet website in your
country, accessible on
www.peugeot.co.uk.
Audio and Telematics

350
Accessories .................................................. 256
Accessory socket, 12V .........102, 108, 109, 113
Access to the 3rd row
..................................... 75
Additive, AdBlue


.............................. 23, 204-2 11
Additive, Diesel


..................................... 201, 202
Adjusting headlamps


...................................... 89
Adjusting head restraints


..........................70, 77
Adjusting seat belt height
............................. 13

9
Adjusting the date


........................33, 35 , 38 , 40
Adjusting the height and reach of the steering wheel
..................................81
Adjusting the time
........................ 33, 35 , 38 , 40
Advice on driving


.......................................... 147
Airbags


.................................................... 26, 143
Airbags, curtain
..................................... 14

5 , 146
Airbags, front ......................................... 143, 146
Airbags, lateral


...................................... 145, 146
Air conditioning


............................................... 12
Air conditioning, digital


............................. 61, 65
Air conditioning, manual


........................... 61, 62
Air vents


.......................................................... 60
Alarm


............................................................... 51
Anti-pinch


................................................ 53, 10 6
Anti-theft


................................................. 5 0, 148
Armrest, rear
................................................. 10

9
Assistance call


.............................................. 270
Audible warning


............................................ 13 5
Audio streaming (Bluetooth)
................. 3

14 , 3 41
Audio systems

....................................... 273, 329
Automatic illumination of headlamps


................................................ 83
Automatic operation of hazard warning lamps
..............................

............................ 13 5
Automatic rain sensitive windscreen
wipers
................................................................ 94
Au

xiliary socket


............................. 101, 315, 338Battery


...........................................
202, 244-246
Battery, charging

...........................................
246
Battery, remote control
............................. 49,
50
Blind, panoramic sunroof

........................................................
10 6
Blinds ............................................................. 114
BlueHDi

.........................................
179, 195, 204
Bluetooth (hands-free)
......................... 29
6
, 339
Bluetooth (telephone)

...........................
296, 339
Bonnet ...........................................................
19 6
Bonnet stay ...................................................
19 6
Boot ................................................................. 58
Boot lamp


........................................................ 98
Brake discs
.................................................... 20

3
Brake lamps


.................................................. 234
Brake pads


.................................................... 203
Braking, dynamic emergency


.................................................. 15 4
Bulbs (changing)
...............................

...234 , 236
A
D
DAB (Digital Audio Broadcasting) -
Digital radio ........................................ 308, 309
Date (setting)
...............................

.33 , 35 , 38 , 40
Daytime running lamps


...................................86
Daytime running lamps, LED


..........8 6, 231 , 232
Capacity, fuel tank
..............................

..........
191
CD


.........................................................
311, 3 3 4
CD, MP3
........................................ 3

11, 3 3 4
, 335
Central locking


..........................................
47, 56
Centre console


..............................................
101
Changing a bulb
....................................
231-236
Changing a fuse
.....................................
2 37-24 3
Changing a wheel
................................. 212, 223
Changing a wiper blade


.......................... 95, 248
Changing the remote control battery


.............. 49
Checking levels
..................................... 19

9 -201
C
Checking the engine oil level ..................30, 199
Checking tyre pressures (using the kit) ........219
Checks
...............

.................................... 197-203
Checks, routine


..................................... 202, 203
Child lock
...............................

..................54, 13 4
Children
...............................

...115 -13 4 , 14 2 , 14 4
Child seats

................... 11

5, 11 6 , 120 , 12 2 , 128
Child seats, conventional


......................12 2, 123
Child seats, ISOFIX

...................................... 12

8
Closing the boot
.............................................. 58
Closing the doors


............................................ 55
Cold climate screen
...................................... 255
Colour screen, retractable


..............................41
Concertina boards


.......................................... 76
Configuration, vehicle


....32, 34 , 36, 39, 40, 344
Control, electric windows


................................53
Control for panoramic sunroof blind


.............10 6
Control stalk, lighting
................................ 8

2- 84
Control stalk, wipers
.................................91, 93
Coolant level


........................................... 27, 201
Courtesy lamps
............................................... 96
Cover, load space

................................. 10

8, 109
Cruise control
................................................ 16

6
Cup holder

...............................
........99, 108 , 109
B
Alphabetical index

351
Deactivating ESP .......................................... 13 8
Deactivating the passenger airbag ...............14 4
Deadlocking


.................................................... 47
Defrosting


..................................... 63, 64 , 65, 79
Demisting
...............................

......63, 64, 65, 79
Dials and gauges


............................................ 14
Diesel


............................................................ 193
Dimensions


................................................... 267
Dipped beam
...............................

....82, 231-233
Dipstick
................

.................................... 30, 19 9
Direction indicators


...............13 5, 231 , 232 , 234
Display screen, instrument panel


...........15, 179
Display screen, multifunction (with audio system)
..........................34, 36 , 39
Display screen, multifunction (without audio system)
..................................32
Distance alert


................................................ 160
Doors


............................................................... 55
Doors emergency control


...............................57
Door pockets
................................................... 99
D

riving economically ....................................... 12
Dynamic stability control (DSC)


............................................ 22, 137 , 15 4 Emergency call .............................................
2 70
Emergency warning lamps ........................... 13
5
Emissions control system, SCR
.............24, 204
Energy economy mode


.................................247
Engine compartment


............................197, 198
Engine, Diesel
...... 19

3, 195 , 198 , 261, 263 , 266
Engine, petrol


........................193, 197 , 258-260
Environment
........ 12,

50, 64, 183, 201, 211, 246
ESC/ASR
...............................

........................13 6Fuel filler cap
.................................................
191
Fuel filler flap .................................................191
Fuel gauge


..............................................14, 191
Fuel tank ................................................ 191, 19 4
Fusebox, dashboard


.....................................238
Fusebox, engine compartment


.....................237
Fuses


.............................................................237
E
Eco-driving .....................................................12
E co-driving (advice) ........................................ 12
Economy mode


............................................. 247
Electronic gearbox


........................................ 170
Electronic stability control (ESC)
..................13 6
Emergency boot release
................................. 59
F
Filling with fuel ..............................1 91, 193, 194
Filter, air ............... ......................................... 202
Filter, oil


......................................................... 202
Filter, particle


........................................ 201, 202
Filter, passenger compartment


.....................202
Fitting a wheel

...............................
................228
Fitting roof bars


............................................. 254
Fittings, boot
......................................... 10

8, 109
Fittings, interior


............................................... 99
Flap, fuel filler

...............................
.................19 4
Flashing indicators


........................................ 13 5
Floor, concertina


................................... 108, 109
Foglamps, front


............................... 84, 231, 233
Foglamps, rear


............................... 84, 234, 235
Folding the rear seats


.........................73, 75 , 76
Folding/unfolding the door mirrors
............................................ 79
Front seats


.......................................... 68, 69 , 72
Fuel .................................................. 12, 191 , 193
Fuel consumption
...................................... 12,

42
G
Gearbox, automatic ....................12, 14 , 18 , 151 ,
15 4 , 155 , 175, 203 , 246
Gearbox, electronic


..........................12, 18 , 151 ,
15 4 , 170 , 180 , 203
Gearbox, manual


...........................12, 151 , 15 4 ,
155 , 169 , 180, 203
Gear lever, automatic gearbox
................

....................................... 175
Gear lever, electronic gearbox


.....................170
Gear lever, manual gearbox


.........................169
Gear shift indicator


....................................... 179
Glove box
................................................ 99, 10 0
G . P. S .


............................................................ 270
Grab handles
.................................................. 99
G

uidance (Navigation)

..................................270
Guide-me-home


........................................ 86, 87
.
Alphabetical index
