14
WINDSHIELD WIPER AND WASHER SWITCH
Move the lever to one of the following positions to
operate the windshield wipers:
1 Mist
(MIST) – One sweep operation of the
front wipers.
2 Intermittent
(INT) – Operates the
speed-sensing front wipers intermittently.
The intermittent speed can be adjusted by
twisting the time control ring
3 to increase
or decrease wiper speed.
4 Low
(LO) – Front wipers operate at a
continuous low-speed.
5 High
(HI) – Front wipers operate at a
continuous high-speed.
6 Pull the lever toward you to activate the
front washer. The front wipers will
operate several times.
REAR WINDSHIELD WIPER AND WASHER
7 Intermittent
(INT) – Rear wiper operates intermittently.
8 Low
(ON) – Rear wiper operates at a continuous low-speed.
9 Push the lever forward to activate the rear washer. The rear wiper will operate
several times.
For more information, refer to the “Instruments and controls (section 2)” of your Owner’s Manual.
AUTOMATIC CLIMATE CONTROLS
1 AUTO BUTTON/DRIVER’S SIDE TEMPERATURE CONTROL DIAL
The auto mode may be used year-round. Push the AUTO button to turn the system on,
and the system will automatically control the inside temperature (autom\
atic cooling and/
or dehumidified heating), air flow distribution and fan speed.
Turn the driver’s side temperature control dial to the left for cooler air or right for \
warmer air.
2 DUAL BUTTON/PASSENGER’S SIDE TEMPERATURE CONTROL DIAL
Push the D UAL button to turn the passenger’s side temperature controls on or off.
This will allow the passenger’s side temperature to be adjusted independently from the
driver’s side by turning the passenger’s side temperature control dial.
Turn the passenger’s side temperature control dial left for cooler air or right for
warmer air.
FIRST DRIVE FEATURES
123
5
7
9
6
8
4
1
2
4
5
MIST
OFF
INT
LO
HI3
6
9
7
8
INT
ON
1904703_15c_Pathfinder_QRG_031315.indd 143/13/15 12:52 PM
To view detailed instructional videos regarding these and other features, please go to www.nissanownersinfo.mobi.
