2015 NISSAN PATHFINDER reset

11
2
12
212220
23
24
3
4
9
5
10
16
1
6
7
19
8
17
18
Behind
Steering
Wheel
13
14
1 Instrument Brightness Control*2 Twin Trip Odometer Reset Switch*3 Vehicle Information Display4 Headlight and Turn Signal Switch5 Low Tire Pressure Warning Light6 Windshield Wiper and

Washer Switch
7 Vehicle Information Display Switch8 Steering Wheel Switches for
Audio*/Bluetooth
®/Navigation*
9 Cruise Control10 Vehicle Dynamic Control (VDC)
System Off Switch* 11 Heated Steering Wheel Switch*12 Power Liftgate Switch
13 Power Liftgate Main Switch14 Tilt/Telescopic Steering Column*15 Blind Spot Warning / Rear Cross
Traffic Alert Switch16 Tow Mode Switch17 Power Inverter Switch18 Hood Release*19 Control Panel Display Screen*
20 Front Passenger Air Bag
Status Light*21 Audio System22
Automatic Climate Controls23
Power Outlet 24 Climate Control/Heated
Seat Switches*25 4WD-i Control Knob*
*See your Owner’s Manual for information.
Underneath
Instrument
Panel
In Front
of Console
25
15
1904703_15c_Pathfinder_QRG_031315.indd 43/13/15 12:51 PM

6
LOOSE FUEL CAP
A LOOSE FUEL CAP warning message will
appear in the vehicle information display
1
when the fuel-filler cap is not tightened correctly.

To tighten, turn the cap clockwise until a single
click is heard.

The warning message will extinguish when the
vehicle detects the fuel-filler cap is properly
tightened and the reset
button 2 is

pressed for about 1 second.

If the cap is not properly tightened, the Malfunction
Indicator Light
may illuminate.
For more information, refer to the “Instruments and controls (section 2)” and the “Pre-driving checks and adjustments
(section 3)” of your Owner’s Manual.
2
1
ESSE NTIAL I N FOR MATION
FUEL-FILLER DOOR
The fuel-filler door is located on the driver’s side of
the vehicle.

The fuel-filler door automatically locks or unlocks
when the driver’s door is locked or unlocked.

To open the fuel-filler door after unlocking, push
the right side of the fuel-filler door.
For more information, refer to the “Pre-driving checks and adjustments (section 3)” of your Owner’s Manual.
TOWING YOUR VEHICLE
All-Wheel Drive (AWD) vehicle
• An all-wheel drive vehicle must be towed with all wheels off the ground,\
even if placed
in 2WD mode.

For proper towing and to prevent accidental damage to your vehicle, NISSAN
recommends that a service operator tow your vehicle after carefully reading the
Owner’s Manual precautions.
For more information, refer to the “In case of emergency (section 6)” of your Owner’s Manual.
1904703_15c_Pathfinder_QRG_031315.indd 63/13/15 12:52 PM
To view detailed instructional videos regarding these and other features, please go to www.nissanownersinfo.mobi.

17
2 SEEK •CAT AND TRACK BUTTONS

To scan quickly and stop at the previous or next broadcast station, press the

SEEK•CAT
button or the TRACK
button.

For satellite radio to switch to the previous or next category, press the

SEEK•CAT
button or the TRACK
button.

To change tracks on a CD, press the
SEEK•CAT
button or the TRACK
button.

To rewind or fast forward a track on a CD, press and hold the
SEEK•CAT
button or
the TRACK

button.
3
AUDIO BUTTON/TUNE/FOLDER CONTROL KNOB

To manually tune the radio, turn the TUNE/FOLDER control knob left or right.

Press the AUDIO button to access the audio settings screen.
4 STATION SELECT BUTTONS

Twelve stations can be set for the FM band, 6 for the AM band and 18 for the
satellite radio.

To store a station in a preset, you must first select a radio band by pressing the
AM•FM
5 or
S AT
button 6 then tune to the desired AM, FM or satellite radio station.

Then press and hold the desired station preset button (1-6) until the preset number is
updated on the display and the sound is briefly muted. The channel indicator will then
display, and the sound will resume. Programing is now complete.

To retrieve a previously set station, select the radio band where the preset was stored
then press the corresponding station select button (1-6).
For more information, refer to the “Monitor, climate, audio, phone and voice recognition systems (section 4)” of
your Owner’s Manual.
USB ( Universal Serial Bus) CONNECTION PORT/ iPOD® INTERFACE
( if so equipped)
The USB port 1 is located in the center console
under the armrest.

When a compatible USB memory device or iPod®
is plugged into the USB port
1, compatible
audio and video files stored on the device can be
played through the vehicle’s audio system and
front display.
For more information, refer to the “Monitor, climate, audio, phone and voice recognition systems (section 4)” of
your Owner’s Manual.
1
1904703_15c_Pathfinder_QRG_031315.indd 173/13/15 12:52 PM
To view detailed instructional videos regarding these and other features, please go to www.nissanownersinfo.mobi.

18
FIRST DRIVE FEATURES
CRUISE CONTROL
The cruise control system enables you to set a
constant cruising speed once the vehicle has
reached 25 mph (40 km/h).

The system will automatically maintain the set
speed until you tap the brake pedal, accelerate,
cancel or turn the system off.

To activate the cruise control, push the ON•OFF switch 1. CRUISE will be displayed
in the vehicle information display.

To set a cruising speed, accelerate the vehicle to the desired speed, pus\
h the
COAST/SET switch
2 and release. The SET indicator light in the vehicle

information display will illuminate. Take your foot off the accelerator pedal. Your
vehicle will maintain the set speed.

To reset at a faster cruising speed, push and hold the ACCEL/RES switch 3.
When the vehicle attains the desired speed, release the switch.

To reset at a slower cruising speed, push and hold the COAST/SET switch 2.
Release the switch when the vehicle slows to the desired speed.

To cancel the preset speed, push the CANCEL switch 4.

To turn off cruise control, push the ON•OFF switch 1. Both the CRUISE indicator
light and the SET indicator light in the vehicle information display will extinguish.
For more information, refer to the “Starting and driving (section 5)” of your Owner’s Manual.
POWER OUTLETS
12V OUTLETS

The power outlets are for powering electrical
accessories such as cellular telephones. They
are rated at 12 volt, 120W (10A) maximum.

To use a power outlet, open the cap.

The power outlets on the instrument panel 1
and inside the center console 2 are powered

only when the ignition switch is in the ACC or
ON position.


The power outlet in the cargo area 3 is powered
all the time.
12
3
4
1
2
3
1904703_15c_Pathfinder_QRG_031315.indd 183/13/15 12:52 PM
To view detailed instructional videos regarding these and other features, please go to www.nissanownersinfo.mobi.

20
VEHICLE INFORMATION DISPLAY
The vehicle information display 1 displays items such as:

Vehicle settings

Trip computer information

Drive system warnings and settings
(if so equipped)

Cruise control system

Intelligent Key operation information

Indicators and warnings

Tire pressure information

4X4 information (if so equipped)
USING THE VEHICLE INFORMATION DISPLAY
The vehicle information display modes can be changed using the
button 2 and the
ENTER button 3 located on the steering wheel.

Press the button 2 to enter the vehicle
information menu items.

Press the button 4 to navigate through the
items in the vehicle information.

Press the ENTER button 3 to change or select
an item in the vehicle
information display.

Press the button 5 to go back to the
previous menu.
RESETTING THE TRIP COMPUTER
1. Press the
button 2 until you reach the trip
computer mode 6.
2. Press the
button 2 again for more than
1.5 seconds to reset average fuel consumption,
average speed, distance to empty and journey time.
SETTINGS
The setting mode allows you to change the information displayed in the vehicle
information display:

Driver assistance
(if so equipped)

Main menu selection
Body color

Maintenance

Alarms

Vehicle settings
Language

Unit

Welcome effect
For more information, refer to the “Instruments and controls (section 2)” of your Owner’s Manual.
SYSTEM GUIDE
1
2
435
6
1904703_15c_Pathfinder_QRG_031315.indd 203/13/15 12:52 PM
To view detailed instructional videos regarding these and other features, please go to www.nissanownersinfo.mobi.
