2015 MITSUBISHI MIRAGE width

Rear-view camera (if so equipped)
Features and controls 5-61
5
CAUTION The rear-view camera uses a wide-angle lens. As a result, imag
es and distances shown
on the screen are not exact. Actual distance may be different from dis- tance indicated by the
lines on the screen,
depending on the loadi
ng condition of the
vehicle and road surface condition. The reference lines for
distance and vehicle
width are based on a level, flat road surface. In the following cases, objects shown on the screen will appear to
be farther off than they
actually are.• When the rear of th
e vehicle is weighed
down with the weight of passengers and luggage in the vehicle. (Case 1)• When there is an upward slope at the back.(Case 2)
Case 1 A- Actual objects B- Objects shown on the screen
CAUTION The reference lines for
distance and vehicle
width are intended to i
ndicate the distance to
a flat object such as a level, flat road surface. They may not indicate correct distance depending on the shape of an obstacle.For example, when there is an object behind the vehicle that has u
pper sections projecting
in the direction of the
vehicle, the reference
lines on the screen will indicate that point A is the farthest point a
nd point B is the closest
point to the vehicle. In
reality, point A and B
are actually the same distance from the vehi- cle, and point C is fa
rther off than point A
and B.Case 2 A- Actual objects B- Objects shown on the screen
NOTE
 Mirror image is displayed on the screen.  Monitor brightness is ad
justed automatically
by sensors.  It is possible to change the display language of the screen. For details, please refer to the separatedowner’s manual for “Mitsubishi Multi Enter- tainment System”.  Under certain circumst
ances, it may become
difficult to see an image on the screen, even when the system is functioning correctly. • In a dark area, such as at night. • When water drops or condensation are on the lens. • When sun light or he
adlights shine directly
into the lens.
BK0212400US.book 61 ページ ２０１４年４月１日　火曜日　午後２時２１分

Tire repair kit (if so equipped)
For emergencies 8-7
8
1. Park the vehicle on a safe, flat and level place.2. Set the parking brake firmly. 3. On vehicles equipped with manual trans- axle, stop the engine and move the gear-shift lever to the “R” (Reverse) position. On vehicles equippe
d with continuously
variable transmissi
on (CVT), move the
selector lever to the “P” (PARK) position, and stop the engine. 4. Turn on the hazard warning flashers and set up a warning sign, such as a warning triangle or flashing signal lamp, at an ade-quate distance from the vehicle, and have all your passengers
leave the vehicle.
5. Take out the tire repair kit.Make sure that the compressor switch is OFF. 6. Shake the tire sealant bottle well.
• The puncture hole has a length or width of 1/7 inch (4 mm) or greater.• The tire is punctured in the side wall (A), not in the tread (B).• The vehicle has been driven with the tirealmost completely flat.• The tire has completely slipped over thewheel rim and come off the wheel.• The wheel is damaged.• A bump, cut or crack is on the tire.• The tire sealant’s expiration date has passed. (The expiration date is shown onthe bottle label (C).)• The ambient temperature is below -40 °F(-40 °C) or above 140 °F (60 °C).WA R N I N G
WA R N I N G The tire sealant can
cause health damage
if swallowed. If you
accidentally swallow
it, drink as much water as possible andimmediately seek
medical attention.
If the tire sealant ge
ts in your eyes or on
your skin, rinse it away with lots of water. If you still sense an abnormality, seek medical attention. Consult a doctor immediately if any aller- gic reactions occur. Do not allow children to touch the tire sealant.CAUTION If the vehicle body is contaminated by the tire sealant, wipe the tire sealant off immedi- ately with a wet cloth. Immediately wash clot
hes contaminated with
tire sealant. The tire sealant may not be removed from the clothes.NOTE
 Do not pull out an object, such as a nail or screw, that penetrat
es the punctured tire.
 Move the vehicle so that the tire valve is positioned away from the point where thetire touches the ground. If the valve is near the point where the tire touches the ground, the sealant may not enter the tire easily.
BK0212400US.book 7 ページ ２０１４年４月１日　火曜日　午後２時２１分

Tires 9-12 Vehicle care and maintenance
9
N00939200566
It is important to familiarize yourself with the following terms:
 Cold tire pressure: • The measured pressure after the vehiclehas been parked for at least three hours, or • The measured pressure when the vehicleis driven less than 1 mile (1.6 km) after having been parked for three hours.
 Maximum pressure: the maximum per- missible cold tire inflation pressure for this tire.  Recommended inflation pressure: the inflation pressure for optimum tire perfor- mance. Intended outboard sidewall: • The sidewall that c
ontains a whitewall,
bears white letteri
ng or bears manufac-
turer, brand, and/or model name molding that is higher or deeper than the same molding on the other sidewall of the tire,or • The outward facing si
dewall of an asym-
metrical tire that has a particular sidethat must always face outward when mounted on a vehicle.
 Passenger car tire: a
tire intended for use
on passenger cars, multipurpose passen- ger vehicles, and trucks that have a gross vehicle weight rati
ng (GVWR) of 10,000
pounds or less.
 Light truck (LT) tire
: a tire designated by
its manufacturer as primarily intended foruse on lightweight tr
ucks or multipurpose
passenger vehicles.  Tread: portion of a tire that comes into contact with the road.  Tread rib: a tread se
ction running circum-
ferentially around a tire. Tread separation: pulling away of the tread from the tire carcass.  Carcass: the tire structure, except tread and sidewall rubber which, when inflated, bears the load. Sidewall: portion of a tire between the tread and bead.  Section width: the line
ar distance between
the exteriors of the sidewalls of an inflated tire, excluding elevations due to labeling, decoration, or protective bands. Bead: the part of the tire that is made of steel wires, wrapped
or reinforced by ply
cords and that is shaped to fit the rim. Ply: a layer of rubber-coated parallel cords.  Cord: the strands forming the plies in the tire.  Rim: a metal support for a tire or a tire and tube assembly upon which the tirebeads are seated.  Rim diameter: nominal diameter of the bead seat.
 Check to see that the battery is securely installed and cannot be moved. Also checkeach terminal for tightness.  If you will not be driving your vehicle for a long period of time, remove the battery andstore it in a place where the battery fluid will not freeze. The battery only should be stored with a full charge.  Before cleaning the battery, tighten all the filler port caps to keep
dirt and moisture out.
Tires
WA R N I N GDriving with tires that are worn, damaged or improperly inflated is dangerous. These type tire conditions will adverselyaffect vehicle performance. These type tire conditions can also cause a tread separation or blowout which mayresult in an accide
nt causing serious
injury or death. Tires, including spar
e tire, degrade over
time with age even when they are not being used. It is recommended that tires over 6 yearsgenerally be replaced even if damage is not obvious.NOTE
BK0212400US.book 12 ページ ２０１４年４月１日　火曜日　午後２時２１分

Tires
Vehicle care and maintenance 9-13
9
 Groove: the space between two adjacent tread ribs.
EXAMPLE: P215/65R15
EXAMPLE: 95H
Maximum load indicates the maximum load this tire is designed to carry.
Tire Markings Size Designation P
Passenger car tir
e size based on
U.S.A. design standards
215 Section width in millimeters (mm) 65
Aspect ratio in percent (%) Ratio of section he
ight to section
width of tire.
R
Construction code • “R” means radial construction. • “D” means diagon
al or bias con-
struction.
15 Rim diameter in inches (in)
NOTE
 European/Japanese metric tire sizing is based on European/Japanese design standards. Tires designed to these standards have thetire size molded into
the sidewall beginning
with the section width. The letter “P” is absent from this tire
size designation. Exam-
ple: 215/65R15 96H.  LT (Light Truck) -metri
c tire sizing is based
on U.S.A. design standa
rds. The size desig-
nation for LT-metric tires is the same as for P-metric tires except for the letters “LT” thatare molded into the sidewall preceding the size designation. Example: LT235/85R16.  Temporary spare tires are high pressure com- pact spares designed for temporary emer- gency use only. Tires designed to thisstandard have the letter “T” molded into the sidewall preceding th
e size designation.
Example: T145/80D18 103M.
Service Description 95
Load index A numerical code associated with the maximum load a tire can carry.
H
Speed symbol A symbol indicating the range of speeds at which a tire can carry a load corresponding to its load index under certai
n operating con-
ditions. The maximum speed correspond-ing to the speed symbol should only be achieved under specified operating conditions
. (i.e. tire pres-
sure, vehicle loading, road condi- tions and posted speed limits)
Maximum Load
WA R N I N G Overloading of your tire is dangerous. Overloading can cause tire failure, affectvehicle handling, and
increase your stop-
ping distance. Use tires of the recom- mended load capacity for your vehicle.Never overload them.
BK0212400US.book 13 ページ ２０１４年４月１日　火曜日　午後２時２１分

Vehicle dimensions
Specifications 11-3
11
The engine serial num
ber is stamped on the
cylinder block as show
n in the illustration.
N01148100616
The tire and loading information placard is located on the driver’s door sill.
N01148200242
The certification label is located on thedriver’s door sill.
N01147501577 N01147600917
Engine serial number * - Front of the vehicle
Tire and loading information placard
Certification label Vehicle dimensions Overall length 148.8 in (3,780 mm)Overall width 65.6 in (1,665 mm)Overall height 59.4 in (1,510 mm)Wheel base 96.5 in (2,450 mm)
Vehicle weights
Item
M/T
CVT
Gross vehicle weight
rating 2,910 lb (1,320 kg) 3,020 lb (1,370 kg)
BK0212400US.book 3 ページ ２０１４年４月１日　火曜日　午後２時２１分
