2015 MITSUBISHI iMiEV Owner's Manual (in English)

BK0209800US.book 7 ページ ２０１４年１月１４日　火曜日　午前９時２６分

2-1
2
If this warning light comes on or
flashes while you’re driving...
Quick index
N00200702188
If this warning light comes on
or flashes while you’re driving...
NOTE
These warning lights will come on for a few se
conds for a bulb check when the electric
motor switch is first turned to “ON”.
Warning light
Do this
Ref. page
12V starter battery charging system warning
light
 Park your vehicle in a safe place a
nd turn off the electric motor unit.
Contact a certified i-MiEV dealer for assistance.
P.5-43
or
Brake warning light
 If this light comes on while driving, ch
eck to see that the parking brake is
fully released.  If this light stays on after releasing
the parking brake, stop and check the
brake fluid level.  If the brake fluid level is correct, ther
e may be a system
malfunction. Avoid
hard braking and high speeds, and cont
act a certified i-MiEV dealer for
assistance.
P.5-42
Electric motor unit warning light
 Park your vehicle in a safe place and
contact a certified
i-MiEV dealer for
assistance.
P.5-43
BK0209800US.book 1 ページ ２０１４年１月１４日　火曜日　午前９時２６分

If this warning light comes on or flashes while you’re driving... 2-2 Quick index
2
Electric power steering
system (EPS) warning
light
 If this light comes on while the elec
tric motor unit is running, it may
become harder to turn the steering wh
eel. Have your vehicle inspected at a
certified i-MiEV
dealer as soon as possible.
P. 5 - 2 8
Anti-lock braking system warning light
 When this light comes on, the anti-l
ock braking system is not functioning
and only the ordinary brak
ing system is functioning.
 Park your vehicle in a safe plac
e and stop the electric motor unit.
Test the system as described on page 5-27. If the light does not go out
after the test, or if it comes on again, we recom-
mend that you have the system checked
at a certified i-MiEV dealer as
soon as possible.
P.5-26, 5-27
SRS warning light
 Immediately have the airb
ag and the seat belt pre-
tensioner system checked
at a certified i-MiEV dealer.
P.4-13, 4-26
Power down warning light
 If this light comes on while driving,
avoid sudden acce
leration and sudden
starting. When the remaining power in the main drive lithium-ion battery is low, recharge the main drive lithium-ion battery as soon as possible.
P. 5 - 4 3
Warning light
Do this
Ref. page
BK0209800US.book 2 ページ ２０１４年１月１４日　火曜日　午前９時２６分

If this warning light comes on or
flashes while you’re driving...
Quick index 2-3
2
Selector lever position indicator in the instru-
ment cluster flashes slowly
 Have the transmission checked at a cert
ified i-MiEV dealer as soon as pos-
sible.
P.5-21
and
ASC indicator and ASC OFF indicator
 Park your vehicle in a safe place a
nd turn off the electric motor unit.
Restart the electric motor unit and check to see if the indicator comes on again.  If the indicator does not go out, or if it
comes on again, have your vehicle
inspected at a certified i-MiEV
dealer as soon as possible.
 When this indicator comes on, the acti
ve stability contro
l is not functioning
and normal operation of the vehi
cle will not be affected.
P.5-30
Tire pressure monitoring system warning light
 If the warning light comes on, you shoul
d stop and adjust the tires to the
proper inflation pressure
as soon as possible.
(See “Tire inflation pr
essures” on page 9-13.)
Once adjustments have been made, the
warning light will go off after a few
minutes of driving.  If the warning light blinks for appr
oximately 1 minute and then remains
continuously illuminated, the system is
not operating properly. If the sys-
tem returns to normal, the warning li
ght will go off. If the warning light
does not go off, have the vehicle insp
ected at a certified i-MiEV dealer.
P.5-31, 5-32
Warning light
Do this
Ref. page
BK0209800US.book 3 ページ ２０１４年１月１４日　火曜日　午前９時２６分

If this problem occurs... 2-4 Quick index
2
N00200900854
If this problem occurs...
Problem
Do this
Ref. Page
Cannot turn the key.
From “LOCK” to “ACC”. Turn the key while turning the st
eering wheel in either direction.
P.5-19, 5-20
From “ACC” to “LOCK”. Check the position of the selector lever. The key cannot be removed unless the selector
lever is set to the “P” (PARK) position.
Cannot shift the selector lever from the “P” (PARK) position.
Shift the selector lever wh
ile pressing the brake pedal.
Check that the electric motor switch is in the “ON” position.
P.5-21
The windows are fogged up.
1. Set the mode selection dial
to the “ ” or “ ” position.
2. Turn on the blower.
P.7-9
The electric motor unit does not start. The lights do not come on. The lights are dim. The horn does not honk. The horn sound is weak. Cannot charge the main drive lith-ium-ion battery.
Have the 12V starter battery checked.
Recharge or replace as needed.
P.8-2, 9-7
BK0209800US.book 4 ページ ２０１４年１月１４日　火曜日　午前９時２６分

If this problem occurs...
Quick index 2-5
2
The vehicle is stuck
in sand, mud, or
snow.
Rock your vehicle back and forth to free it. P.8-13
WA R N I N G When attempting to rock your vehicle out of
a stuck position, be sure that
no one is near the vehicl
e. The rocking motion may c
ause the vehicle to
suddenly lurch forward or backward, possibly injuring bystanders. Avoid spinning the wheels. Prolonged efforts to free
a stuck vehicle may result
in transmission failure.
If the vehicle remains stuck after several rocking attempts, have a towing service pull the vehicle out.
Problem
Do this
Ref. page
The brakes are not functioning prop- erly after driving through water.
Dry out the brakes by driving slowly whil
e lightly pressing the brake pedal. P.6-5
A tire is punctured.
1. Park the vehicle in a safe place where the surface is flat and level. 2. Repair the flat tire with tire repair kit.
P.8-5
Problem
Do this
Ref. Page
BK0209800US.book 5 ページ ２０１４年１月１４日　火曜日　午前９時２６分

BK0209800US.book 6 ページ ２０１４年１月１４日　火曜日　午前９時２６分

3
General information/ChargingFamiliarizing yourself with i-
MiEV ........
...........
...........
...........
.......3-2
Modifications to and racing of your vehi
cle ...........
...........
.........
.....3-6
Mitsubishi Motors genuine parts .....................................................3-7California Perchlorate Materials Requirements ...............................3-7 Cautions and actions to deal with intense heat ................................3-7 Cautions and actions to deal with intense cold ................................3-9Charging ........................................................................................ 3-11 Precautions during Charging the Main Drive Lithium-ion Battery ................................................3-14Regular charging (charging method with rated AC 120 V
outlet) .....
........
............3-15
EV charging cable ..........................................................................3-21Regular charging (using 240V Electric Vehi
cle Supply Equipment) ..
...................3-24
Quick charging (charging method with quick charger) ..
..............
.........
.........
.....3-24
Charging troubleshooting guide ....................................................3-28 High-Voltage components ......
...........
...........
...........
.........
.........
.....3-30
MiEV Remote System ...................................................................3-32
