2015 MAZDA MODEL 3 5-DOOR USB

*Some models.5–1
5Interior Features
Use of various features for ride comfort, including air-conditioning and
audio system.



Climate Control System..................................................................... 5-2 Operating Tips ........................................................................\
....... 5-2
Vent Operation ........................................................................\
...... 5-3
Manual Climate Control ............................................................... 5-5
Automatic Climate Control ........................................................... 5-9
Dual-Zone Automatic Climate Control ....................................... 5-12
Audio System ........................................................................\
............ 5-16 Antenna ........................................................................\
............... 5-16
Operating Tips for Audio System ............................................... 5-17
Audio Set (Type A) ..................................................................... 5-26
Audio Set (Type B) ..................................................................... 5-38
Audio Control Switch Operation
* ............................................... 5-57
AUX/USB/iPod mode ................................................................. 5-59
Bluetooth
® .......................................................................\
.................. 5-77
Bluetooth®* .......................................................................\
........... 5-77
Bluetooth® Hands-Free (Type A)* ............................................... 5-99
Bluetooth® Hands-Free (Type B)* ............................................. 5-105
Bluetooth® Audio (Type A)* ...................................................... 5-115
Bluetooth® Audio (Type B)* ...................................................... 5-117
Troubleshooting* .......................................................................\
5-131
Interior Equipment ........................................................................\
5-134 Sunvisors ........................................................................\
........... 5-134
Interior Lights ........................................................................\
... 5-135
Accessory Sockets .................................................................... 5-137
Cup Holder ........................................................................\
........ 5-138
Bottle Holder ........................................................................\
..... 5-139
Storage Compartments .............................................................. 5-140
.B[EB@%9&"'@&EJUJPOJOEC


.B[EB@%9&"'@&EJUJPOJOEC










5–24
Interior Features
Audio System
Operating Tips for USB device
This unit plays audio fi les as follows:
Extension Playback with this unit
.mp3 MP3
.wma WMA
.aac AAC
.m4a
.wav
*1
.ogg *1 OGG
*1 Type B
CAUTION
Do not use an audio fi le extension on
fi les other than audio fi les. In addition,
do not change the audio fi le extension.
Otherwise, the unit will not recognize
the fi le correctly resulting in noise or a
malfunction.
NOTE
 y Playback may not be possible
depending on the type and condition of
the USB fl ash memory even if the audio
fi le complies with the standard above.
 y A copyright protected WMA/AAC fi le
cannot be played in this unit.
 y  The order of the music data stored in
the device may differ from the playback
order.
 y To prevent loss or damage of stored
data, we recommend that you always
back up your data.
 y If a device exceeds the maximum
electric current value of 1,000 mA,
it may not operate or recharge when
connected.
 y Do not pull out the USB device while in
the USB mode (only pull it out while in
FM/AM radio or CD mode).
 y The device will not operate if the data is
password protected.
 y MP3/WMA/AAC/OGG *1fi les written
under specifi cations other than the
indicated specifi cation may not play
normally or fi les/folder names may not
display correctly.
*1 Type B
.B[EB@%9&"'@&EJUJPOJOEC


.B[EB@%9&"'@&EJUJPOJOEC










5–26
Interior Features
Audio System
Audio Set (Type A)



Power/Volume/Sound Controls ........................................................................\
..... page 5-28



Clock ........................................................................\
............................................. pag e 5-30



Operating the Radio ........................................................................\
...................... page 5-32



Operating the Compact Disc (CD) Player................................\
............................. page 5-34



How to use Auxiliary jack/USB port .................................................................... page 5-37



Error Indications ........................................................................\
........................... page 5-37
.B[EB@%9&"'@&EJUJPOJOEC


.B[EB@%9&"'@&EJUJPOJOEC










5–37
Interior Features
Audio System
NOTE
The number of characters which can be
displayed is restricted.
Message display
If “ CHECK CD ” is displayed, it means
that there is some CD malfunction. Check
the CD for damage, dirt, or smudges, and
then properly reinsert it. If the message
appears again, insert another known good
CD. If the message continues to appear,
take the unit to an Authorized Mazda
Dealer for service.
How to use Auxiliary jack/USB port
Audio can be heard from the vehicle's
speakers by connecting a commercially-
available portable audio unit to the
auxiliary jack.
Use a commercially-available, non-
impedance (3.5
) stereo mini plug cable.
Contact an Authorized Mazda Dealer for
details.
In addition, audio can be played from the
vehicle audio device by connecting a USB
device or an iPod to the USB port.
Refer to AUX/USB/iPod mode on page
5-59 .
Error Indications
If you see an error indication on the audio
display, fi nd the cause in the chart. If you
cannot clear the error indication, take the
vehicle to an Authorized Mazda Dealer.
Indication Cause Solution
CHECK CD CD is
inserted
upside
down
Insert the CD properly.
If the error indication
continues to display,
consult an Authorized
Mazda Dealer.
CD is
defective Insert another CD
properly. If the error
indication continues
to display, consult an
Authorized Mazda
Dealer.
.B[EB@%9&"'@&EJUJPOJOEC


.B[EB@%9&"'@&EJUJPOJOEC










5–44
Interior Features
Audio System
Operating the Radio
Radio ON
Select the
icon on the home screen and display the Entertainment screen. When selecting
the desired radio, the following icons are indicated in the lower part o\
f the center display.
AM/FM Radio
Icon Function
Displays the Entertainment menu. Use to switch to a different audio source.
Displays the station list.
Select
to display the frequencies of up to ten radio stations on the auto
memory preset list.
Select the desired frequency.
Displays the Favorites list. Long-press to store radio station currently\
being aired.
Switches the on and off. Displays the multi-cast channel list of the
.
You can search for receivable radio stations.
Scanning stops at each station for about fi ve seconds.
Select again to continue receiving the radio station.
Manual radio station selection.
Select the tuner and rotate the commander knob or drag the display, or touch the radio
frequency.
Press
or to change the radio frequency one step at a time.
When
or is long-pressed, the radio frequency changes continually. It stops when you
remove your hand from the icon or the commander knob.
Launches the iTunes Tagging function (for Apple devices with USB use only). Can be used
when the
is on.
Automatic radio station selection.
When long-pressed, the radio frequency changes continually. It stops when you remove
your hand from the icon or the commander knob.
Displays sound settings to adjust audio quality level.
Refer to Volume/Display/Sound Controls on page 5-42 .
.B[EB@%9&"'@&EJUJPOJOEC


.B[EB@%9&"'@&EJUJPOJOEC










*Some models.5–47
Interior Features
Audio System
NOTE
 y If an analog broadcast is received once
and
is received while HD1 is
selected, the audio unit switches to the
station automatically. y  When the icon is illuminated, there
could be a noticeable difference in
sound quality and volume when a
change from digital to analog signals
occurs. If the sound quality and volume
become noticeably diminished or cut
off, select the
icon to turn off
( icon is not illuminated). y  Once an analog broadcast is received
when HD1 is selected from the Favorite
channels, it is switched to
automatically. If the radio reception
conditions are poor, or HD is off,
switching to
broadcasts is
not possible.
 y  When an HD specialty channel (HD2 to
HD8) is selected from the Favorite
channels, “Signal Lost” is displayed
and no audio is output until
is received. If the radio reception
conditions are poor, “Signal Lost”
continues to be displayed.
 y If the icon is not illuminated,
information such as song titles of the
station are received,
however, the audio output is analog.
iTunes Tagging (for Apple devices with
USB use only)
By tagging a song currently being aired,
the song can be easily purchased from the
iTunes Store. Up to 100 tags can be stored.
1. Select the
icon. The tag is stored in
the audio unit.
2. Connect the device via USB. The tag is sent to the connected device
automatically.
3. Synchronize the device with iTunes. The tagged song can now be purchased
from the iTunes Store.
NOTE
 y Both AM and FM can be
used.
 y  Because iTunes Tagging only supports
purchasing from the iTunes Store, direct
downloading from the equipped vehicle
audio is not possible.
 y If the available memory for the
connected device is insuffi cient, the tag
is not sent.
 y If an error occurs while the tag is being
sent, reconnect the device.
Operating the Satellite Radio *
What is satellite radio?
With over 130 channels, SiriusXM
Satellite Radio brings you more of what
you love. Get channels and channels of
commercial-free music, plus sports, news,
talk, entertainment and more.
Commercial-free music from nearly
every genre — rock to pop, hip-hop to
country, jazz, classical and more. Plus
live performances and artist-dedicated
channels.
Live sports Play-by-Play & Expert Talk
— every NFL game, every NASCAR
®
race, 24/7 sports talk, college sports and
more.
Exclusive entertainment, comedy and
talk — The biggest names, compelling
talk, hilarious comedy.
World-class news plus local traffi c and
weather.
Sign up for SiriusXM Satellite Radio
today!
.B[EB@%9&"'@&EJUJPOJOEC


.B[EB@%9&"'@&EJUJPOJOEC










5–54
Interior Features
Audio System
Icon Function
Plays a CD. When selected again, playback is temporarily stopped.
Advances to the beginning of the next song.
Long-press to fast forward. It stops when you remove your hand from the \
icon or the
commander knob.
Displays sound settings to adjust audio quality level.
Refer to Volume/Display/Sound Controls on page 5-42 .
Example of use (When searching for
a song from the top level of an MP3/
WMA/AAC CD)
1. Select the
icon and display the
folder/fi le list at the top level.
2. When the folder is selected, folders/fi le
lists in the folder are displayed.
3. Select the desired song.
NOTE
 y  Select to move to a folder one level
higher.
 y  The appearance of the repeat and
shuffl e icons changes depending on the
type of operation in which the function
is used.
How to use Auxiliary jack/USB port
Audio can be heard from the vehicle's
speakers by connecting a commercially-
available portable audio unit to the
auxiliary jack.
Use a commercially-available, non-
impedance (3.5
) stereo mini plug cable.
In addition, audio can be played from the
vehicle audio device by connecting a USB
device or an iPod to the USB port.
Refer to AUX/USB/iPod mode on page
5-59 .
.B[EB@%9&"'@&EJUJPOJOEC


.B[EB@%9&"'@&EJUJPOJOEC










5–56
Interior Features
Audio System
Tab Item Function
System Tool Tips
Turns button explanations ON/OFF.
Language Changes the language.
Temperature Changes the setting between Fahrenheit and
Celsius.
Distance Changes the setting between miles and
kilometers.
Music Database Update Used to update Gracenote
® . Gracenote is used
with USB Audio, and provides:
1. Supplemental music information (Such as song name, artist name)
2. Voice recognition assistance for Play Artist and Play Album
Gracenote can be downloaded from the Mazda
Handsfree Website.
Refer to Gracenote Database (Type B) on page
5-75 .
Restore All Factory Settings Memory and settings are initialized to the
factory settings.
The initialization launches by selecting the
button.
About Agreements and
Disclaimers
Verify the disclaimer and agree.
Version Information Can verify the current audio unit OS version
and Gracenote Database version.
.B[EB@%9&"'@&EJUJPOJOEC


.B[EB@%9&"'@&EJUJPOJOEC
