2015 LEXUS RX450h towing

5883-6. Using the storage features
Cup holders
Front (Center console)
Press down the lid on the farthest
side from the driver.
Front (Instrument panel)
Press in and re lease the cup
holder.NOTICE■
When stowing a bottle
Put the cap on before stowing the bottle. Do not place open bottles in the bottle
holders. The contents may spill. Bottle holders/door pockets and cup holders

6303-7. Other interior features
■ Stolen Vehicle Location
If your vehicle is stolen, Safety Co nnect can work with local authorities
to assist them in locating and re covering the vehicle. After filing a
police report, call the Safety Conn ect response center at 1-800-25-
LEXUS (1-800-255-3987) and follo w the prompts for Safety Con-
nect to initiate this service.
In addition to assisting law enforcemen t with recovery of a stolen vehi-
cle, Safety-Connect-equipped vehicl e location data may, under cer-
tain circumstances, be shared with third parties to locate your vehicle.
Further information is available at Lexus.com.
■ Emergency Assistance Button (“SOS”)
In the event of an emergency on the road, push the “SOS” button to
reach the Safety Connect response center. The answering agent will
determine your vehicle’s location, assess the emergency, and dispatch
the necessary assistance required. If you accidentally press the “SOS” bu tton, tell the response-center agent
that you are not experiencing an emergency.
■ Enhanced Roadside Assistance
Enhanced Roadside Assistance ad ds GPS data to the already
included warranty-based Lexus roadside service.
Subscribers can press the “SOS” button to reach a Safety Connect
response-center agent, who can help with a wide range of needs, such
as: towing, flat tire, fuel delivery, etc. For a descriptio n of the Enhanced
Roadside Assistance services and th eir limitations, please see the
Safety Connect Terms and Conditions, which are available at
Lexus.com.

6584-3. Do-it-yourself maintenance
■
Engine oil consumption
A certain amount of engine oil will be consumed while driving. In the following situ-
ations, oil consumption may increase, and engine oil may need to be refilled in
between oil maintenance intervals. ●
When the engine is new, for example di rectly after purchasing the vehicle or
after replacing the engine●
If low quality oil or oil of an inappropriate viscosity is used●
AWD models with towing package: When driving at high engine speeds or with
a heavy load, when towing, or when driving while accelerating or decelerating
frequently●
2WD models and AWD models without towing package: When driving at high
engine speeds or with a heavy load, or when driving while accelerating or
decelerating frequently●
When leaving the engine id ling for a long time, or when driving frequently
through heavy traffic
CAUTION■
Used engine oil ●
Used engine oil contains potentially harmful contaminants which may cause skin
disorders such as inflammati on or skin cancer, so care should be taken to avoid
prolonged and repeated contact. To remove used engine oil from your skin, wash
thoroughly with soap and water.●
Dispose of used oil and filters only in a safe and acceptable manner. Do not dis-
pose of used oil and filters in househol d trash, in sewers or onto the ground.
Call your Lexus dealer, service station or auto parts store for information con-
cerning recycling or disposal.
●
Do not leave used engine oil within the reach of children.

6964-3. Do-it-yourself maintenance
13
DCDC 150 A IG1 MAIN, TOWING BATT,
DEICER, TOWING, STOP, RDI FAN
NO. 1, ABS NO. 1, RR DEF, AIR SUS,
HEATER, RDI FAN NO. 2, H-LP
CLN, PBD, ECU-IG1 NO. 1, ECU-
IG1 NO. 3, GAUGE NO. 1, ECU-IG1
NO. 2, EPS, FR WIP, RR WIP, FR
WASH, RR WASH, RH S-HTR, LH S-
HTR, TAIL, PANEL, D/L ALT B, FR
FOG, FR DOOR, FL DOOR, RR
DOOR, RL DOOR, PSB, P-SEAT LH,
P-SEAT RH, TI&TE, FUEL OPN, DR
LOCK, OBD, RR FOG, S/ROOF,
4WD, INVERTER, ECU-ACC, P/
POINT, CIG, RADIO NO. 214
AMP1 30 A Audio system15
EFI MAIN 30 A Multiport fuel injection system/
sequential multiport fuel injection sys-
tem, EFI NO. 1, EFI NO. 2, F/PMP16
AMP2 30 A Audio system17
IG2 MAIN 30 A IGN, GAUGE NO. 2, ECU IG218
IP J/B 25 A Power door lock system19
STR LOCK 20 A Starter system20
RAD NO. 3 15 A Meters and gauges, navigation sys-
tem, audio system21
HAZ 15 A Emergency flashers
22
ETCS 10 A Multiport fuel injection system/
sequential multiport fuel injection sys-
tem
23
RAD NO. 1 10 A Audio system, navigation systemFuse Ampere Circuit

7024-3. Do-it-yourself maintenance
22
TA I L 10 A Parking lights, front side marker lights,
tail lights, license pl ate lights, front fog
lights, towing converter23
AIR SUS 20 A24
P-S E AT R H 30 A Power seat (right-side)25
OBD 7. 5 A On-board diagnosis26
FR DOOR 25 A Front power window (right-side), out-
side rear view mirror27
RR DOOR 25 A Rear power window (right-side)28
FL DOOR 25 A Front power window (left-side), out-
side rear view mirror29
RL DOOR 25 A Rear power window (left-side)30
FR WASH 25 A Windshield wipers and washer31
RR WIP 15 A Windshield wipers and washer32
RR WASH 20 A Windshield wipers and washer33
FR WIP 30 A Windshield wipers and washer
34
ECU IG2 10 A Multiport fuel injection system/
sequential multiport fuel injection sys-
tem, front passenger occupant classi-
fication system, SRS airbag system,
stop lights, electronically controlled
brake system, steering lock system,
hybrid system35
GAUGE NO. 2 7. 5 A Gauge and meters36
RH S-HTR 15 A Seat heater (right-side)
37
LH S-HTR 15 A Seat heater (left-side)Fuse Ampere Circuit

5
When trouble arises
7255-1. Essential information
If your vehicle needs to be towed
Situations needs to contact dealers before towing
The following may indicate a problem with your transmission. Contact
your Lexus dealer before towing.
● A warning message for the hybrid system is shown on the multi-infor-
mation display and the vehicle does not move.
● The vehicle makes an abnormal sound.If towing is necessary, we recommend having your vehicle towed by your
Lexus dealer or a commercial towing service, using a lift-type truck or a
flatbed truck.
Use a safety chain system for all towi ng, and abide by all state/provincial
and local laws.
2WD models: If towing your vehicle wi th a wheel-lift type truck from the
front, the vehicle's rear wheels and axles must be in good conditions.
(  P. 726, 730)
If they are damaged, use a to wing dolly or flatbed truck.
AWD models: If towing your vehicle with a wheel-lift type truck, use a tow-
ing dolly. (  P. 7 2 6 , 7 3 0 )

7265-1. Essential information
Towing with a sling-type truck
Do not tow with a sling-type truck
to prevent body damage.
Towing with a wheel-lift type truck
From the front (2WD models)
Release the parking brake.
From the front (AWD models)
Use a towing dolly under the rear
wheels.

5
When trouble arises
7275-1. Essential information
From the rear
Use a towing dolly under the front
wheels.
Using a flatbed truck
If your Lexus is transported by a
flatbed truck, it should be tied
down at the locations shown in the
illustration.
If you use chains or cables to tie
down your vehicle, the angles
shaded in black must be 45  .
Do not overly tighten the tie downs
or the vehicle may be damaged.
