2015 LEXUS RC F fuse box

4797-3. Do-it-yourself maintenance
7
Maintenance and care
RC350/RCF_U (OM24636U)
RC350
Engine compartment
Fuse boxes (P. 5 0 9 )
Battery ( P. 4 8 7 )
Engine oil level dipstick (P. 4 8 1 )
Engine coolant reservoir (P. 4 8 4 )
Engine oil filler cap ( P. 4 8 2 )Brake fluid reservoir (
P. 4 8 6 )
Wa s h e r f l u i d t a n k ( P. 4 9 0 )
Electric cooling fans
Condenser ( P. 4 8 5 )
Radiator ( P. 4 8 5 )1
2
3
4
5
6
7
8
9
10

4807-3. Do-it-yourself maintenance
RC350/RCF_U (OM24636U)
RC F
Fuse boxes ( P. 5 0 9 )
Battery ( P. 4 8 7 )
Engine oil level dipstick (P. 4 8 1 )
Engine coolant reservoir (P. 4 8 4 )
Engine oil filler cap ( P. 4 8 2 )Brake fluid reservoir (
P. 4 8 6 )
Wa s h e r f l u i d t a n k ( P. 4 9 0 )
Electric cooling fans
Condenser ( P. 4 8 5 )
Radiator ( P. 4 8 5 )1
2
3
4
5
6
7
8
9
10

5097-3. Do-it-yourself maintenance
7
Maintenance and care
RC350/RCF_U (OM24636U)
Turn the engine switch off.
Open the Fuse box cover.
Engine compartment: type A fuse box
Push the tab in and lift the lid off.
Engine compartment: type B fuse box
Push the tab in and lift the lid off.
Driver’s side instrument panel
Remove the lid.
Checking and replacing fuses
If any of the electrical components do not operate, a fuse may have blown. If
this happens, check and replace the fuses as necessary.
1
2

5107-3. Do-it-yourself maintenance
RC350/RCF_U (OM24636U)
Remove the fuse with the pullout
tool.
Only type A fuses can be removed
using the pullout tool.
Check if the fuse is blown. Normal fuse
Blown fuse
Type A and B:
Replace the blown fuse with a new fuse of an appropriate amperage rating. The
amperage rating can be found on the fuse box lid.
Ty p e C a n d D :
Contact your Lexus dealer.
3
4
1
2
Ty p e ATy p e B
Ty p e CTy p e D

5117-3. Do-it-yourself maintenance
7
Maintenance and care
RC350/RCF_U (OM24636U)
■After a fuse is replaced
●If the lights do not turn on even after the fuse has been replaced, a bulb may need
replacement. (P. 5 1 2 )
●If the replaced fuse blows again, have the vehicle inspected by your Lexus dealer.
■If there is an overload in a circuit
The fuses are designed to blow, protecting the wiring harness from damage.
■When replacing light bulbs
Lexus recommends that you use genuine Le xus products designed for this vehicle.
Because certain bulbs are connected to circuits designed to prevent overload, non-gen-
uine parts or parts not designed for this vehicle may be unusable.
WA R N I N G
■To prevent system breakdowns and vehicle fire
Observe the following precautions.
Failure to do so may cause damage to the vehicle, and possibly a fire or injury.
●Never use a fuse of a higher amperage rati ng than that indicated, or use any other
object in place of a fuse.
●Always use a genuine Lexus fuse or equivalent.
Never replace a fuse with a wire, even as a temporary fix.
●Do not modify the fuses or fuse boxes.
NOTICE
■Before replacing fuses
Have the cause of electrical overload determ ined and repaired by your Lexus dealer as
soon as possible.
