2015 LEXUS NX300h differential

196 4-1. Before driving
NX300h_U_OM78007U ■
Break-in schedule
If your vehicle is new or equipped with any new power train components (such as an
engine, transmission, differential or wheel bearing), Lexus recommends that you do not
tow a trailer until the vehicle has been driven for over 500 miles (800 km).
After the vehicle has been driven for over 500 miles (800 km), you can start towing.
However, for the next 500 miles (800 km), drive the vehicle at a speed of less than
50 mph (80 km/h) when towing a trailer, and avoid full throttle acceleration.■
Maintenance ●
If you tow a trailer, your vehicle will requir e more frequent maintenance due to the addi-
tional load. (See “Warranty and Services Guide”, “Owner’s Manual Supplement” or
“Scheduled Maintenance”.) ●
Retighten the fixing bolts of the towing ba ll and bracket after approximately 600 miles
(1000 km) of trailer towing. ■
If trailer sway occurs
One or more factors (crosswinds, passing vehicles, rough roads, etc.) can adversely
affect handling of your vehicle and trailer, causing instability.●
If trailer swaying occurs:
• Firmly grip the steering wheel. Steer straight ahead.
Do not try to control trailer sway ing by turning the steering wheel.
• Begin releasing the accelerator pedal i mmediately but very gradually to reduce
speed.
Do not increase speed. Do not apply vehicle brakes.
If you make no extreme correction with the steering or brakes, your vehicle and trailer
should stabilize. ●
After the trailer sw aying has stopped:
• Stop in a safe place. Get all occupants out of the vehicle.
• Check the tires of the vehicle and the trailer.
• Check the load in the trailer.
Make sure the load has not shifted.
Make sure the tongue weight is appropriate, if possible.
• Check the load in the vehicle.
Make sure the vehicle is not overloaded after occupants get in.
If you cannot find any problems, the speed at which trailer swaying occurred is beyond
the limit of your particular vehicle-trailer combination. Drive at a lower speed to pre-
vent instability. Remember that swaying of the towing vehicle-trailer increases as
speed increases.

614 9-1. Specifications
NX300h_U_OM78007U * : The fluid capacity is the quantity of reference.
If replacement is necessary, contact your Lexus dealer.
* : The fluid capacity is the quantity of reference.
If replacement is necessary, contact your Lexus dealer.
* : Minimum pedal clearance when depressed wi th a force of 110 lbf (490 N, 50.0 kgf)
while the hybrid system is operating.Hybrid transmission Fluid capacity
* 
Front
4.0 qt. (3.8 L, 3.3 Imp.qt.)
Fluid type To y o t a G e n u i n e AT F W S
NOTICE ■
Transmission fluid type
Using transmission fluid other than “Toyot a Genuine ATF WS” may cause deterioration
in shift quality, locking up of your transm ission accompanied by vibration, and ulti-
mately damage the transmission of your vehicle.
Rear differential (Rear electric motor) (AWD models) Fluid capacity
* 1.9 qt. (1.8 L, 1.6 Imp.qt.)
Fluid type To y o t a G e n u i n e AT F W S
NOTICE ■
Transmission fluid type
Using transmission fluid other than “Toyot a Genuine ATF WS” may cause deterioration
in shift quality, locking up of your transm ission accompanied by vibration, and ulti-
mately damage the transmission of your vehicle.
Brakes Pe d a l c l e a r a n c e
* 4.13 in. (105 mm) Min.
Brake pad wear limit 0.04 in. (1.0 mm)
Pedal free play 0.04 — 0.24 in. (1.0 — 6.0 mm)
Fluid type FMVSS No. 116 DOT 3 or SAE J1703

665Alphabetical index
NX300h_U_OM78007U Coat hooks.............................................. 466
Compass .................................................. 473
Condenser ..............................................509
Console box ........................................... 447
Consumption screen ...............................111
Coolant
Capacity .................................................. 613
Checking............................................... 508
Preparing and checking
before winter ....................................326
Warning light ...................................... 565
Cooling system .....................................508
Hybrid system overheating ......... 600
Cruise control
Cruise control...................................... 267
Dynamic radar cruise
control ..................................................240
Dynamic radar cruise control
with full-speed range ....................253
Cup holders ............................................ 448
Curtain shield airbags ........................... 40
Customizable features ....................... 633 Daytime running light system............ 221
Deck board..............................................452
Deck under tray ...................................... 451
Defogger
Outside rear view mirrors ............ 435
Rear window........................................ 435
Windshield............................................ 435
Differential ................................................ 614
Dimension ............................................... 608
Dinghy towing ....................................... 200
Display
Drive information................................ 103
Dynamic radar cruise
control.................................................. 240
Dynamic radar cruise control
with full-speed range ................... 253
Energy monitor........................................ 111
LDA (Lane Departure Alert
with steering control) ................... 270
Multi-information display.................102
Warning messages .......................... 572
Do-it-yourself maintenance............. 498
Doors
Automatic door locking and
unlocking system.............................. 127
Back door................................................ 129
Door glasses ..........................................166
Door lock................................................. 124
Outside rear view mirrors ..............163
Rear door child-p rotectors ............ 126
Side doors ............................................... 124 D

672 Alphabetical index
NX300h_U_OM78007U Multi-information display
Drive information ................................ 103
Dynamic radar cruise
control ..................................................240
Dynamic radar cruise control
with full-speed range ....................253
Energy monitor ........................................ 111
Language .............................................. 638
LDA (Lane Departure Alert
with steering control) ...................253
Warning messages........................... 572
Navigation system
*Noise from under vehicle ....................... 8
Odometer ...................................................97
Oil
Engine oil................................................... 611
Rear differential oil .............................. 614
Opener
Back door ............................................... 130
Fuel filler door ......................................236
Hood ....................................................... 500
Outside rear view mirrors ..................163
Adjusting and folding........................ 163
Blind Spot Monitor (BSM)............. 316
Linked mirror function
when reversing ................................. 164
Mirror position memory .................. 154
Outside rear view mirror
defoggers ...........................................435 Outside temperature display .............. 97
Overheating........................................... 600
Panic mode ................................................ 119
Parking brake
Operation................................................ 213
Parking brake engaged
warning buzzer/message ........... 215
Warning light .......................................566
Parking lights
Light switch............................................. 219
Replacing light bulbs ....................... 552
Warning light .......................................566
PCS (Pre-Collision System)
Function ................................................... 310
PCS switch ...............................................311
Warning light .......................................566
Warning message............................. 572
Personal lights ........................................443
Switch ...................................................... 444
Power back door opener and
closer ....................................................... 129
Power control unit coolant
Capacity...................................................613
Checking .............................................. 508
Preparing and checking
before winter .................................... 326
Radiator ................................................. 509N
