2015 LEXUS LX570 tow

TABLE OF CONTENTS
1
LX570_OM_OM60L96U_(U) 1
Before driving Adjusting and operating features such as door locks, mirrors,
and steering column
2
When driving Driving, stopping and safe-driving information
3
Interior features Air conditioning and audio systems, as well as other interior
features for a comfortable driving experience
4
Maintenance
and care Cleaning and protecting your vehicle, performing do-it-
yourself maintenance, and maintenance information
5
When trouble
arises What to do if the vehicle needs to be towed, gets a flat tire, or
is involved in an accident
6
Vehicle
specifications Detailed vehicle information
7
For owners Reporting safety defects for U. S. owners, and seat belt and
SRS airbag instructions for Canadian owners
Index Alphabetical listing of inform ation contained in this manual

1
2
3
4
5
6
7
3
LX570_OM_OM60L96U_(U) 2-1. Driving procedures
Driving the vehicle ........................ 166
Engine (ignition) switch ............... 177
Automatic transmission............... 181
Turn signal lever ............................ 189
Parking brake ................................. 190
Horn...................................................... 191
2-2. Instrument cluster
Gauges and meters ..................... 192
Indicators and warning
lights................................................. 196
Multi-information display......... 200
2-3. Operating the lights and wipers
Headlight switch .......................... 208
Automatic High Beam ................ 213
Fog light switch ............................. 220
Windshield wipers
and washer................................... 222
Rear window wiper
and washer................................... 228
Headlight cleaner switch ........... 231 2-4. Using other driving systems
Cruise control ............................... 232
Dynamic radar cruise
control............................................ 236
Intuitive parking assist ................. 251
Rear view monitor system ........ 262
Lexus parking assist
monitor .......................................... 270
Wide view front &
side monitor................................ 303
4-Wheel AHC
(Active Height Control
Suspension) ................................. 320
AVS (Adaptive Variable
Suspension system)................... 331
Four-wheel drive system........... 332
Crawl Control (with Turn
Assist function)........................... 337
Multi-terrain Select ..................... 344
Driving assist systems................. 349
Pre-Collision System.................. 357
2-5. Driving information
Off-road precauti ons ................. 363
Cargo and luggage .................... 368
Vehicle load limits ........................ 375
Winter driving tips ....................... 376
Trailer towing .................................. 381
Dinghy towing ................................ 4012
When driving

TABLE OF CONTENTS Index
6
LX570_OM_OM60L96U_(U) 4-1. Maintenance and care
Cleaning and protecting the
vehicle exterior .......................... 734
Cleaning and protecting the
vehicle interior............................ 737
4-2. Maintenance
Maintenance
requirements............................... 740
General maintenance ................ 743
Emission inspection and
maintenance (I/M)
programs ...................................... 746
4-3. Do-it-yourself maintenance
Do-it-yourself service
precautions .................................. 747
Hood.................................................. 750
Engine compartment................... 751
Tires ................................................... 766
Tire inflation pressure ................. 775
Wheels.............................................. 779
Air conditioning filter ................... 781
Electronic key battery ................ 784
Checking and
replacing fuses ........................... 786
Light bulbs ...................................... 803 5-1. Essential information
Emergency flashers...................... 816
If your vehicle needs to be
towed............................................... 817
If you think something is
wrong ............................................. 824
Fuel pump shut off system ....... 825
5-2. Steps to take in an emergency
If a warning light turns on or a
warning buzzer sounds... ...... 826
If a warning message is
displayed ....................................... 837
If you have a flat tire.................... 854
If the engine will not start ......... 868
If the shift lever cannot be
shifted from “P” ......................... 870
If you lose your keys ..................... 871
If the electronic key does not
operate properly ....................... 872
If the battery is discharged ....... 875
If your vehicle overheats .......... 878
If the vehicle becomes
stuck................................................. 881
If your vehicle has to
be stopped in an
emergency .................................. 8834
Maintenance and care 5
When trouble arises

401-2. Opening, closing and locking the doors
LX570_OM_OM60L96U_(U) ■
Conditions affecting operation
The smart access system with push-button start uses weak radio waves. In the fol-
lowing situations, the commu nication between the electr onic key and the vehicle
may be affected, preventing the smart acce ss system with push -button start, wire-
less remote control and en gine immobilizer system from operating properly.
(Ways of coping:  P. 872)●
When the electronic key battery is depleted ●
Near a TV tower, electric power plant, gas station, radio st ation, large display,
airport or other facility that generates strong radio waves or electrical noise●
When carrying a portable ra dio, cellular phone, cordless phone or other wire-
less communication devices ●
When the electronic key is in contact with, or is covered by the following metal-
lic object
• Card to which aluminum foil is attached
• Cigarette boxes that have aluminum foil inside
• Metallic wallets or bags
•Coins
• Hand warmers made of metal
• Media such as CDs and DVDs ●
When multiple electronic keys are in the vicinity ●
When other wireless keys (that emit radio waves) are being used nearby ●
When carrying or using the electronic key together with the following devices
that emit radio waves
• Another vehicle’s electronic key or a wireless key that emits radio waves
• Personal computers or personal digital assistants (PDAs)
• Digital audio players
• Portable game systems ●
If window tint with a metallic content or metallic objects are attached to the rear
window

681-3. Adjustable components (s eats, mirrors, steering wheel)
LX570_OM_OM60L96U_(U) Power easy access system
When the driver enters and exits the ve hicle, the driver ’s seat and steer-
ing wheel will automatically p erform the following operations:
Exiting the vehicle: When all of the
following actions have been per-
formed, the steering wheel will
move up and back to the point far-
thest away from the driver and the
seat will move backward (auto
away function): • The shift lever has been shifted to P
• The “ENGINE START STOP”
switch has been turned off
• The driver seat belt has been
unfastened
Entering the vehicle: When either
of the following actions has been
performed, the steering wheel will
move toward the driver and seat
will move forward (auto return
function): • The “ENGINE START STOP”
switch has been turned to
ACCESSORY mode
• The driver seat belt has been fas-
tened

721-3. Adjustable components (s eats, mirrors, steering wheel)
LX570_OM_OM60L96U_(U) Tumbling the second seats and third seat entry
For easy access to the third seat, perform in “Tumbling the sec-
ond seats” (  P. 73).
■ Before tumbling the second seats
Stow the seat belt buckles and
lower the head restraints to the
lowest position.
Pass the outer seat belts through
the seat belt hangers and secure
the seat belt plates. This prevents the shoulder belt
from being damaged.
Make sure that the seat belts are
removed from the hangers before
using them. STEP 1
STEP 1
STEP 2

731-3. Adjustable components (s eats, mirrors, steering wheel)
1
Before driving
LX570_OM_OM60L96U_(U) ■ Tumbling the second seats
Fold down the seat back while pull-
ing the seatback angle adjustment
lever, and swing the whole seat up
and forward.
Hook the holding strap to the
assist grip and secure the seat by
pulling its free end. When returning the second seat to
its original position, stow the hold-
ing strap.STEP 1
STEP 2

751-3. Adjustable components (s eats, mirrors, steering wheel)
1
Before driving
LX570_OM_OM60L96U_(U) Folding the third seats
■ Before folding the third seats
Stow the seat belts buckles.
Stow the center head restraint in the seatback. (  P. 90)
Pass the outer seat belts through
the seat belt hangers and secure
the seat belt plates. This prevents the shoulder belt
from being damaged.
Make sure that the seat belts are
removed from the hangers before
using them.
Stow the center seat belt tabs in the cover set in the roof.
(  P. 93) STEP 1
STEP 2
STEP 3
STEP 4
