2015 LEXUS LX570 automatic transmission fluid

1872-1. Driving procedures
2
When driving
LX570_OM_OM60L96U_(U) ■ Shift ranges and their functions
● Automatically selecting gears betw een 1 and 6 according to vehicle
speed and driving conditions. But, the gear is limited according to
selected shift range.
● You can choose from 6 levels of engine braking force.
● A lower shift range will provide grea ter engine braking force than a
higher shift range, and the engine speed will also increase. ■
Paddle shift switches (if equipped) ●
When the “-” paddle shift switch is operated in the “D” position, a shift range will
be automatically selected. The highest gear of the first shift range will be one
gear lower than the gear in use during normal “D” position driving. ●
Automatic deactivation of shift range selection in the “D” position
Shift range selection in the “D” position w ill be deactivated in the following situa-
tions:
• When the vehicle comes to a stop
• If the accelerator pedal is depressed for longer than a certain period of time
in one shift range■
“S” mode ●
When the shift range is “5” or lower, holding the shift lever or paddle shift switch
toward “+” sets the shift range to “6”. ●
To prevent excessive engine speed, a function was adopted that automatically
selects a higher shift range before the engine speed becomes too high. ●
To protect the automatic transmission, a function is adopted that automatically
selects a higher shift range when the fluid temperature is high.■
Downshifting restrict ions warning buzzer
To help ensure safety and driving perf ormance, downshifting operation may some-
times be restricted. In some circumstances, downsh ifting may not be possible even
when the shift lever or a paddle shift swit ch (if equipped) is operated. (The warning
buzzer will sound twice.)

7484-3. Do-it-yourself maintenance
LX570_OM_OM60L96U_(U) Items Parts and tools
Engine oil level  P. 753) • “Toyota Genuine Motor Oil” or
equivalent
• Rag or paper towel, funnel
(used only for adding oil)
Fuses (  P. 786) • Fuse with same amperage rating as
original
Power steering fluid (  P. 761) • Automatic transmission fluid
DEXRON ®
II or III
•Rag or paper towel
• Funnel (used only for adding power
steering fluid)
Light bulbs (  P. 803) • Bulb with same number and
wattage rating as original
• Phillips-head screwdriver
•Flathead screwdriver
•Wrench
Radiator and condenser
(  P. 758) 
Tire inflation pressure (  P. 775) • Tire pressure gauge
• Compressed air source
Washer fluid (  P. 765) • Water or washer fluid containing
antifreeze (for winter use)
• Funnel (used only for adding water
or washer fluid)

7614-3. Do-it-yourself maintenance
4
Maintenance and care
LX570_OM_OM60L96U_(U) Power steering fluid
■ Fluid level
The fluid level should be within the appropriate range.
Full (when cold)
Add fluid (when cold)
Full (when hot)
Add fluid (when hot)
Hot: Vehicle has been driven arou nd 50 mph (80 km/h) for 20 min-
utes, or slightly longer in fr igid temperatures. (Fluid tempera-
ture, 140  F - 175  F [60  C - 80  C]).
Cold: Engine has not been run for about five hours. (Room tempera-
ture, 50  F - 85  F [10  C - 30  C]).
■ Checking the fluid level
Make sure to check the fluid type and prepare the necessary items.
Clean all dirt off the reservoir.
Remove the cap by turning it counterclockwise.
Wipe the dipstick clean.
Reinstall and remove the reservoir cap again.
Check the fluid level.Fluid type Automatic transmission fluid DEXRON ®
II or III
Items Rag or paper, Clean funnel (only for adding fluid)STEP 1
STEP 2
STEP 3
STEP 4
STEP 5

5
When trouble arises
8835-2. Steps to take in an emergency
LX570_OM_OM60L96U_(U) CAUTION■
When attempting to free a stuck vehicle
If you choose to push the vehicle back and forth to free it, make sure the surround-
ing area is clear, to avoid striking other vehicles, objects or people. The vehicle may
also lunge forward or lunge back sudden ly as it becomes free. Use extreme cau-
tion. ■
When shifting the shift lever
Be careful not to shift th e shift lever with the acc elerator pedal depressed.
This may lead to unexpected rapid acceleration of the vehicle that may cause an
accident resulting in de ath or serious injury.
NOTICE■
To avoid damaging the transm ission and other components●
Avoid spinning the rear wheels and depr essing the accelera tor pedal more than
necessary. ●
If the vehicle remains stuck even after these procedures are performed, the vehi-
cle may require towing to be freed. ●
When a warning message for the automatic transmission fluid temperature is dis-
played while attempting to free a stuck vehicle, immediately remove your foot
from the accelerator pedal and wait until the warning message disappears. Oth-
erwise, the transm ission may become damaged. (  P. 843)

8936-1. Specifications
6
Vehicle specifications
LX570_OM_OM60L96U_(U) Automatic transmission
The fluid capacity is the quantity of refere nce. If replacement is necessary, contact
your Lexus dealer.
Transfer
* : Your Lexus vehicle is filled with “Toyot a Genuine Transfer Gear oil LF” at the
factory. Use Lexus approved “Toyota Ge nuine Transfer Gear oil LF” or an
equivalent of matching quality to satisf y the above specification. Please contact
your Lexus dealer for further details.Fluid capacity With air-
cooled type
ATF cooler 12.6 qt. (11.9 L, 10.5 Imp.qt.)
Without
air-cooled type
ATF cooler 12.3 qt. (11.6 L, 10.2 Imp.qt.)
Fluid type Toyota Genuine ATF WS
NOTICE■
Automatic transmission fluid type
Using transmission fluid other than “T oyota Genuine ATF WS” may cause deterio-
ration in shift quality, locking up of your transmission accompanied by vibration, and
ultimately damage the tran smission of your vehicle.
Oil capacity 1.53 qt. (1.45 L, 1.28 Imp.qt.)
Oil type
* Toyota Genuine Transf er Gear oil LF or
equivalent
Recommended oil viscosity SAE 75W

8946-1. Specifications
LX570_OM_OM60L96U_(U) Brakes
* 1
: Minimum pedal clearance when depressed with a force of 110 lbf (490 N, 50
kgf) while the engine is running
* 2
: Parking brake lever travel when pulled up with a force of 45.0 lbf (200 N,
20.4 kgf)
Chassis lubrication
Steering Pedal clearance
* 1
3.6 in. (92 mm) Min.
Pedal free play 0.04  0.24 in. (1.0  6.0 mm)
Brake pad wear limit 0.04 in. (1.0 mm)
Parking brake lining wear limit 0.04 in. (1.0 mm)
Parking brake lever travel
* 2
5  7 clicks
Fluid type SAE J1703 or FMVSS No. 116 DOT 3
Propeller shafts Spider Lithium base chassis grease, NLGI No.2
Slide yoke Molybdenum-disulfide lithium base chassis
grease, NLGI No.2 or Lithium base chassis
grease, NLGI No.2
Free play Less than 1.18 in. (30 mm)
Power steering fluid type Automatic transmission fluid DEXRON ®
II or III
