7394-1. Maintenance and care
4
Maintenance and care
LX570_OM_OM60L96U_(U) NOTICE■
Cleaning detergents ●
Do not use the following types of detergent, as they may discolor the vehicle inte-
rior or cause streaks or damage to painted surfaces.
• Non-seat portions: Organic substances such as benzene or gasoline, alkaline
or acidic solutions, dye, or bleach.
• Seats: Acidic solutions, such as thinner, benzene, or alcohol. ●
Do not use polish wax or po lish cleaner. The instrument panel’s or other interior
part’s painted surface may be damaged.■
Preventing damage to leather surfaces
Observe the following precautions to avoid damage to and deterioration of leather
surfaces. ●
Remove any dust or dirt on leather surfaces immediately. ●
Do not expose the vehicle to direct sunlight for extended periods of time. Park
the vehicle in the shade, especially during summer. ●
Do not place items made of vinyl, plastic, or that contain wax on the upholstery, as
they may stick to the leather surface if the vehicle interior heats up significantly.■
Water on the floor
Do not wash the vehicle floor with water.
Vehicle systems such as the audio syst em may be damaged if water comes into
contact with electrical components under the floor of the vehicle, and may also
cause the body to rust. ■
Cleaning the inside of the rear quarter windows and rear window ●
Do not use glass cleaner to clean the rear quarter windows and rear window, as
this may cause damage to the rear wind ow defogger heater wires or antenna.
Use a cloth dampened with lukewarm wa ter to gently wipe the window clean.
Wipe the window in stroke s running parallel to the heater wires or antenna.●
Be careful not to scratch or damage the heater wires or antenna.

7914-3. Do-it-yourself maintenance
4
Maintenance and care
LX570_OM_OM60L96U_(U) Fuse layout and amperage ratings
■ Engine compartment (fuse box on the left side)
Fuse Ampere Circuit
1 A/F 15 A A/F heater
2 HORN 10 A Horn
3 EFI MAIN 25 A Multiport fuel injection system/
sequential multiport fuel injection sys-
tem, A/F heater, fuel pump
4 IG2 MAIN 30 A INJ, IGN, MET
5 RR A/C 50 A Blower controller
6 CDS FAN 25 A Condenser fan
7 RR S/HTR 20 A Rear seat heater
8 FR FOG 15 A Front fog lights
9 STOP 15 A Stoplights, high mounted stoplight,
brake controller, ABS, VSC, main
body ECU, Multiport fuel injection
system/sequential multiport fuel injec-
tion system, trailer

7924-3. Do-it-yourself maintenance
LX570_OM_OM60L96U_(U) 10 SEAT-A/C LH 25 A Seat heaters and ventilators
11 HWD4 30 A No circuit
12 HWD3 30 A No circuit
13 AHC 50 A 4-Wheel AHC
14 PTC-1 50 A PTC heater
15 PTC-2 50 A PTC heater
16 PTC-3 50 A PTC heater
17 RH-J/B 50 A RH-J/B
18 SUB BATT 40 A Towing
19 VGRS 40 A VGRS ECU
20 H-LP CLN 30 A Headlight cleaner
21 DEFOG 30 A Rear window defogger
22 SUB-R/B 100 A SUB-R/B
23 HTR 50 A Front air conditioning system
24 PBD 30 A Power back door ECU
25 LH-J/B 150 A LH-J/B
26 ALT 180 A Alternator
27 A/PUMP NO.1 50 A AI DRIVER
28 A/PUMP NO.2 50 A AI DRIVER 2
29 MAIN 40 A Headlight, daytime running light sys-
tem, HEAD LL, HEAD RL, HEAD LH,
HEAD RHFuse Ampere Circuit

7954-3. Do-it-yourself maintenance
4
Maintenance and care
LX570_OM_OM60L96U_(U) ■ Engine compartment (fuse box on the right side)
Fuse Ampere Circuit
1 HWD1 30 A No circuit
2 TOW BRK 30 A Brake controller
3 RR P/SEAT 30 A Power second seat
4 PWR HTR 7.5 A No circuit
5 DEICER 20 A Windshield wiper de-icer
6 ALT-CDS 10 A ALT-CDS
7 SECURITY 5 A SECURITY
8 SEAT A/C RH 25 A Seat heaters and ventilators
9 AI PMP HTR 10 A AI pump heater
10 TOW TAIL 30 A Towing tail light system
11 HWD2 30 A No circuit

7974-3. Do-it-yourself maintenance
4
Maintenance and care
LX570_OM_OM60L96U_(U) 4 PANEL 10 A Ashtray, brake controller, cigarette
lighter, cool box, center differential
lock, driving mode switches, multi-
information display, air conditioning
system, glove box light, audio system,
emergency flashers, headlight cleaner
switch, driving position memory but-
tons, outside rear view mirror
switches, overhead module, roll sens-
ing of curtain shield airbags off switch,
rear heater panel, shift lever switch,
power back door main switch, camera
switch, VSC OFF switch, steering
switch, console switch, instrument
panel light control
5 ECU-IG No.2 10 A Air conditioning system, rear heater
panel, overhead module, ABS, VSC,
steering sensor, yaw rate & G sensor,
main body ECU, stoplights, moon
roof, anti-glare inside rear view mirror
6 WINCH 5 A No circuit
7 A/C IG 10 A Cool box, condenser fan, cooler com-
pressor, rear window and outside rear
view mirror defoggers, smog sensor
8 TAIL 15 A Tail lights, license plate lights, front fog
lights, parking lights, side marker
lightsFuse Ampere Circuit

7984-3. Do-it-yourself maintenance
LX570_OM_OM60L96U_(U) 9 WIPER 30 A Windshield wiper
10 WSH 20 A Windshield washer
11 RR WIPER 15 A Rear window wiper and washer
12 4WD 20 A Four-wheel drive system
13 LH-IG 5 A Alternator, towing, seat heater and
ventilators, windshield wiper de-icer,
front seat belt, emergency flasher,
inverter switch, shift lever switch
14 ECU-IG No.1 5 A ABS, VSC, tilt and telescopic steer-
ing, gateway ECU, shift lock system,
parking assist system, cruise control
switch, pre-collision system, headlight
cleaner, multi-display assembly, rain-
sensing windshield wiper, driving
position memory system, power door
lock system
15 S/ROOF 25 A Moon roof
16 RR DOOR RH 20 A Power windows
17 MIR 15 A Mirror ECU, outside rear view mirror
defoggers
18 RR DOOR LH 20 A Power windows
19 FR DOOR LH 20 A Power windows
20 FR DOOR RH 20 A Power windowsFuse Ampere Circuit

8014-3. Do-it-yourself maintenance
4
Maintenance and care
LX570_OM_OM60L96U_(U) Fuse Ampere Circuit
11 SEAT-A/C FAN 10 A Ventilators
12 SEAT-HTR 20 A Seat heaters
13 AFS 5 A Adaptive Front-lighting System
14 ECU-IG No.3 5 A Adaptive Front-lighting System,
dynamic radar cruise control system
15 STRG HTR 10 A Heated steering wheel
16 TV 10 A Multi-display assembly■
After a fuse is replaced ●
If the lights do not turn on even after the fuse has been replaced, a bulb may
need replacement. (  P. 803)●
If the replaced fuse blows again, have the vehicle inspected by your Lexus
dealer.■
If there is an overload in the circuits
The fuses are designed to blow, protec ting the wiring harness from damage.

9066-1. Specifications
LX570_OM_OM60L96U_(U) Warning: The temperature grades of a tire assume that it is properly inflated
and not overloaded.
Excessive speed, underinflation, or exce ssive loading, either separately or
in combination, can cause heat bu ildup and possible tire failure.
Glossary of tire terminology Tire related term Meaning
Cold tire inflation
pressure Tire pressure when the vehicle has been parked for
three hours or more, or ha s not been driven more
than 1 mile or 1.5 km under that condition
Maximum inflation pres-
sure The maximum cold inflated pressure to which a tire
may be inflated, shown on the sidewall of the tire
Recommended inflation
pressure Cold tire inflation pressure recommended by a manu-
facturer
Accessory weight The combined weight (in excess of those standard
items which may be replaced) of automatic transmis-
sion, power steering, power brakes, power windows,
power seats, radio and heater, to the extent that these
items are available as f actory-installed equipment
(whether installed or not)
Curb weight The weight of a motor vehi cle with standard equip-
ment, including the maximum capacity of fuel, oil and
coolant, and if so equipped, air conditioning and addi-
tional weight optional engine
Maximum loaded
vehicle weight The sum of:
(a) Curb weight
(b) Accessory weight
(c) Vehicle capacity weight
(d) Production options weight
Normal occupant weight 150 lb. (68 kg) times the nu mber of occupants speci-
fied in the second column of Table 1
* that follows
Occupant distribution Distribution of occupants in a vehicle as specified in
the third column of Table 1
* below
