2015 Lexus IS250 tow

4638-2. Steps to take in an emergency
8
When trouble arises
IS350/250_U (OM53C50U)
CAUTION
■While towing
●When towing using a cables or chains, avoid sudden starts, etc. which place excessive
stress on the towing eyelets, cables or chains. The towing eyelets, cables or chains
may become damaged, broken debris ma y hit people and cause serious damage.
●Do not turn the engine switch off.
There is a possibility that the steering wheel is locked and cannot be operated.
■Installing towing eyelet to the vehicle
Make sure that towing eyelet is installed securely.
If not securely installed, towing ey elet may come loose during towing.
NOTICE
■To prevent damage to the vehicle when towing using a wheel-lift type truck (2WD
models)
●Do not tow the vehicle from the rear when the engine switch is off. The steering lock
mechanism is not strong enough to hold the front wheels straight.
●When raising the vehicle from the rear, en sure adequate ground clearance for towing
at the opposite end of the raised vehicle. Without adequate clearance, the vehicle
could be damaged while being towed from the rear.
■To prevent damage to the vehicle when towing using a wheel-lift type truck (AWD
models)
When raising the vehicle, ensure adequate ground clearance for towing at the oppo-
site end of the raised vehicle. Without adequate clearance, the vehicle could be dam-
aged while being towed.
■To prevent body damage when to wing with a sling-type truck
Do not tow with a sling-type truck, either from the front or rear.

4878-2. Steps to take in an emergency
8
When trouble arises
IS350/250_U (OM53C50U)
Location of the spare tire, jack and tools
Jack handle
Screwdriver
Wheel nut wrenchTowing eyelet
Spare tire
Jack1
2
3
4
5
6

4938-2. Steps to take in an emergency
8
When trouble arises
IS350/250_U (OM53C50U)
Remove any dirt or foreign matter
from the wheel contact surface.
If foreign matter is on the wheel contact
surface, the wheel nuts may loosen
while the vehicle is in motion, causing
the tire to come off.
Install the spare tire and loosely tighten each wheel nut by hand by approxi-
mately the same amount.
When replacing an aluminum wheel
with a steel wheel, tighten the wheel
nuts until the tapered portion comes
into loose contact with the disc
wheel seat.
Lower the vehicle.
Firmly tighten each wheel nut two or
three times in the order shown in the
illustration.
Tightening torque:
76 ft•lbf (103 N•m, 10.5 kgf•m)
Stow the flat tire, tire jack and all tools.
Installing the spare tire
1
2
Tapered portionDisc wheel
seat
3
4
5

5108-2. Steps to take in an emergency
IS350/250_U (OM53C50U)
CAUTION
■When attempting to free a stuck vehicle
If you choose to push the vehicle back and forth to free it, make sure the surrounding
area is clear to avoid striking other vehicles, objects or people. The vehicle may also
lunge forward or lunge back suddenly as it becomes free. Use extreme caution.
■When shifting the shift lever
Be careful not to shift the shift lever with the accelerator pedal depressed.
This may lead to unexpected rapid accelerati on of the vehicle that may cause an acci-
dent resulting in death or serious injury.
NOTICE
■To avoid damaging the transmission and other components
●Avoid spinning the rear wheels and depressing the accelerator pedal more than nec-
essary.
●If the vehicle remains stuck even after th ese procedures are performed, the vehicle
may require towing to be freed.

568Alphabetical index
IS350/250_U (OM53C50U)
Daytime running light system ............ 174
DefoggerFront windshield .................................362
Outside rear view mirrors .............362
Rear window ........................................362
Differential Front differential ................................... 517
Rear differential .................................... 517
Dimension .................................................512
Dinghy towing......................................... 158
Display Drive information .................................. 87
Dynamic radar cruise control....... 196
LDA (Lane Departure Alert) ...... 209
Multi-information display ..................86
Warning message ............................. 472
Distance ...................................................... 88
Do-it-yourself maintenance ............. 409
Door courtesy lights Location ................................................. 368
Wattage ................................................... 521 Doors ..........................................................103
Automatic door locking and unlocking system ................... 106
Door glasses ......................................... 138
Door lock................................................ 105
Open door warning buzzer ..........104
Open door warning light .............. 467
Outside rear view mirrors ..............135
Rear door child-protector ............. 106
Drive information .....................................87
Drive info 1/Drive info 2 ....................... 88
Driver’s seat position memory.......... 123
Driving ........................................................ 146 Break-in tips ........................................... 147
Correct driving posture .................... 28
Driving mode select switch ...........237
Procedures .............................................146
Winter drive tips ................................ 260
Dynamic radar cruise control ........... 196
D

569Alphabetical index
IS350/250_U (OM53C50U)
E-mail......................................................... 327
Eco drive mode ..................................... 237
Eco Driving Indicator............................. 90
Eco Driving Indicator Light ................. 88
EDR (Event data recorder) ...................10
Elapsed time .............................................. 87
Electric Power Steering (EPS) .........241Function ....................................................241
Warning light ....................................... 467
Electronic key ........................................... 98 Battery-saving function ...................... 115
If the electronic key does not operate properly............................ 499
Replacing the battery .......................439 Emergency, in case of
If the electronic key does not operate properly ........ 499
If the engine will not start ............... 496
If the shift lever cannot be shifted from P ............498
If the vehicle battery is discharged.........................................502
If the warning buzzer sounds ................................................. 466
If the warning light turns on .......... 466
If the warning message is displayed .........................................472
If you have a flat tire ..........................486
If you think something is wrong .............................................. 464
If your vehicle becomes stuck..................................................... 509
If your vehicle has to be stopped in an emergency.......... 457
If your vehicle needs to be towed .......................................458
If your vehicle overheats ............... 506
E

581Alphabetical index
IS350/250_U (OM53C50U)
Tools........................................................... 487
Top tether strap........................................ 65
Total load capacity .................................156
TowingDinghy towing ...................................... 158
Emergency towing........................... 458
Towing eyelet........................................ 461
Trailer towing ........................................ 157
TRAC (Traction Control) ................. 240
Transmission.............................................164 Automatic transmission ................... 164
Driving mode select switch .......... 237
If the shift lever cannot be shifted from P .................................. 498
M mode ....................................................167
Paddle shift switches ......................... 166
Trip meters ...................................................81 Trunk ...........................................................109
Internal trunk release lever ................ 111
Luggage security system.................. 110
Smart access system with push-button start................... 109
Trunk features...................................... 374
Trunk handle ........................................... 110
Trunk light................................................... 111
Trunk opener main switch ............... 110
Trunk opener switch ......................... 109
Wireless remote control................. 109
Trunk light..................................................... 111 Wattage ................................................... 521
Turn signal lights ..................................... 170 Replacing light bulbs ................ 446, 448, 449, 452
Turn signal lever ...................................170
Wattage ................................................... 521
*: For vehicles with a navigation system, refer to the
“NAVIGATION SYSTEM OWNER’S MANUAL”.
