2015 Lexus IS200t USB

3265-2. Setup
IS200t_EE(OM53D19E)
→ “Setup” → “General” → “Delete personal data”
Select “Delete”.
Check carefully beforehand, as data cannot be retrieved once deleted.
The following personal data will be deleted or changed to its default settings.
•Phonebook data
•Voice tag
• Call history data
•Favorite data
• Bluetooth
® devices data
• Phone sound settings
• Detailed Bluetooth
® settings
• Audio/video setting
• Preset switch data
• Last used radio station
• Customized image data
•FM info setting
• iPod tagging information
• Software update history
• Software update detail information
• Phone display setting
• Contact/call history setting
• Messaging setting
NOTICE
■If the console box lid cannot be fully closed
→ P. 3 5 4
■To prevent damage to the USB memory device or its terminals
→P. 3 5 4
Deleting personal data
1
2

3315-3. Using the audio system
5
Lexus Display Audio system
IS200t_EE(OM53D19E)
Go to “Audio settings”: → “Setup” → “Audio”
Change sound settings
( → P. 3 3 0 )
Change FM radio settings
( → P. 3 3 2 )
Change DAB settings ( →P. 3 3 2 )
Change iPod settings ( →P. 333)
Change USB settings ( →P. 333)
Change A/V settings ( →P. 3 3 4 )
Change the cover art settings ( →P. 3 3 4 )
Audio settings
Screen for audio settings
1
2
3
4
5
6
7

3335-3. Using the audio system
5
Lexus Display Audio system
IS200t_EE(OM53D19E)
Change the screen size (video
mode)
Change the cover art settings
(→ P. 3 3 4 )
Adjust the screen quality (video
mode) ( →P. 3 2 8 )
Change video so und input port
Change the screen size (video
mode)
Change the cover art settings
( → P. 3 3 4 )
Adjust the screen quality (video
mode) ( →P. 3 2 8 )
Changing iPod settings
1
2
3
4
Changing USB settings
1
2
3

3345-3. Using the audio system
IS200t_EE(OM53D19E)
Change the screen size
Change the video signal
Adjust the screen quality (→P. 3 2 8 )
Select to set the cover art display of
DISC mode on/off.
Select to set the cover art display of
USB mode on/off.
Change the priority of the cover art
display for USB mode.
Select to set the cover art display of
iPod mode on/off.
Change the priority of the cover art display for iPod mode.
Changing A/V settings
1
2
3
Changing the cover art settings
1
2
3
4
5

3365-3. Using the audio system
IS200t_EE(OM53D19E)
XCD, MP3/WMA/AAC disc, USB, Bluetooth® or iPod
Play or pause a track/file/song
Select a track/file/song
Select a folder/album (MP3/
WMA/AAC disc or USB)
Select and hold: Fast-forward or
reverse a track/file/song
Select a repeat mode. ( →P. 3 3 7 )
Select a random/shuffle play
mode. ( →P. 3 3 7 )
Select the full screen mode. (USB
video or iPod video mode)
Change USB settings (USB)
( → P. 333)
Change iPod settings (iPod)
( → P. 333)
Connect a Bluetooth
® device (Bluetooth®) ( → P. 3 5 9 )
Change the cover art settings (CD or MP3/WMA/AAC disc) ( →P. 3 3 4 )
XAUX or A/V
Select the full screen mode (A/V)
Change A/V settings (A/V)
(→ P. 3 3 4 )
1
2
3
4
5
6
7
8
9
10
11
1
2

3375-3. Using the audio system
5
Lexus Display Audio system
IS200t_EE(OM53D19E)
Repeat play
ModeActionTa r g e t a u d i o s o u r c e
File/track/song repeat All media
Folder repeat MP3 /WMA/AAC disc, USB
Album repeat USB, Bluetooth
®
Random/shuffle playback
ModeActionTa r g e t a u d i o s o u r c e
Random/shuffle play of the disc/
folder/album All media
Random play of all folders MP3/WMA/AAC disc, USB
Random/shuffle play of all albums USB, iPod, Bluetooth
®

3505-6. Using an external device
IS200t_EE(OM53D19E)
→P. 3 2 1
Pressing the “MEDIA” button displays the USB top screen from any screen of the
selected source.
Moving the controller to the right and selecting “Play music” while the USB video
screen is displayed changes to USB audio mode.
■Menu screen
→ P. 3 3 5
■Selecting a file
Press the “ <” or “ >” button, turn the right side knob (left-hand drive vehicle) or
left side knob (right-hand drive vehicle) on the audio panel to select the
desired file number.
To fast-forward or rewind, press and hold the “ <” or “ >” button.
■Selecting a play mode
Move the controller to the right and select “Browse”.
Select the desired play mode, and select a file to begin the selected play
mode.
■Displaying the now playing list
Move the controller to the right and select “Now playing list”.
Using USB memory device
Connecting a USB memory device enables you to enjoy music from the vehi-
cle speakers.
Select “USB1” or “USB2” on the “Source” screen.
Connecting a USB memory device
USB top screen
USB audio
1
2

3515-6. Using an external device
5
Lexus Display Audio system
IS200t_EE(OM53D19E)
Moving the controller to the right and selecting “Play Video” while the USB
video screen is displayed changes to USB video mode.
This function cannot be used while USB photo or MirrorLink is in use.
■Menu screen
→ P. 3 3 5
■Selecting a file
Press the “ <” or “ >” button, turn the right side knob (left-hand drive vehicle) or
left side knob (right-hand drive vehicle) on the audio panel to select the
desired file number.
To fast-forward or reverse, press and hold the “ <” or “ >” button.
■Selecting a folder
Move the controller to the right and select “Browse”.
Select the desired folder, then select a file to begin using the selected
folder.
■Displaying the now playing list
Move the controller to the right and select “Now playing list”.
■USB memory functions
●Depending on the USB memory device that is connected to the system, the device
itself may not be operable and certain functions may not be available. If the device is
inoperable or a function is unavailable du e to a malfunction (as opposed to a system
specification), disconnecting the device and reconnecting it may resolve the problem.
●If the USB memory device still does not begin operation after being disconnected and
reconnected, format the device.
■Error messages for USB memory
■USB memory
●Compatible devices
USB memory devices that can be used for MP3, WMA and AAC (audio mode) or
MP4, WMV and AVI (video mode) playback.
USB video
MessageCause/Correction procedures
“Connection error.”This indicates a problem with the USB memory
device or its connection.
“There are no files available for
playback.”This indicates that no MP3/WMA/AAC files are
included on the USB memory device.
1
2
