GX 460 _O M_ OM6 0L 72U _( U)6-3. Do-it-yourself maintenance
Headlight aim
(
→ P. 4 8 8 )• Phillips-head screwdriver
Light bulbs
(→ P. 4 9 0 )
• Bulb with same number and wattage rating as original
• Phillips-head screwdriver•Flathead screwdriver
•Wrench
Power steering fluid
level ( →P. 4 6 3 )• Automatic transmission fluid DEXRON® II or III
• Rag or paper towel•Clean funnel
Radiator and con-
denser ( →P. 4 6 1 )
Tire inflation pres-
sure ( →P. 4 7 5 )• Tire pressure gauge• Compressed air source
Wa s h e r f l u i d
(→ P. 4 6 7 )• Water or washer fluid containing antifreeze (for winter use)
• Funnel (used only for adding water or washer fluid)
ItemsParts and tools
GX460_OM_OM60L72U_(U).book Page 452 Friday, May 16, 2014 3:03 PM

490
GX 460 _O M_ OM6 0L 72U _( U)6-3. Do-it-yourself maintenance
Light bulbs
Check the wattage and color of the light bulb being replaced. (
→P. 5 7 1 )
→ P. 4 5 6
■Front
You may replace the following bulbs yourself. The difficulty level of replace-
ment varies depending on the bulb. If necessary bulb replacement seems diffi-
cult to perform, contact your Lexus dealer.
For more information about replacing other light bulbs, contact your Lexus
dealer.
Preparing for light bulb replacement
Removing the engine compartment covers
Bulb locations
Front turn signal light
Headlight high beam1
2
GX460_OM_OM60L72U_(U).book Page 490 Friday, May 16, 2014 3:03 PM

492
GX 460 _O M_ OM6 0L 72U _( U)6-3. Do-it-yourself maintenance
■Headlight high beams
Turn the cover counterclockwise.
Turn the bulb base counterclock-
wise.
Unplug the connector while pull-
ing the lock release.
Replacing light bulbs
1
2
3
GX460_OM_OM60L72U_(U).book Page 492 Friday, May 16, 2014 3:03 PM

GX 460 _O M_ OM6 0L 72U _( U)
4936-3. Do-it-yourself maintenance
6
Maintenance and care
Replace the light bulb, and install
the bulb base.
Align the 3 tabs on the light bulb with
the mounting, and insert.
Turn and secure the bulb base.
Shake the bulb base gently to check
that it is not loose, turn the headlights
on once and visually confirm that no
light is leaking through the mounting.
When installing the cover, conduct in reverse.
4
5
61
GX460_OM_OM60L72U_(U).book Page 493 Friday, May 16, 2014 3:03 PM

498
GX 460 _O M_ OM6 0L 72U _( U)6-3. Do-it-yourself maintenance
■Running board lights
Turn the bulb bases counter-
clockwise.
Remove the light bulb.
When installing, reverse the steps listed.
■Replacing the following bulbs
If any of the lights listed below has burnt out, have it replaced by your Lexus
dealer.
●Headlight low beams
●Parking lights/daytime running lights
●Front side marker lights
●Fog lights (if equipped)
●Side turn signal lights
●High mounted stoplight
●Stop/tail lights
●License plate lights
1
2
3
GX460_OM_OM60L72U_(U).book Page 498 Friday, May 16, 2014 3:03 PM
