GX460_Navi_OM60L77U_(U)14.05.27 10:31
1. REAR SEAT ENTERTAINMENT SYSTEM FEATURES .......................... 227
DISPLAY .................................................................... 228
REAR SEAT ENTERTAINMENT
SYSTEM CONTROLLER .............................. 228
HEADPHONE JACKS ........................................ 229
HEADPHONES ..................................................... 230
CAUTION SCREEN............................................ 230
TURNING THE REAR DISPLAY ON/OFF ................................................................. 230
CHANGING THE DISPLAY TO BE OPERATED .......................................................... 230
TURNING THE REAR DISPLAY OFF USING THE REMOTE
CONTROLLER..................................................... 231
CHANGING THE SOURCE ............................ 231
CHANGING THE SPEAKER OUTPUT.................................................................. 232
OPERATION FROM THE FRONT SEATS ..................................................... 234
USING THE RADIO............................................. 235
USING THE RADIO (INTERNET RADIO BROADCAST) ..................................................... 237
PLAYING AN AUDIO CD/CD TEXT .......................................................................... 237
PLAYING MP3/WMA/AAC DISCS ....................................................................... 238
PLAYING DVD VIDEO ..................................... 239
PLAYING A USB MEMORY .......................... 245
PLAYING iPod......................................................... 246 PLAYING Bluetooth
® AUDIO ....................... 248
USING THE AUX MODE ................................. 249
USING THE VIDEO MODE ............................ 249
CHANGING SETTINGS..................................... 251
IF THE REAR SEAT ENTERTAINMENT SYSTEM MALFUNCTIONS ........................ 254
1. STEERING SWITCHES ........................ 255
1. AUDIO SETTINGS ................................. 258
AUDIO SETTINGS SCREEN .......................... 258
1. OPERATING INFORMATION......... 266
RADIO......................................................................... 266
DVD PLAYER AND DISC ................................ 268
iPod................................................................................. 273
FILE INFORMATION ........................................... 274
TERMS .......................................................................... 276
ERROR MESSAGES............................................ 278
4REAR SEAT ENTERTAINMENT
SYSTEM OPERATION
5AUDIO/VISUAL REMOTE
CONTROLS
6SETUP
7TIPS FOR OPERATING THE
AUDIO/VISUAL SYSTEM
GX_Navi_OM60L77U_(U).book Page 157 Monday, June 2, 2014 10:49 AM

201
3. MEDIA OPERATION
GX460_Navi_OM60L77U_(U)14.06.02 10:48
4
AUDIO/VISUAL SYSTEM
XVehicles with rear seat entertainment
system
zFront passengers can cancel this setup
operation by touching “Play”. The player
will resume normal play.
z Likewise, a rear passenger can cancel a
front passenger’s sele ction of the setup
menu.
z To lock the rear seat entertainment system,
see “OPERATION FROM THE FRONT
SEATS” on page 234.
SETUP OPERATION FROM
THE REAR SEAT
This screen appears when a rear pas-
senger selects the setup menu.
GX_Navi_OM60L77U_(U).book Page 201 Monday, June 2, 2014 10:49 AM

234
4. REAR SEAT ENTERTAINMENT SYSTEM OPERATION
GX460_Navi_OM60L77U_(U)14.06.02 10:48
1Press the “A U D I O ” button.
2Select “Source” .
3Select “Rear”.
4Select the desired button.
zThe selected button indicator is high-
lighted.
OPERATION FROM THE
FRONT SEATS
The rear seat display can be operated
from the front seats.
No.Function
Turns the rear screen on or off.
Locks the system so passengers in
the rear seats cannot operate the
rear entertainment system.
When the “Speaker Output” is
turned on, the rear seat entertain-
ment system can be operated in link
with front audio/visual system.
(→ P.235)
GX_Navi_OM60L77U_(U).book Page 234 Monday, June 2, 2014 10:49 AM

235
4. REAR SEAT ENTERTAINMENT SYSTEM OPERATION
GX460_Navi_OM60L77U_(U)14.06.02 10:48
4
AUDIO/VISUAL SYSTEM
1Select “Speaker Output” .
2Select “Right” or “Left” .
“Right” : Link with the mode of right side
display
“Left” : Link with the mode of left side dis-
play
1Display the audio source selection
screen. ( →P.231)
2Select “A M ”, “FM” or “SAT” .
■CONTROL SCREEN
CHANGING THE SPEAKER
OUTPUTUSING THE RADIO
When a different audio source is select-
ed at the front seats, radio mode cannot
be selected at the rear seats.
No.FunctionPage
Select to display the
cache radio operation
screen.236
GX_Navi_OM60L77U_(U).book Page 235 Monday, June 2, 2014 10:49 AM

245
4. REAR SEAT ENTERTAINMENT SYSTEM OPERATION
GX460_Navi_OM60L77U_(U)14.06.02 10:48
4
AUDIO/VISUAL SYSTEM
■SETUP OPERATION FROM THE
FRONT SEAT
z Rear passengers can cancel this setup
operation by selecting “Play”. The player
will resume normal play.
z Likewise, a front passenger can cancel a
rear passenger’s selection of the setup
menu.
1Connect a USB memory. ( →P.163)
2Display the audio source selection
screen. ( →P.231)
3Select “USB”.
■CONTROL SCREEN
This screen appears when a front pas-
senger selects the setup menu.
PLAYING A USB MEMORY
When a different audio source is select-
ed at the front seats, USB mode cannot
be selected at the rear seats.
No.Function
Select to set repeat playback.
Select to set random playback.
GX_Navi_OM60L77U_(U).book Page 245 Monday, June 2, 2014 10:49 AM

246
4. REAR SEAT ENTERTAINMENT SYSTEM OPERATION
GX460_Navi_OM60L77U_(U)14.06.02 10:48
■CONTROLLER
1Connect iPod. ( →P.163)
2Display the audio source selection
screen. ( →P.231)
3Select “iPod (DEVICE NAME)” .
■CONTROL SCREEN
No.Function
Press to select a folder/album.
Press to play/pause.
Press to fast forward/rewind.
z Press to select a file/track.
z Press and hold to fast forward/
rewind.
INFORMATION
●
Depending on the USB memory that is
connected to the system, certain
functions may not be available.
PLAYING iPod
When a different audio source is select-
ed at the front seats, iPod mode cannot
be selected at the rear seats.
iPod AUDIO
No.Function
Select to set repeat playback.
Select to set random playback.
Select to display the iPod video con-
trol screen.
GX_Navi_OM60L77U_(U).book Page 246 Monday, June 2, 2014 10:49 AM

247
4. REAR SEAT ENTERTAINMENT SYSTEM OPERATION
GX460_Navi_OM60L77U_(U)14.06.02 10:48
4
AUDIO/VISUAL SYSTEM
■CONTROLLER ■CONTROL SCREEN
z Select “iPod (DEVICE NAME)” to display
full screen video.
z Press the “SOURCE” button and the sys-
tem will return to the iPod video control
screen.
No.Function
Press to play/pause.
Press to fast forward/rewind.
z Press to select a track.
z Press and hold to fast forward/
rewind.
iPod VIDEO
If iPod mode is selected again at the rear
seats when iPod video is being displayed
in the front monitor, iPod video can be
displayed.
No.Function
Select to display the iPod audio con-
trol screen.
GX_Navi_OM60L77U_(U).book Page 247 Monday, June 2, 2014 10:49 AM

248
4. REAR SEAT ENTERTAINMENT SYSTEM OPERATION
GX460_Navi_OM60L77U_(U)14.06.02 10:48
■CONTROLLER
1Display the audio source selection
screen. ( →P.231)
2Select “Bluetooth*” .
■CONTROL SCREEN
*: Bluetooth is a registered trademark of
Bluetooth SIG, Inc.
No.Function
Press to play/pause.
Press to fast forward/rewind.
zPress to select a file.
z Press and hold to fast forward/
rewind.
INFORMATION
●
Depending on the iPod that is connected
to the system, certain functions may not
be available.
PLAYING Bluetooth® AUDIO
When a different audio source is select-
ed at the front seats, Bluetooth
® audio
mode cannot be selected at the rear
seats.
No.Function
Select to set repeat playback.
Select to set random playback.
