2015 Lexus GX460 audio

215
3. MEDIA OPERATION
GX460_Navi_OM60L77U_(U)14.06.02 10:48
4
AUDIO/VISUAL SYSTEM
■CONTROL SCREEN
■ CONTROL PANEL
GX_Navi_OM60L77U_(U).book Page 215 Monday, June 2, 2014 10:49 AM

216
3. MEDIA OPERATION
GX460_Navi_OM60L77U_(U)14.06.02 10:48
No.Function
Select to select an album.
Displays Bluetooth® device condition
Select to display the audio source selection screen.
Select to display the portable device connection screen.
•Displays cover art
• Select to display a track list.
To return to the top screen, select “Now Playing” on the list screen.
Select to display the playlist screen.
To return to the top screen, select “Now Playing” on the list screen.
Select to display the sound settings screen.
Select to set random playback.
Select to set repeat playback.
Shows progress
Select to play.
Select to pause.
•Turn to select a track/file.
• Turn to move the cursor up/down on the list.
• Press to select the list.
•Press to select a track/file.
• Press and hold to fast forward/rewind.
• Press to select the list.
•Turn to adjust volume.
• Press to turn the audio system on/off.
• Press and hold to restart the audio system.
GX_Navi_OM60L77U_(U).book Page 216 Monday, June 2, 2014 10:49 AM

217
3. MEDIA OPERATION
GX460_Navi_OM60L77U_(U)14.06.02 10:48
4
AUDIO/VISUAL SYSTEM
CAUTION
●Do not operate the player’s controls or connect to the Bluetooth® audio system while driv-
ing.
●Your audio unit is fitted with Bluetooth® antennas. People with implantable cardiac pace-
makers, cardiac resynchronization therapy-pacemakers or implantable cardioverter
defibrillators should mainta in a reasonable distance between themselves and the
Bluetooth
® antennas. The radio waves may affect the operation of such devices.
●Before using Bluetooth® devices, users of any electrical medical device other than implant-
able cardiac pacemakers, cardiac resynchron ization therapy-pacemakers or implantable
cardioverter defibrillators should consult the manufacturer of the device for information
about its operation under the influence of ra dio waves. Radio waves could have unexpected
effects on the operation of such medical devices.
NOTICE
●Do not leave your portable player in the vehicl e. In particular, high temperatures inside the
vehicle may damage the portable player.
GX_Navi_OM60L77U_(U).book Page 217 Monday, June 2, 2014 10:49 AM

218
3. MEDIA OPERATION
GX460_Navi_OM60L77U_(U)14.06.02 10:48
INFORMATION
●
Depending on the Bluetooth® device that is connected to the system, the music may start
playing when selecting while it is pa used. Conversely, the music may pause when
selecting while it is playing.
●In the following conditions, the system may not function:
•The Bluetooth
® device is turned off.
•The Bluetooth
® device is not connected.
•The Bluetooth
® device has a low battery.
●It may take time to connect the phone when Bluetooth® audio is being played.
●For operating the portable player, see the instruction manual that comes with it.
●If the Bluetooth® device is disconnected due to poor reception from the Bluetooth® net-
work when the engine switch is in ACCESSORY or IGNITION ON mode, the system
automatically reconnects the portable player.
●If the Bluetooth® device is disconnected on purpose, such as it was turned off, this does not
happen. Reconnect the portable player manually.
●Bluetooth® device information is registered when the Bluetooth® device is connected to
the Bluetooth® audio system. When selling or disp osing of the vehicle, remove the
Bluetooth® audio information from the system. ( →P. 6 1 )
GX_Navi_OM60L77U_(U).book Page 218 Monday, June 2, 2014 10:49 AM

219
3. MEDIA OPERATION
GX460_Navi_OM60L77U_(U)14.06.02 10:48
4
AUDIO/VISUAL SYSTEM
XRegistering an additional device
1Select “Connect” on the Bluetooth®
audio control screen.
2For more information: →P.46
X Selecting a registered device
1Select “Connect” on the Bluetooth®
audio control screen.
2For more information: →P.48
1Select .
zEach time is selected, the mode
changes as follows:
• track repeat
→ album repeat → off
CONNECTING A Bluetooth®
DEVICE
To use the Bluetooth® audio system, it is
necessary to register a Bluetooth
® de-
vice with the system.
LISTENING TO Bluetooth®
AUDIO
REPEATING
The track or album currently being lis-
tened to can be repeated.
INFORMATION
●
Each time is selected, “RPT”/
“ALB.RPT” appears on the screen.
GX_Navi_OM60L77U_(U).book Page 219 Monday, June 2, 2014 10:49 AM

221
3. MEDIA OPERATION
GX460_Navi_OM60L77U_(U)14.06.02 10:48
4
AUDIO/VISUAL SYSTEM
6. AUX
■CONTROL SCREEN
OVERVIEW
The AUX operation screen can be reached by the following methods:
X Connecting a device to the AUX port ( →P.163)
Press the “A U D I O ” button to display the audio control screen.
Select “Source” and select “A U X ”.
GX_Navi_OM60L77U_(U).book Page 221 Monday, June 2, 2014 10:49 AM

222
3. MEDIA OPERATION
GX460_Navi_OM60L77U_(U)14.06.02 10:48
■CONTROL PANEL
No.Function
Select to display the audio source selection screen.
Select to display the sound setting screen.
•Turn to adjust volume.
• Press to turn the audio system on/off.
• Press and hold to restart the audio system.
GX_Navi_OM60L77U_(U).book Page 222 Monday, June 2, 2014 10:49 AM

223
3. MEDIA OPERATION
GX460_Navi_OM60L77U_(U)14.06.02 10:48
4
AUDIO/VISUAL SYSTEM
CAUTION
●Do not connect portable audio device or operate the controls while driving.
NOTICE
●Depending on the size and shape of the portable audio device that is connected to the sys-
tem, the lid may not close fully. In this case, do not forcibly close the lid as this may damage
the portable audio device or the terminal, etc.
●Do not leave portable audio device in the vehicle. The temperature inside the vehicle may
become high, resulting in damage to the player.
●Do not push down on or apply unnecessary pressure to the portable audio device while it is
connected as this may damage the portable audio device or its terminal.
●Do not insert foreign objects into the port as this may damage the portable audio device or
its terminal.
GX_Navi_OM60L77U_(U).book Page 223 Monday, June 2, 2014 10:49 AM
