GX460_OM_OM60L72U_(U)
4996-3. Do-it-yourself maintenance
6
Maintenance and care
■LED lights
The headlight low beams, parking lights/daytime running light s, front side marker lights,
fog lights, side turn signal lights, high moun ted stoplight, stop/tail lights and license plate
lights consist of a number of LEDs. If any of the LEDs burn out, take your vehicle to your
Lexus dealer to have the light replaced.
■Condensation build-up on the inside of the lens
Temporary condensation build-up on the inside of the headlight lens does not indicate a
malfunction. Contact your Lexus dealer for mo re information in the following situations:
●Large drops of water are built up on the inside of the lens.
●Wa t e r h a s b u i l t u p i nside the headlight.
CAUTION
■Replacing light bulbs
●Turn off the headlights. Do not attempt to replace the bulb immediately after turning
off the headlights.
The bulbs become very hot and may cause burns.
●Do not touch the glass portion of the light bulb with bare hands. When it is unavoid-
able to hold the glass portion, use and ho ld with a clean dry cloth to avoid getting
moisture and oils on the bulb.
Also, if the bulb is scratched or dropped, it may blow out or crack.
●Fully install light bulbs and any parts used to secure them. Failure to do so may result
in heat damage, fire, or water entering the headlight unit. This may damage the head-
lights or cause condensation to build up on the lens.
●Do not attempt to repair or disassemble light bulbs, connectors, electric circuits or
component parts.
Doing so may result in death or se rious injury due to electric shock.
■To prevent damage or fire
●Make sure bulbs are fully seated and locked.
●Check the wattage of the bulb before installin g to prevent heat damage.

GX460_OM_OM60L72U_(U)
5718-1. Specifications
8
Vehicle specifications
Light bulbs
Light bulbsBulb No.WTy p e
Exterior
Headlights (High beam)970365A
Front turn signal lights21B
Rear turn signal lights21B
Back-up lights92116C
Rear side marker lights5C
Running board lights5C
Interior
Pe r s o n a l /
Interior lightsFront5C
Rear5C
Va n i t y l i g h t s8C
Door courtesy lights5C
A: H9 halogen bulbsB: Wedge base bulb (amber) C: Wedge base bulb (clear)

618Alphabetical index
GX460_OM_OM60L72U_(U)
Alphabetical index
A/C ................................................ 380, 390Air conditioning filter......................... 481
ABS (Anti-lock Brake System)....... 345 Function ..................................................345
Warning light .......................................... 511
Active Traction Control .................... 346
Air conditioning filter ........................... 481
Air conditioning system ......... 380, 390 Air conditioning filter......................... 481
Micro dust and pollen filter .......... 385
Airbags ........................................................ 34 Airbag operating conditions ........... 42
Airbag precautions for your child........................................ 37
Airbag warning light ............................ 511
Correct driving posture .................... 26
Curtain shield airbag operating conditions........................ 42
Curtain shield airbag precautions ........................................... 37
General airbag precautions............ 37
Locations of airbags ............................ 34
Modification and disposal of airbags ..............................41
Side airbag operating conditions .............................................. 42
Side airbag precautions..................... 37
Side and curtain shield airbags operating conditions........................ 42
Side and curtain shield airbags precautions ........................................... 37
SRS airbags.............................................. 34
SRS warning light.................................. 511
Alarm Alarm........................................................... 70
Warning buzzer .................................... 511 Anchor brackets....................................... 57
Antennas (smart access system
with push-button start) ........................ 111
Anti-lock brake system (ABS) ..................................................... 345 Function .................................................. 345
Warning light .......................................... 511
Armrest ...................................................... 421
Assist grip .................................................422
Audio input
*
Audio system*
Automatic headlight leveling system .....................................198
Automatic High Beam ......................... 199
Automatic light control system ........ 196
Automatic transmission.......................190 If the shift lever cannot be shifted from P ...................................548
S mode...................................................... 192
AUX port
*
Auxiliary boxes ..................................... 404
AVS ........................................................... 335
Back door ................................................... 101
Back-up lights Replacing light bulbs ....................... 497
Wattage ................................................... 571
Battery .......................................................464 Battery checking ................................ 464
If the vehicle battery is discharged......................................... 552
Preparing and checking before winter ...................................... 371
Warning light .......................................... 511
Bluetooth
®*
A
B

622Alphabetical index
GX460_OM_OM60L72U_(U)
Fuel ............................................................. 564Capacity ................................................ 564
Fuel gauge ................................................ 79
Fuel pump shut off system.............. 510
Information ............................................ 572
Refueling...................................................214
Type ............................................... 214, 564
Warning light ........................................ 513
Fuel consumption information ........... 88
Fuel filler door .......................................... 214 Refueling...................................................214
Fuel gauge ...................................................79
Fuel pump shut off system.................. 510
Fuses .......................................................... 485
Garage door opener ...........................427
Gauges .........................................................79
Glass hatch .............................................. 106
Glove box ................................................400
Hands-free system (for cellular phone)
*
Head restraints ........................................136
Headlights .................................................196 Light switch ............................................ 196
Replacing light bulbs ........................492
Wattage ................................................... 571
Headlights cleaner.................................213
Heaters Automatic air conditioning system .................................... 380, 390
Seat heaters ..........................................394
Outside rear view mirrors ............ 385 Height control ......................................... 331
Hill-start assist control ....................... 346
Hood ......................................................... 454
Hooks
Cargo hooks .......................... 406, 407
Coat hooks ............................................. 421
Retaining hooks (floor mat)..............24
Horn............................................................. 139
I/M test ..................................................... 450
Identification Engine ..................................................... 564
Vehicle ....................................................563
Ignition switch (engine switch) .........185
Ignition switch light .............................. 396
Illuminated entry system ................... 398
Immobilizer system ................................ 68
Indicators ..................................................... 74
Initialization Moon roof .............................................. 150
Power windows.................................... 147
Inside rear view mirror...........................141
Instrument panel light control ............ 80
Interior lights .......................................... 396 Switch ...................................................... 397
Wattage ................................................... 571
Jack Vehicle-equipped jack ................... 534
Jack handle ..............................................537
Jam protection function Moon roof .............................................. 150
Power windows.................................... 147
G
H
I
J

623Alphabetical index
GX460_OM_OM60L72U_(U)
Keyless entrySmart access system with push-button start ...................... 94, 101
Wireless remote control ................... 94
Keys............................................................... 90 Battery-saving function ...................... 113
Electronic key .........................................90
If the electronic key does not operate properly............................ 549
If you lose your keys .......................... 614
Key number plate .................................90
Keyless entry .................................. 94, 101
Mechanical key ........................................91
Replacing the battery ...................... 483
Wireless remote control ...................90
KDSS ......................................................... 346 Warning light ........................................ 512
Lane Departure Alert (LDA) .......... 232
Lever Auxiliary catch lever .........................454
Hood lock release lever .................454
Shift lever ................................................. 190
Turn signal lever .................................. 194
Wiper lever .......................................... 206
License plate lights.................................196 Light switch ............................................ 196 Light
Engine switch light ............................ 396
Fog light switch ................................... 204
Headlight switch ..................................196
Illuminated entry system.................398
Interior light........................................... 397
Interior light list .................................... 396
Personal light ....................................... 397
Replacing light bulbs .......................490
Turn signal lever ...................................194
Vanity lights ............................................415
Wattage ................................................... 571
Light bulbs Replacing ...............................................490
Wattage ................................................... 571
Lock steering column........................... 187
Luggage cover ...................................... 408
Maintenance Do-it-yourself maintenance ...........451
Maintenance data.............................. 562
Maintenance requirements .......... 444
Resetting the message indicating maintenance is
required .............................................. 445
Malfunction indicator lamp ................. 511
Master warning light ............................. 519
K
L
M
*:For vehicles with a navigation system or a multimedia system, refer to the
“NAVIGATION SYSTEM OWNER’S MANUAL” or “MULTIMEDIA OWNER’S MANUAL”.

626Alphabetical index
GX460_OM_OM60L72U_(U)
Seat heaters ............................................ 394
Seat ventilators ...................................... 395
Seat position memory............................ 131
Seats....................................................118, 120Adjustment .................................... 118, 120
Adjustment precau tions ......... 119, 130
Child seats/child restraint system installation.............................. 57
Cleaning .................................................. 441
Driving position memory .................. 131
Head restraint ....................................... 136
Properly sitting in the seat ................ 26
Seat position memory......................... 131
Ventilators ............................................ 395
Sensor Automatic headlight system .......... 198
Inside rear view mirror ......................142
Intuitive parking assist-sensor .................................... 238
Rain-sensing windshield wipers .................................................. 209
Service reminder indicators ................74
Shift lever Automatic transmission ................... 190
If the shift lever cannot be shifted from P .................................. 548
Shift lock system.................................... 548
Shopping bag hooks ........................... 407
Side airbags ............................................... 34
Side mirrors ..............................................143 Adjusting and folding........................ 143
Blind Spot Monitor............................. 351
Side turn signal lights ............................194 Replacing light bulbs ....................... 498
Turn signal lever .................................. 194 Smart access system with
push-button start.................................... 111 Antenna location..................................... 111
Starting the engine ............................. 185
Snow tires .................................................373
Spare tire ................................................. 533 Inflation pressure................................ 570
Storage location ................................. 534
Spark plug ............................................... 566
Specifications......................................... 562
Speedometer ............................................. 79
Steering lock Column lock release ........................ 188
Steering wheel ........................................ 139 Adjustment..............................................139
Audio switches
*
Heated steering wheel ................... 393
Steering wheel position memory...................................................131
Stop/tail lights Replacing light bulbs .......................498
Storage feature ..................................... 399
Stuck If the vehicle becomes stuck....... 558
Sun shade Roof ........................................................... 150
Sun visors................................................... 415
Switch “2nd START” button ........................... 191
AVS switch ........................................... 335
BSM (Blind Spot Monitor) switch .....................................................351
Center differential lock/ unlock switch.................................... 337
Crawl Control switch......................340
Cruise control switch ..............218, 221
“DAC” switch ...................................... 343

628Alphabetical index
GX460_OM_OM60L72U_(U)
Tools........................................................... 534
TowingDinghy towing ...................................... 184
Emergency towing........................... 506
Towing hooks ..................................... 507
Trailer Sway Control ........................346
Trailer towing ........................................ 166
Trailer Sway Control........................... 346
TRAC (Traction Control) ................. 345
Transmission Automatic transmission ................... 190
AVS switch .......................................... 335
If the shift lever cannot be shifted from P .................................. 548
Trip information........................................ 83
Trip meters ..................................................79
Turn signal lights .....................................194 Replacing light bulbs ........... 494, 495
Turn signal lever .................................. 194
Wattage ................................................... 571
USB port
*
Vanity lights Vanity lights ........................................... 415
Wattage ................................................... 571
Vanity mirrors ..........................................415
Vehicle identification number ......... 563
VSC (Vehicle Stability Control) .... 345 Warning buzzers .................................... 511
Brake system .......................................... 511
Downshifting ..........................................193
Open back door.................................. 521
Open door ............................................. 521
Seat belt remainder ............................514
Warning lights .......................................... 511 ABS ............................................................. 511
Automatic headlight leveling system .................................................... 512
Brake system .......................................... 511
Charging system .................................. 511
KDSS.......................................................... 512
LED headlight ....................................... 512
Low fuel level .........................................513
Malfunction indicator lamp.............. 511
Master warning light ..........................513
Open door .............................................513
Parking brake indicator ..................... 511
PCS ............................................................ 512
Seat belt reminder light ....................513
Slip indicator .......................................... 512
SRS............................................................... 511
Tire pressure warning light .............513
Warning message.................................. 519
Warning reflector holder.................. 406
Washer ..................................................... 206 Checking ............................................... 467
Preparing and checking before winter ...................................... 371
Switch ...................................................... 206
Washing and waxing .......................... 438
Wide view front & side monitor ..... 283
U
V
W
