2015 Lexus GX460 tow

3
1
8 7
6
5
4
3
2
GX460_OM_OM60L72U_(U)
9
4-1. Before driving Driving the vehicle ......................154
Cargo and luggage...................... 161
Vehicle load limits ........................165
Trailer towing (with towing hitch) ....................166
Dinghy towing .............................. 184
4-2. Driving procedures Engine (ign ition) switch ............ 185
Automatic transmission ........... 190
Turn signal lever ............................194
Parking brake ................................195
4-3. Operating the lights and wipers
Headlight switch ..........................196
Automatic High Beam.............. 199
Fog light switch ........................... 204
Windshield wipers and washer ......................................... 206
Rear window wiper and washer ............................................ 211
Headlight cleaner switch..........213
4-4. Refueling Opening the fuel tank cap .......214 4-5. Using the driving support
systems
Cruise control .............................. 218
Dynamic radar cruise control ........................................... 221
LDA (Lane Departure Alert)........ 232
Intuitive parking assist .............. 238
Rear view monitor system ....... 247
Lexus parking assist monitor.........................................257
Wide view front & side monitor........................................ 283
Multi-terrain Select................... 302
Multi-terrain Monitor............... 307
Rear height control air suspension ...................................331
AVS (Adaptive Variable Suspension System)............... 335
Four-wheel drive system ......... 336
Crawl Control ............................. 340
Downhill assist control system .......................................... 343
Driving assist systems .............. 345
BSM (Blind Spot Monitor).......351
• The Blind Spot Monitor function .................................... 356
• The Rear Cross Traffic Alert function ........................ 359
PCS (Pre-Collision system) .......... 362
4-6. Driving tips Winter driving tips ....................... 371
Off-road precautions ................ 374
4Driving

5
1
8 7
6
5
4
3
2
GX460_OM_OM60L72U_(U)
9
6-1. Maintenance and care Cleaning and protecting the vehicle exterior ................ 438
Cleaning and protecting the vehicle inte rior....................441
6-2. Maintenance Maintenance requirements ............................ 444
General maintenance...............447
Emission inspection and maintenance (I/M)
programs .................................... 450
6-3. Do-it-yourself maintenance Do-it-yourself service precautions.................................. 451
Hood ............................................... 454
Engine compartment ............... 455
Tires.................................................. 468
Tire inflation pressure ................475
Wheels ............................................479
Air conditioning filter ................ 481
Electronic key battery.............. 483
Checking and replacing fuses.............................................. 485
Headlight aim ..............................488
Light bulbs .................................... 490 7-1. Essential information
Emergency flashers .................. 502
If your vehicle has to be stopped in
an emergency .......................... 503
7-2. Steps to take in an emergency If your vehicle needs to be towed................................ 504
If you think something is wrong........................................... 509
Fuel pump shut off system ....... 510
If a warning light turns on or a warning buzzer
sounds ............................................ 511
If a warning message is displayed ......................................519
If you have a flat tire .................. 533
If the engine will not start ........ 546
If the shift lever cannot be shifted from P ........................... 548
If the electronic key does not operate properly ............. 549
If the vehicle battery is discharged ................................. 552
If your vehicle overheats ......... 555
If the vehicle becomes stuck ............................................. 558
6Maintenance and care7When trouble arises

16Pictorial index
GX460_OM_OM60L72U_(U)
■Instrument panel
Engine switch . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . P . 185
Starting the engine/changing the modes . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . P. 185
Emergency stop of the engine . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . P. 503
When the engine will not start . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .P. 546
Warning messages . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . P. 5 19
Shift lever . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . P. 190
Changing the shift position . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . P. 190
Precautions against towing . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . P. 504
When the shift lever does not move . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . P. 548
Meters . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . P. 79
Reading the meters/adjusting the instrument panel light . . . . . . . . . . . . . . . . . P. 79
Warning lights/indicators . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .P. 7 4
When the warning lights come on . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . P. 511
1
2
3

371-1. For safe use
GX460_OM_OM60L72U_(U)
1
For safety and security
Your vehicle is equipped with ADVANCED AIRBAGS designed based on the
US motor vehicle safety standards (FMVSS208). The airbag sensor assembly
(ECU) controls airbag deployment based on information obtained from the sen-
sors etc. shown in the system compon ents diagram above. This information
includes crash severity and occupant information. As the airbags deploy, a
chemical reaction in the inflators quickly fills the airbags with non-toxic gas to
help restrain the moti on of the occupants.
CAUTION
■SRS airbag precautions
Observe the following precautions regarding the SRS airbags.
Failure to do so may cause death or serious injury.
●The driver and all passengers in the vehicle must wear their seat belts properly.
The SRS airbags are supplemental device s to be used with the seat belts.
●The SRS driver airbag deploys with consider able force, and can cause death or seri-
ous injury especially if the driver is very close to the airbag. The National Highway
Traffic Safety Administration (NHTSA) advises:
Since the risk zone for the driver’s airbag is the first 2 - 3 in. (50 - 75 mm) of inflation,
placing yourself 10 in. (250 mm) from your driver airbag provides you with a clear
margin of safety. This distance is measured from the center of the steering wheel to
your breastbone. If you sit less than 10 in. (250 mm) away now, you can change your
driving position in several ways:
• Move your seat to the rear as far as you can while still reaching the pedals com- fortably.
• Slightly recline the back of the seat. Al though vehicle designs vary, many drivers
can achieve the 10 in. (250 mm) distance, even with the driver seat all the way for-
ward, simply by reclining the back of th e seat somewhat. If reclining the back of
your seat makes it hard to see the road, raise yourself by using a firm, non-slippery
cushion, or raise the seat if your vehicle has that feature.
• If your steering wheel is ad justable, tilt it downward. This points the airbag toward
your chest instead of your head and neck.
The seat should be adjusted as recommen ded by NHTSA above, while still maintain-
ing control of the foot pedals, steering whee l, and your view of the instrument panel
controls.

391-1. For safe use
GX460_OM_OM60L72U_(U)
1
For safety and security
CAUTION
■SRS airbag precautions
●Do not lean against the door, the roof side rail
or the front, side and rear pillars.
●Do not allow anyone to kneel on the passen-
ger seats toward the door or put their head or
hands outside the vehicle.
●Do not attach anything to or lean anything
against areas such as the dashboard, steering
wheel pad and lower portion of the instru-
ment panel.
These items can become projectiles when the
SRS driver, front passenger and knee airbags
deploy.

GX460_OM_OM60L72U_(U)
1133-2. Opening, closing and locking the doors
3
Operation of each component
■Battery-saving function
The battery-saving function will be activated in order to prevent the electronic key bat-
tery and the vehicle battery from being discharged while the vehicle is not in operation
for a long time.
●In the following situations, the smart access system with push-button start may take
some time to unlock the doors.
• The electronic key has been left in an area of approximately 6 ft. (2 m) of the outside
of the vehicle for 10 minutes or longer.
• The smart access system with push-butto n start has not been used for 5 days or
longer.
●If the smart access system with push-butto n start has not been used for 14 days or
longer, the doors cannot be unlocked at any doors except the driver’s door. In this case,
take hold of the driver’s door handle, or us e the wireless remote control or the mechan-
ical key, to unlock the doors.
■Conditions affe cting operation
The smart access system with push-button start uses weak radio waves. In the following
situations, the communication between th e electronic key and the vehicle may be
affected, preventing the smart access system with push-button start, wireless remote
control and engine immobilizer system from operating properly.
(Ways of coping: P. 5 4 9 )
●When the electronic key battery is depleted
●Near a TV tower, electric powe r plant, gas station, radio station, large display, airport or
other facility that generates strong radio waves or electrical noise
●When carrying a portable radio, cellular ph one, cordless phone or other wireless com-
munication device
●When the electronic key is in contact wi th, or is covered by the following metallic
objects
• Cards to which aluminum foil is attached
• Cigarette boxes that have aluminum foil inside
• Metallic wallets or bags
•Coins
•Hand warmers made of metal
• Media such as CDs and DVDs
●When other wireless keys (that emit radio waves) are being used nearby
●When carrying the electronic key together with the following devices that emit radio
waves
• Another vehicle’s electronic key or a wireless key that emits radio waves
• Personal computers or personal digital assistants (PDAs)
• Digital audio players
• Portable game systems
●If window tint with a metallic content or me tallic objects are attached to the rear win-
dow

124
GX460_OM_OM60L72U_(U)3-3. Adjusting the seats
■Before folding down the third seats
Use the seat belt hanger to prevent
the belt from being tangled.
■Folding down the third seats
From rear door side
Pull the strap to fold the head
restraint.
Pull the seat cushion lock release
lever.
The seat cushion is stowed automati-
cally.
Pull the seatback lock release
lever and fold the seatback down.
Folding down the third seats (manual seat)
1
2
3

GX460_OM_OM60L72U_(U)
1253-3. Adjusting the seats
3
Operation of each component
From back door side
Pull the strap to fold the head
restraint.
Pull the seat cushion/seatback
lock release lever.
The seat cushion is stowed automati-
cally.
Fold the seatback down.
■Returning the third seatsFrom rear door side, unlock the
seatbacks by pulling the lock
release lever, and lift them up until
they lock.
1
2
3
1
