2015 Lexus GS450h headlights

2
GS450h_QG_OM30F72U_(U)
Front Seats ................................................................................................................................. 18
Fuel Tank Cap .................................................................................................................. ......... 96
Garage Door Opener ........................................................................................................... 89
Hands-free System For Cellular Phone
Bluetooth
® phone pairing .........................................................................................................66
Contacts transfer .............................................................................................................. ............. 67
Registering the contacts in the favorites list....................................................................... 68
Calling by name (vehicles with navigation system) ......................................................... 69
Calling by favorites list ...................................................................................................... ........... 69
Calling using e-mail/SMS/MMS message ........................................................................ 70
Receiving a call ............................................................................................................... ................ 70
Steering switches .............................................................................................................. ............. 70
Headlights ..................................................................................................................... ............. 31
Head-up Display...................................................................................................................... 30
Hybrid System .................................................................................................................. ......... 12
Intuitive Parking Assist ....................................................................................................... ... 46
Lexus Enform................................................................................................................... ......... 93
Lexus Enform Safety Connect ............................................................................................. 91
Lexus Night View............................................................................................................... ....... 51
LKA (Lane-Keeping Assist) ................................................................................................. 48
Multi-information Display .................................................................................................... 28
Navigation System Register home .................................................................................................................. ...............60
Destination input - Search by address ................................................................................... 61
Destination input - Search points of interest by name....................................................63
Destination input - Search points of interest by category.............................................64
Destination input - Search points of intere st by telephone number .........................65

31
GS450h_QG_OM30F72U_(U)
Headlights
The side marker, parking, tail,
license plate and instrument
panel lights turn on.
The headlights and all the lights
listed above turn on.
The headlights, daytime run-
ning lights and all the lights
listed above turn on and off
automatically. (When the
power switch is in ON mode.)
Off
The daytime running lights turn
on.
■ Turning on the high beam headlights
With the headlights on, push the lever
away from you to turn on the high
beams.
Pull the lever toward you to the center
position to turn the high beams off.
Pull the lever toward you and release it
to flash the high beams once.
You can flash the high beams with the
headlights on or off.
(Canada)
(U.S.A.)
1
2
3
4
(U.S.A.)
(Canada)
1
2

32
GS450h_QG_OM30F72U_(U)
■AFS (Adaptive Front-lighting System) (if equipped)
AFS (Adaptive Front-lighting System) secures ex cellent visibility at intersections and on
curves by automatically adjusting the direction of the light axis of the headlights according
to vehicle speed and the degree of the tire’s angle as controlled by steering input.
Turns the AFS on/offThe indicator turns on when the AFS is
deactivated.

51
GS450h_QG_OM30F72U_(U)
Lexus Night View (if equipped)
■Displaying the Lexus night view
Turn the power switch to ON mode.
Turn the headlights on.
Press the Lexus night view switch.
The Lexus night view is displayed on the
Remote Touch screen.
To return the screen to its previous state,
press the switch again.
When the light sensor determines that it is
currently night time from the brightness of
the surrounding area, the Lexus night view
can be operated by pressing the Lexus
night view switch while the headlights are
on.
Lexus night view is a system which assists with nighttime driving. Near-infrared rays are
irradiated forward and an image converted from the irradiated light is shown on the
Remote Touch screen. The image shows pede strians, obstacles, and road conditions
ahead of the vehicle, which are difficult to see at nighttime with the naked eye.
1
2
3
