3305-1. Remote Touch screen
GS450h_OM_OM30F70U_(U)
*1: Refer to the “NAVIGATION AND MULTIMEDIA SYSTEM OWNER’SMANUAL”.
*2:If equipped
“Display”Select to adjust the contrast an d brightness of the screens, turn
the screen off, etc.
*1
Select to display the compass mode screen (8-inch display) or the
“Destination” screen (12.3-inch display).
*1
SwitchFunction

3345-1. Remote Touch screen
GS450h_OM_OM30F70U_(U)
■Display the side display
Basic screens
The following functions can be displayed and operated on the side dis-
play.
Audio
*
Air conditioning system
(P. 340)
Vehicle information
( P. 116)
Interruption screens
Each of the following screens is di splayed automatically in accordance
with conditions.
•
Intuitive parking assist* (if equipped)
•Phone
*
• Destination Assist*
• Driving mode ( P. 280)
• Lexus night view (if equipped) ( P. 312)
*: Refer to the “NAVIGATION AND MULTIMEDIA SYSTEM OWNER’S
MANUAL”.
■To display on the main display
Detailed information that is not shown on the side display can be set to
display on the main display.
Select , or .
1
2
3

472
GS450h_OM_OM30F70U_(U)
6-3. Do-it-yourself maintenance
■Passenger’s side instrument panel
FuseAmpereCircuit
1P/ S E AT 1 F/ R30Po w e r s e a t s
2FR P/OUTLET15Po w e r o u t l e t ( f r o n t )
3RR P/OUTLET15Power outlet (rear)
4P/ S E AT 2 F/ R25Po w e r s e a t s
5AV S20AV S
6STRG HTR15Heated steering wheel
7WA S H20Windshield washer
8RH ECU-IG10
Navigation system, VGRS, pre-collision seat
belts, air conditioning system, brake system,
Lexus night view, yaw rate and G sensor,
capacitor, Dynamic rear steering
9RH-IG10
Tension reducer, seat heater/ventilator
switches, front right-hand door ECU, CAN
gateway ECU, tire pressure warning system,
power seats
10DOOR FR30
Front right-hand door control system (out-
side rear view mirror defoggers, power win-
dow)
11DOOR RR30Power window (rear right-hand)
12RAD NO.230Audio system
13AM27. 5Power management system

GS450h_OM_OM30F70U_(U)
4736-3. Do-it-yourself maintenance
6
Maintenance and care
14MULTIMEDIA10Navigation system, Remote Touch
15RAD NO.130Audio system
16AIR BAG10SRS airbag system, occupant classification
system
17OBD7. 5On-board diagnosis system
18ACC7. 5
Body ECU, DCM, head-up display, RR
CTRL, Remote Touch screen, navigation sys-
tem, clock, transmission
FuseAmpereCircuit

5527-2. Steps to take in an emergency
GS450h_OM_OM30F70U_(U)
CAUTION
■When using the compact spare tire
●Remember that the compact spare tire provided is specifically designed for use
with your vehicle. Do not use your compact spare tire on another vehicle.
●Do not use more than one compact spare tire simultaneously.
●Replace the compact spare tire with a standard tire as soon as possible.
●Avoid sudden acceleration, abrupt steering, sudden braking and shifting opera-
tions that cause sudden engine braking.
■When the compact spare tire is attached
The vehicle speed may not be correctly detected, and the following systems may
not operate correctly:
• ABS & Brake assist
•VSC
•TRAC
•Cruise control
• Dynamic radar cruise control (if equipped)
•PCS (if equipped)
•EPS
•AFS (if equipped) •AVS
• LKA (Lane-Keeping Assist)
(if equipped)
• Lexus parking assist monitor
•Intuitive parking as sist (if equipped)
• Navigation system (if equipped)
• DRS (if equipped)
• VGRS (if equipped)
•LDH (if equipped)

GS450h_OM_OM30F70U_(U)
6078-2. Customization
8
Vehicle specifications
*1: The default setting varies according to countries
*2: U.S.A. only
*3:If equipped
*4: Refer to the “NAVIGATION AND MULTIMEDIA SYSTEM OWNER’SMANUAL”.
Illumination
( P. 3 6 3 )
Enable/disable opera-
tion of the outer foot
lights when you
approach the vehicle
with the electronic key
on your person
OnOff——O
Enable/disable opera-
tion of the outer foot
lights when the doors
are unlocked with the
power door lock switch
OnOff——O
Rear
sunshade
( P. 3 8 7 )
Reverse operationOnOff——O
Ti m e e l a p s e d b e f o r e
the reverse operation
feature activates0.7
seconds
0 second
——O
0.9
seconds
1.2
seconds
Seat belt
reminder
buzzer
(  P. 506)
Speed-linked seat belt
reminder functionOnOff——O
ItemFunctionDefault
settingCustomized setting123

627
GS450h_OM_OM30F70U_(U)
Index
What to do if... (Troubleshooting)................................ 628
Alphabetical index................................. 634
For information regarding the equipment listed below, refer to the
“NAVIGATION AND MULTIMEDIA SYSTEM OWNER’S
MANUAL”.
•Audio system
• Navigation system
•Intuitive parking assist
• Lexus parking assist monitor

635Alphabetical index
GS450h_OM_OM30F70U_(U)
Approach warningDynamic radar cruise control......245
Dynamic radar cruise control with full-speed range ..................... 261
Armrest .................................................... 386
Ashtrays.....................................................377
Assist grips ................................................391
Audio input
*
Audio system*
Automatic headlight leveling system .................................................... 220
Automatic light control system......... 217
AUX port
*
Auxiliary boxes ...................................... 372
AVS (Adaptive Variable Suspension system).......................... 284
Back-up lights Replacing light bulbs ....................... 488
Wattage ................................................. 583
Battery (12-volt battery) .................... 439 If the 12-volt battery is discharged .........................................562
Preparing and checking before winter ..................................................... 318
Warning light ...................................... 504
Battery (traction battery) ......................76
Blind Spot Monitor (BSM)................300
Bluetooth
®*
Brake Brake Hold ............................................. 214
Fluid .......................................................... 437
Parking brake ..........................................211
Regenerative braking ..........................74
Warning light ..........................503, 506
Warning message...............................513
Brake assist ............................................. 283
Brake Hold................................................ 214
Break-in tips ............................................. 177
Brightness control Instrument panel light control ........ 93
BSM (Blind Spot Monitor) ............... 300 Blind Spot Monitor function.........304
Rear Cross Traffic Alert function................................................ 307
Care................................................. 408, 412 Aluminum wheels ..............................409
Exterior .................................................. 408
Interior ....................................................... 412
Seat belts.................................................. 413
Cargo capacity .......................................190
Cargo hooks ...........................................373
Caution label.............................................. 76
CD player
*
Chains ....................................................... 320
BC
*: Refer to the “NAVIGATION AND MULTIMEDIA SYSTEM OWNER’S MANUAL”.
