6788-2. Steps to take in an emergency
ES350_300h_OM_OM33B99U_(U)
■Trunk
Turn the mechanical key clock-
wise to open.
Ensure that the shift lever is in P and depress the brake pedal.
Touch the Lexus emblem side of
the electronic key to the “START
STOP ENGINE” <“POWER”>
switch.
The “START STOP ENGINE”
<“POWER”> switch will turn to IGNI-
TION ON mode.
When the smart access system with
push-button start is deactivated in
customization setting, the “START
STOP ENGINE” <“POWER”> switch
will turn to ACCESSORY mode.
Firmly depress the brake pedal and check that is shown on the
multi-information display.
Press the “START STOP ENGINE” <“POWER”> switch.
In the event that the engine still cannot be started, contact
your Lexus dealer.
Starting the engine
1
2
3
4

6798-2. Steps to take in an emergency
ES350_300h_OM_OM33B99U_(U)
8
When trouble arises
■Stopping the engine
Shift the shift lever to P and press the “START STOP ENGINE” <“POWER”> switch
as you normally do when stopping the engine .
■Replacing the key battery
As the above procedure is a temporary measure, it is recommended that the elec-
tronic key battery be replaced immedi ately when the battery is depleted. (P. 584)
■Changing “START STOP ENGINE” <“POWER”> switch modes
Release the brake pedal and press the “START STOP ENGINE” <“POWER”> switch
in step above.
The engine does not start and modes will be changed each time the
switch is pressed. ( P. 2 0 6 , 2 1 3 )
■When the electronic key does not work properly
●Make sure that the smart access system with push-button start has not been deac-
tivated in the customization setting. If it is off, turn the function on.
(Customizable features  P. 7 3 0 )
●Check if battery-saving mode is set. If it is set, cancel the function. ( P. 1 3 3 )
CAUTION
■When using the mechanical key and operating the power windows or moon roof
Operate the power window or moon roof af ter checking to make sure that there is
no possibility of any passenger having any of their body parts caught in the window
or moon roof.
Also, do not allow children to operate the mechanical key. It is possible for children
and other passengers to get caught in the power window or moon roof.
3

6828-2. Steps to take in an emergency
ES350_300h_OM_OM33B99U_(U)
■Charging the 12-volt battery
The electricity stored in the 12-volt battery will discharge gradually even when the
vehicle is not in use, due to natural discharge and the draining effects of certain elec-
trical appliances. If the vehicle is left for a long time, the 12-volt battery may dis-
charge, and the engine may be unable to start. (The 12-volt battery recharges
automatically during driving.)
■When recharging or replacing the 12-volt battery
●Make sure that the key is not inside the vehicle when recharging or replacing the
12-volt battery. The key may be locked in the vehicle if the alarm is activated.
(  P. 8 9 )
●In some cases, it may not be possible to unlock the doors using the smart access
system with push-button start when the 12-volt battery is discharged. Use the wire-
less remote control or the mechanical key to lock or unlock the doors.
●The engine may not start on the first atte mpt after the 12-volt battery has recharged
but will start normally after the second attempt. This is not a malfunction.
●The “START STOP ENGINE” switch mode is memorized by the vehicle. When the
12-volt battery is reconnected, the system will return to the mode it was in before
the 12-volt battery was discharged. Before disconnecting the 12-volt battery, turn
the “START STOP ENGINE” switch off.
If you are unsure what mode the “START STOP ENGINE” switch was in before the
12-volt battery discharged, be especially careful when reconnecting the 12-volt
battery.
CAUTION
■Avoiding 12-volt battery fires or explosions
Observe the following precautions to prev ent accidentally igniting the flammable
gas that may be emitted from the 12-volt battery:
●Make sure each jumper cable is connected to the correct terminal and that it is
not unintentionally in contact with any other than the intended terminal.
●Do not allow the other end of the jumper cable connected to the “+” terminal to
come into contact with any other parts or metal surfaces in the area, such as
brackets or unpainted metal.
●Do not allow the + and - clamps of the jumper cables to come into contact with
each other.
●Do not smoke, use matches, cigarette lighters or allow open flame near the 12-
volt battery.

773Alphabetical index
ES350_300h_OM_OM33B99U_(U)
I/M test ..................................................... 536
IdentificationEngine ......................................................702
Vehicle ..................................................... 701
Ignition switch (“POWER” switch) ...................................................... 212
Ignition switch (“START STOP ENGINE” switch) ............................. 205
Illuminated entry system ..................... 481
Immobilizer system.........................84, 86
Indicators .................................................... 95
Initialization Maintenance........................................ 530
Tire pressure warning system................................567
Initiators (tire pressure warning system)................................. 575
Inside rear view mirror .......................... 171
Instrument panel light control ............ 99
Interior light............................................. 479
Intuitive parking assist Function ................................................... 281
Warning message ................638, 645 Jack
Positioning a floor jack.................... 542
Vehicle-equipped jack .................. 660
Jack handle ................................................ 660
Jam protection function Moon roof .............................................. 183
Power trunk opener and closer ............................................. 151
Power windows....................................178
Keyless entry Smart access system with push-button start.................... 127
Wireless remote control....................141
Keys Battery-saving function ....................133
Electronic key ........................................ 124
Engine switch ............................205, 212
If the electronic key does not operate properly ........ 677
Key number plate ................................ 124
Keyless entry ..................................127, 141
Mechanical key..................................... 124
“POWER” switch ................................ 212
Replacing the battery ......................584
“START STOP ENGINE” switch ...................................................205
Warning buzzer.....................................131
Wireless remote control key ...........141
Knee airbags ............................................. 38
IJ
K
*: For vehicles with a navigation system, refer to the
“NAVIGATION SYSTEM OWNER’S MANUAL”.

778Alphabetical index
ES350_300h_OM_OM33B99U_(U)
SeatsAdjustment ............................................. 157
Adjustment precautions .................. 158
Child seats/child restraint system installation.............................. 62
Cleaning .................................................526
Driving position memory ................ 159
Head restraints ..................................... 165
Power easy access system ............ 159
Properly sitting in the seat ................30
Seat heaters ..........................................478
Seat position memory....................... 159
Seat ventilators ....................................478
Sensor Automatic headlight system .........235
Humidity sensor ................................. 476
Inside rear view mirror ......................173
Intuitive parking assist ....................... 281
LDA (Lane Departure Alert) ....... 279
Radar sensor ..................267, 322, 331
Rain-sensing windshield wipers ................................................... 247
Service reminder indicators ............... 92
Shift lever Automatic transmission .................. 222
Hybrid transmission.......................... 226
If the shift lever cannot be shifted from P ............676
Shift lever light ....................................... 479
Shift lock system.................................... 676
Side airbags ............................................... 39 Side marker lights
Light switch........................................... 233
Replacing light bulbs ............606, 610
Welcome light illumination control.................................................... 127
Side mirrors Adjusting and folding ........................ 174
Blind Spot Monitor ........................... 328
Linked mirror function when reversing.................................. 175
Mirror position memory ..................159
Side turn signal lights Replacing light bulbs ........................ 610
Turn signal lever ................................. 230
Smart access system with push-button start Antenna location.................................. 129
Entry functions ...................................... 127
Starting the engine ............................205
Starting the hybrid system............... 212
Warning message.............................640
Snow tires ................................................ 345
Spare tire ................................................. 659 Inflation pressure.................................. 713
Storage location ................................ 660
Spark plug ............................................... 708
Specifications......................................... 700
Speedometer ............................................. 97
“START STOP ENGINE” switch ..................................................... 205

780Alphabetical index
ES350_300h_OM_OM33B99U_(U)
Rear sunshade switch ..................... 495
Rear window and outside rear view mirror defoggers
switch....................................................470
Seat heater switches.........................478
Seat ventilator switches ..................478
“SOS” button......................................... 513
“START STOP ENGINE” switch................................................... 205
Talk switch
*........................................... 431
Telephone switches
*........................ 431
Tilt and telescopic steering control switch ................. 169
Tire pressure warning reset switch................................................... 568
Trunk closer switch ............................ 150
Trunk opener switch ......................... 149
Trunk opener main switch.............. 150
Vehicle-to-vehicle distance button .................................................... 261
VSC OFF switch ................................ 315
Window lock switch........................... 177
Windshield wipers and washer switch .........................245 Tachometer ................................................ 97
Tail lights
Light switch........................................... 233
Replacing light bulbs ........................ 610
Welcome light illumination control.................................................... 127
Talk switch
*.............................................. 431
Telephone switches
*............................ 431
Theft deterrent system Alarm ..........................................................88
Engine immobilizer system ............. 84
Immobilizer system.............................. 86
Tire inflation pressure Maintenance data................................ 712
Tire inflation pressure display function................................................. 105
Warning light .......................................630
Warning message............................ 650
Tire information ...................................... 718 Glossary................................................. 725
Size ............................................................. 721
Tire identification number ............. 720
Uniform Tire Quality Grading ...............................................723
Tire pressure warning system Function .................................................. 567
Initializing ............................................... 567
Installing tire pressure warning valves and transmitters................ 567
Registering ID codes .......................569
Tire pressure warning reset switch .................................................. 568
Warning light .......................................630
Warning message............................ 650
T
