2015 Lexus ES300h clock

ES350_300h_OM_OM33B36U_(U)
6017-3. Do-it-yourself maintenance
7
Maintenance and care
■Headlight low beam (halogen bulb)Turn the bulb base counter-
clockwise.
Unplug the connector while
pressing the lock release.
Exchange the light bulb, and
install the bulb base.
Align the 3 tabs on the light bulb
with the mounting, and insert.
Turn and secure the bulb base.
Shake the bulb base gently to
check that it is not loose, turn the
headlights on once and visually
confirm that no light is leaking
through the mounting.
1
2
3
4

602
ES350_300h_OM_OM33B36U_(U)
7-3. Do-it-yourself maintenance
■Halogen fog lights (if equipped)Remove the bolt and partly
remove the under cover, and
unplug the connector while
pushing the lock release.
Turn the bulb base counter-
clockwise.
Set the new light bulb.
Align the 3 tabs on the light bulb
with the mounting, and insert. Turn
it clockwise to set.
1
2
3

604
ES350_300h_OM_OM33B36U_(U)
7-3. Do-it-yourself maintenance
■Front turn signal lightsTo allow enough working
space, turn the steering wheel
to the opposite side of the bulb
to be replaced.
Remove the 3 fender liner
clips and 1 screw.
Turn the steering wheel to the
left when replacing the right
side light bulb, and turn the
steering wheel to the right
when replacing the left side
light bulb.
To take out the clips, turn the
head of the clip to unlock, then
remove by pulling.
While holding the clamp open,
pull and remove the tabs and
open the fender liner.
Turn the bulb base counter-
clockwise.
1
2
3

606
ES350_300h_OM_OM33B36U_(U)
7-3. Do-it-yourself maintenance
■Front side marker lightsPartly remove the fender liner.
Perform the procedure for “Front turn signal lights” from step 1 to 2.
(→ P. 6 0 4 )
Turn the bulb base counter-
clockwise.
Remove the code from clip.
Remove the light bulb.
1
2
3
4

608
ES350_300h_OM_OM33B36U_(U)
7-3. Do-it-yourself maintenance
■Rear turn signal lightsOpen the trunk lid and remove
the cover.
Turn the bulb base counter-
clockwise.
Remove the light bulb.
When installing, reverse the steps listed.
1
2
3
4

ES350_300h_OM_OM33B36U_(U)
6097-3. Do-it-yourself maintenance
7
Maintenance and care
■Back-up lightsOpen the trunk lid.
For the left side (vehicles with
power trunk opener and closer
only): Pry out each side of the
trunk closer switch in turn by
inserting a screwdriver into the
base.
To prevent damage, cover the tip of
the screwdriver with a rag.
Remove the clips on whichever
side you are replacing and
open the cover of the trunk lid.
Turn the bulb base counter-
clockwise.
When installing, pass the wire
around the connector rib and make
sure that it does not rest on top of
the connector rib.
Remove the light bulb.
When installing, reverse the steps listed.
1
2
3
Connector rib
4
5
6

6788-2. Steps to take in an emergency
ES350_300h_OM_OM33B36U_(U)
■Tr u n k
Turn the mechanical key clock-
wise to open.
Ensure that the shift lever is in P and depress the brake pedal.
Touch the Lexus emblem side of
the electronic key to the “START
STOP ENGINE” <“POWER”>
switch.
The “START STOP ENGINE”
<“POWER”> switch will turn to IGNI-
TION ON mode.
When the smart access system with
push-button start is deactivated in
customization setting, the “START
STOP ENGINE” <“POWER”> switch
will turn to ACCESSORY mode.
Firmly depress the brake pedal and check that is shown on the
multi-information display.
Press the “START STOP ENGINE” <“POWER”> switch.
In the event that the engine still cannot be started, contact
your Lexus dealer.
Starting the engine
1
2
3
4

768Alphabetical index
ES350_300h_OM_OM33B36U_(U)
CareAluminum wheels ..............................523
Exterior.................................................... 522
Interior .....................................................526
Seat belts ................................................ 527
Cargo capacity...................................... 202
Cargo hooks ..........................................488
CD player
*............................................. 387
Chains ....................................................... 343
Child restraint system Booster seats, definition ................... 58
Booster seats, installation..................68
Convertible seats, definition ........... 58
Convertible seats, installation .........65
Front passenger occupant
classification system ........................ 50
Infant seats, definition ......................... 58
Infant seats, installation .......................65
Installing CRS
with LATCH anchors ..................... 63
Installing CRS with seat belts ..........65
Installing CRS with top tether strap .........................69 Child safety ................................................. 57
12-volt battery
precautions .......................... 559, 683
Airbag precautions................................ 41
Child restraint system......................... 58
How your child should wear
the seat belt .......................................... 34
Installing child restraints .................... 62
Moon roof precautions ................... 185
Power window lock switch............. 177
Power window precautions .......... 180
Rear door child-protectors ............145
Removed electronic key battery precautions ............. 585
Seat belt extender precautions ...........................................37
Seat belt precautions ............................ 61
Seat heater precautions ..................477
Trunk precautions ............................... 152
Child-protectors .................................... 145
Cleaning Aluminum wheels .............................. 523
Exterior ................................................... 522
Interior ..................................................... 526
Seat belts................................................ 527
Clock........................................................... 491
Coat hooks ............................................. 499
Condenser.............................................. 555
Console box........................................... 485
Console box light ................................. 485
Consumption screen ............................. 118
Cooling system
Engine overheating ......................... 688
Hybrid system overheating ............691
Cruise control Cruise control ..................................... 254
Dynamic radar cruise control .....258
C
