2015 JEEP GRAND CHEROKEE automatic transmission fluid

•Shift to Neutral then Drive or Reverse
•Autostick Unavailable Service Required
•Automatic Unavailable Use Autostick Service Req.
•Transmission Getting Hot Press Brake
•Trans. Hot Stop Safely Shift To Park Wait to Cool
•Transmission Cool Ready to Drive
•Service Transmission
•Service Shifter
•Engage Park Brake To Prevent Rolling
•Transmission Too Cold Idle With Engine On
•Washer Fluid Low
•Service Air Suspension System
•Normal Ride Height Achieved•Aerodynamic Ride Height Achieved
•Off Road 1 Ride Height Achieved
•Off Road 2 Ride Height Achieved
•Entry/Exit Ride Height Achieved
•Selected Ride Height Not Permitted
•Service Air Suspension System Immediately
•Reduce Speed To Maintain Selected Ride Height
•Air Suspension System Cooling Down Please Wait
•Vehicle Cannot Be Lowered Door Open
•Off Road 2 Watch For Clearance
•Entry/Exit Watch For Clearance
302 UNDERSTANDING YOUR INSTRUMENT PANEL

▫Transfer Case........................565
▫Automatic Transmission................566
▫Appearance Care And Protection From
Corrosion...........................568
FUSES..............................574
▫Power Distribution Center...............575
VEHICLE STORAGE....................583
REPLACEMENT BULBS.................583
BULB REPLACEMENT..................585
▫High Intensity Discharge Headlamps (HID) — If
Equipped...........................585
▫Halogen Headlamps — If Equipped........586▫Front Turn Signal.....................587
▫Front Fog Lamps.....................587
▫Rear Tail, Stop, Turn Signal, And Backup
Lamps.............................588
▫Rear Liftgate Mounted Tail Lamp..........589
▫Center High-Mounted Stop Lamp (CHMSL) . .590
▫Rear License Lamp....................591
FLUID CAPACITIES....................591
FLUIDS, LUBRICANTS, AND GENUINE
PARTS ..............................592
▫Engine.............................592
▫Chassis............................593
526 MAINTAINING YOUR VEHICLE

Drain
First remove fill plug, then remove drain plug. Recom-
mended tightening torque for drain and fill plugs is 15 to
25 ft lbs (20 to 34 N·m).
CAUTION!
When installing plugs, do not overtighten. You could
damage them and cause them to leak.
Selection Of Lubricant
Use only the manufacturer’s recommended fluid. Refer
to “Fluids, Lubricants, and Genuine Parts” in “Maintain-
ing Your Vehicle” for further information.
Automatic Transmission
Selection Of Lubricant
It is important to use the proper transmission fluid to
ensure optimum transmission performance and life. Useonly the manufacturer’s specified transmission fluid.
Refer to “Fluids, Lubricants, And Genuine Parts” in this
section for fluid specifications. It is important to maintain
the transmission fluid at the correct level using the
recommended fluid.
NOTE:No chemical flushes should be used in any
transmission; only the approved lubricant should be
used.
CAUTION!
Using a transmission fluid other than the manufac-
turer ’s recommended fluid may cause deterioration
in transmission shift quality and/or torque converter
shudder. Refer to “Fluids, Lubricants, And Genuine
Parts” in this section for fluid specifications.
566 MAINTAINING YOUR VEHICLE

Special Additives
The manufacturer strongly recommends against using
any special additives in the transmission.
Automatic Transmission Fluid (ATF) is an engineered
product and its performance may be impaired by supple-
mental additives. Therefore, do not add any fluid addi-
tives to the transmission. The only exception to this
policy is the use of special dyes for diagnosing fluid
leaks. Avoid using transmission sealers as they may
adversely affect seals.
CAUTION!
Do not use chemical flushes in your transmission as
the chemicals can damage your transmission compo-
nents. Such damage is not covered by the New
Vehicle Limited Warranty.
Fluid Level Check
The fluid level is preset at the factory and does not require
adjustment under normal operating conditions. Routine
fluid level checks are not required, therefore the transmis-
sion has no dipstick. Your authorized dealer can check your
transmission fluid level using special service tools.
If you notice fluid leakage or transmission malfunction,
visit your authorized dealer immediately to have the
transmission fluid level checked. Operating the vehicle
with an improper fluid level can cause severe transmis-
sion damage.
CAUTION!
If a transmission fluid leak occurs, visit your autho-
rized dealer immediately. Severe transmission dam-
age may occur. Your authorized dealer has the proper
tools to adjust the fluid level accurately.
7
MAINTAINING YOUR VEHICLE 567

Chassis
Component Fluid, Lubricant or Genuine Part
Automatic Transmission Use only MOPAR® ZF 8&9 Speed ATF™ Automatic
Transmission Fluid, or equivalent. Failure to use the
correct fluid may affect the function or performance of
your transmission.
Transfer Case We recommend you use MOPAR® ATF+4® Automatic
Transmission Fluid.
Front Axle We recommend you use MOPAR® GL-5 Synthetic Axle
Lubricant SAE 75W-85.
Rear Axle We recommend you use MOPAR® GL-5 Synthetic Axle
Lubricant SAE 75W-85 with friction modifier additive.
Brake Master Cylinder We recommend you use MOPAR® DOT 3 Brake Fluid,
SAE J1703. If DOT 3, SAE J1703 brake fluid is not
available, then DOT 4 is acceptable.
Power Steering Reservoir We recommend you use MOPAR® Power Steering Fluid
+4, MOPAR® ATF+4® Automatic Transmission Fluid.
7
MAINTAINING YOUR VEHICLE 593

Alarm (Security Alarm)..................19, 286
Alterations/Modifications, Vehicle...............9
Antifreeze (Engine Coolant)...............558, 591
Disposal..............................560
Anti-Lock Brake System (ABS)................426
Anti-Lock Warning Light....................286
Appearance Care.........................568
Auto Down Power Windows..................42
Automatic Door Locks......................34
Automatic Headlights......................166
Automatic High Beams.....................166
Automatic Temperature Control (ATC).......366, 374
Automatic Transmission.................407, 568
Adding Fluid..........................568
Autostick.............................414
Fluid And Filter Changes..................568
Fluid Change..........................568
Fluid Level Check...................566, 567
Fluid Type.........................566, 593Gear Ranges...........................409
Special Additives.......................567
Autostick...............................414
Auxiliary Electrical Outlet (Power Outlet)........259
Auxiliary Power Outlet.....................259
Axle Fluid..............................593
Battery.................................540
Keyless Transmitter Replacement (RKE)........26
Belts, Seat...............................109
Blind Spot Monitoring......................132
Body Mechanism Lubrication.................546
B-Pillar Location..........................443
Brake Assist System.......................427
Brake Control System, Electronic..............426
Brake Fluid..........................563, 593
Brake System.........................425, 562
Anti-Lock (ABS).....................425, 426
Fluid Check...........................563
10
INDEX 615

Trailer Towing Guide.......................486
Trailer Weight............................486
Transfer Case............................565
Fluid................................593
Maintenance...........................565
Transmission............................407
Automatic.........................407, 566
Fluid................................593
Maintenance...........................566
Shifting..............................403
Transmitter Battery Service (Remote Keyless Entry) . .26
Transmitter, Garage Door Opener (HomeLink®). . . .242
Transmitter Programming
(Remote Keyless Entry)..................22, 26
Transmitter, Remote Keyless Entry (RKE).........22
Transporting Pets.........................106
Tread Wear Indicators......................457
Turn Signals......................286, 587, 588Uconnect®
Operation.............................340
Screen Activated Features..................24
Uconnect® Settings.......................25
Uconnect® Settings......................23, 24
Customer Programmable Features.......34, 36, 45
Passive Entry Programming............34, 36, 45
Uconnect® Settings.......................45
Uconnect® Voice Command..................379
Uniform Tire Quality Grades.................611
Universal Transmitter......................242
Unleaded Gasoline........................471
Untwisting Procedure, Seat Belt................57
Vanity Mirrors...........................131
Vehicle Identification Number (VIN).............8
Vehicle Loading.......................444, 479
Vehicle Modifications/Alterations...............9
Vehicle Storage........................376, 583
10
INDEX 631
