2015 INFINITI QX60 HYBRID key

2. Check the fluid level in each cell. If it isnecessary to add fluid, add only distilled
water to bring the level up to the bottom of
the filler opening. Do not overfill.Reinstall
the vent caps. Vehicles operated in high temperatures or under
severe conditions require frequent checks of the
battery fluid level.
JUMP STARTING
If jump starting is necessary, refer to “Jump start-
ing” in the “In case of emergency” section of this
manual. If the engine does not start by jump
starting, the battery may have to be replaced.
Contact an INFINITI retailer.
1. Super charger pulley
2. Idler pulley
3. Water pump pulley
4 Air conditioner compressor pulley
5. Drive belt automatic tensioner pulley
6. Crankshaft pulley
WARNING
Be sure the ignition key is in the OFF or
LOCK position before servicing drive belt.
The engine could rotate unexpectedly.
LDI0302
LDI2493
DRIVE BELT
Maintenance and do-it-yourself8-17

INFINITI INTELLIGENT KEY
Replace the battery in the Intelligent Key as fol-
lows:1. Remove the mechanical key from the Intelli- gent Key.
2. Insert a small screwdriver
Ainto the slitB
of the corner and twist it to separate the
upper part from the lower part. Use a cloth to
protect the casing.
3. Replace the battery with a new one. Recommended battery: CR2025 or equiva-
lent.
●Do not touch the internal circuit and elec-
tric terminals as doing so could cause a
malfunction.
● Hold the battery by the edges. Holding
the battery across the contact points will
seriously deplete the storage capacity.
● Make sure that the + side faces the bot-
tom of the case. 4. Close the lid securely as illustrated
CD.
5. Operate the buttons to check the operation.
See an INFINITI retailer if you need assistance for
replacement.
FCC Notice:
For USA:
This device complies with Part 15 of the
FCC Rules. Operation is subject to the fol-
lowing two conditions: (1) This device may
not cause harmful interference, and (2) this
device must accept any interference re-
ceived, including interference that may
cause undesired operation.
SDI1867
WDI0535
Maintenance and do-it-yourself8-25

10 Index
2nd row bench seat adjustment......1-5,1-7
A
Aiming control, headlights ...........2-38
Air bag (See supplemental restraint
system) .....................1-48
Air bag system Front (See supplemental front impact
air bag system) ...............1-55
Airbagwarninglabels.............1-66
Airbagwarninglight...........1-66,2-13
Air bag warning light, supplemental . .1-66, 2-13
Air cleaner housing filter ............8-19
Air conditioner Air conditioner service ...........4-49
Air conditioner specification label .....9-12
Air conditioner system refrigerant and
oil recommendations .............9-7
Heater and air conditioner controls ....4-43
Servicing air conditioner ..........4-49
Alarm system
(See vehicle security system) .........2-29
Anchor point locations .............1-30
Antenna .....................4-94
Anti-lock brake warning light ..........2-9
Anti-lock Braking System (ABS) ........5-98
Armrests .....................1-8
Around View™ Monitor .............4-26
Audible reminders ...............2-16
Audio system ..................4-49 Audio System
AMradioreception.............4-50
Audio system Bluetooth®audio..............4-88
Compact disc (CD) player .........4-70
Audio System Digital Versatile Disc (DVD) Player
Operation ..................4-73
Audio system FM/AM/SAT radio with compact disc (CD)
player ....................4-65
Audio System FMradioreception.............4-50
iPod® Player .............4-82,4-85
iPod® player operation .......4-82,4-85
Audio system Radio ....................4-49
Steering wheel audio control switch . . .4-92
USB interface ............4-77,4-79
Audio System USB (Universal Serial Bus) Connection
Port..................4-77,4-79
Autolight switch .................2-37
Automatic Automatic drive positioner .........3-33
Automatic power window switch .....2-58
Automatic anti-glare inside mirror .......3-31
Automatic door locks ..............3-6
Automatic drive positioner ...........3-33 B
Backup Collision Intervention (BCI)
system......................5-44
Backup Collision Warning (BCW) system . .5-44
Battery .................5- 105, 8-16
Charge warning light .............2-9
Battery replacement Keyfob ...................8-24
Before starting the engine ...........5-16
Belt (See drive belt) ..............8-17
Blind Spot Intervention (BSI) system .....5-32
Block heater Engine ...................5-107
Bluetooth® audio ................4-88
Bluetooth® hands-free phone system . . .4-107, 4-121
Boosterseats..................1-45
Brake Anti-lock Braking System (ABS) ......5-98
Brake assist (for Intelligent cruise control
system) ...................5-99
Brake fluid ..................8-14
Brakelight(Seestoplight).........8-27
Brake system ................5-97
Brakewarninglight..............2-9
B ra

kewearindicators........2-16,8-21
Parking brake operation ..........5-21
Self-adjusting brakes ............8-21
Brake fluid ....................8-14
Brakes ......................8-21
Brake system ..................5-97

Intelligent cruise control (ICC) systemBrake assist .................5-54
Intelligent Key system Key operating range ..............3-9
Key operation ................3-10
Mechanicalkey ................3-3
Remote keyless entry operation.......3-13
Troubleshooting guide ............3-17
Warning signals ...............3-17
Interiorlight....................2-62
Inverter Checking inverter coolant level .......8-10
Inverter cooling system ............8-9
iPod®Player ...............4-82,4-85
ISOFIX child restraints .............1-27
J
Jump starting ...................6-11
K
Key.........................3-2
Key fob battery replacement ..........8-24
Keyless entry With Intelligent Key system
(See Intelligent Key system) .........3-13
Keys, For Intelligent Key system .........3-7
L
Labels Air conditioner specification label .....9-12C.M.V.S.S. certification label
........9-11
Emission control information label .....9-11
Engine serial number ............9-11
F.M.V.S.S. certification label .........9-11
Tire and Loading Information label .....9-12
Vehicle identification number (VIN) .....9-10
Vehicle identification number (VIN) plate . .9-10
Warning labels (for SRS) ..........1-66
Lane Departure Prevention (LDP) system . . .5-25
Lane Departure Warning (LDW) system ....5-25
LATCH (Lower Anchors and Tethers for CHildren)
System ......................1-27
License plate Installing the license plate ..........9-13
Liftgate ......................3-22
Liftgaterelease.................3-25
Light Air bag warning light .........1-66,2-13
Brake light (See stop light) .........8-27
Bulb check/instrument panel .........2-9
Bulbreplacement..............8-27
Charge warning light .............2-9
Foglights...................8-26
Foglightswitch ...............2-40
Headlight and turn signal switch ......2-35
Headlight control switch ..........2-36
Headlights..................8-26
Interiorlight..................2-62
Lightbulbs..................8-26
Low tire pressure warning light .......2-10
Low windshield-washer fluid warning
light ..................2-12,2-28
Passenger air bag and status light .....1-57
Security indicator light ............2-15
Warning/indicator lights and audible
reminders ...................2-8 Lights
Maplights ..................2-63
Lock Child safety rear door lock ..........3-7
Door locks ...................3-4
Gloveboxlock................2-53
Lift gate release ...............3-25
Power door locks ...............3-6
Loose fuel cap warning .............2-29
Low fuel warning light .......2-10,2-12,2-27
Low tire pressure warning light .........2-10
Low windshield-washer fluid warning
light ....................2-12,2-28
Luggage hook.................. 2

-55
Luggage rack (see roof rack) ..........2-56
Luggage (See vehicle loading information) . .9-14
Luggage storage
(see vehicle loading information) ........2-55
M
Maintenance General maintenance .............8-2
Insidethevehicle...............8-3
Maintenance precautions ...........8-5
Outside the vehicle ..............8-2
Seat belt maintenance ............1-23
Under the hood and vehicle .........8-4
Maintenance requirements ............8-2
Malfunction indicator light ............2-14
Maplights ....................2-63
Mappocket....................2-50
Memory Seat ...................3-33
Meters and gauges ................2-4
Instrument brightness control ........2-39
10-4
