table of contents
new system features INFINITI Connection™ (if so equipped) ............................. 2
Main Interface Switches Overview ................................. 3
User Registration ............................................... 4
Upper Display .................................................. 4
Around View
® Monitor (AVM) with Moving Object Detection (MOD)
(if so equipped) ................................................ 5
SiriusXM Travel Link and SiriusXM Traffic (if so equipped) .............. 6
essential information Tire Pressure Monitoring System (TPMS) with Tire Inflation Indicator .....7
Loose Fuel Cap ................................................. 8
Fuel-filler Door ................................................. 8
Lower Display Maintenance ....................................... 8
Driving Aids (if so equipped) ...................................... 8
Active Lane Control (if so equipped) ................................ 9
Heated Steering Wheel (if so equipped) .............................9
Clock Set/Adjustment .......................................... 10
first drive features INFINITI Intelligent Key System .................................. 11
Trunk Lid Release .............................................. 12
Seat Adjustments .............................................. 12
Heated Seats (if so equipped) .................................... 13
Automatic Drive Positioner (if so equipped) .........................13
Outside Mirror Control Switch .................................... 14
Starting/Stopping the Engine .................................... 14
Headlight Control Switch . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .\
. . . . 15
Windshield Wiper and Washer Switch ............................. 16
Climate Controls ............................................... 17
FM/AM/HD Radio
®/SiriusXM® Satellite Radio (if so equipped) ......... 19
USB (Universal Serial Bus) Connection Port /iPod® Interface ........... 20
Conventional (Fixed Speed) Cruise Control .........................20
Intelligent Cruise Control (ICC) (if so equipped) .....................21
system guide Vehicle Information Display ..................................... 22
Bluetooth® Hands-free Phone System ............................. 22
System Operating Tips ....................................... 22
Navigation System (if so equipped) ............................... 25
HomeLink
® Universal Transceiver (if so equipped) ................... 26
To view detailed
instructional videos, go to
www.infinitiownersinfo.mobi/2015/q50 or snap this barcode with an
appropriate barcode reader.
Additional information about your vehicle is also available
in your Owner’s Manual, Navigation System Owner’s Manual
and at www.InfinitiUSA.com.
Please see your Owner’s Manual for important safety information
and system operation limitations.
• A cellular telephone should not be used for any purpose while
driving so full attention may be given to vehicle operation.
• Always wear your seat belt.
• Supplemental air bags do not replace proper seat belt usage.
• Children 12 and under should always ride in the rear seat
properly secured in child restraints or seat belts according to
their age and weight.
• Do not drink and drive.
For more information, refer to your InTouch
™ Owner’s Manual,
the “Safety –– Seats, seat belts and supplemental restraint
system (section 1)” and the “Starting and driving (section 5)”
of your Owner’s Manual.
2045927_15c_Infiniti_Q50_QRG_071415.indd 47/14/15 3:38 PM
18
first drive features
8 INTAKE AIR CONTROL BUTTON
Pressing the intake air control button will cancel auto air recirculation 7
(if so equipped) until it is re-activated from the touch-screen (see above). Press the
intake air control button
to manually control whether the interior air is recirculated
or outside air is drawn into the vehicle. When the indicator light is on, interior air
is recirculated, outside odors are avoided and interior vehicle temperature is most
effectively maintained.
The air recirculation mode cannot be activated when the climate control system is in the
front defroster mode
or the front defroster and foot vent mode .
9 A/C KEY
Touch the A/C key to turn the air conditioner system on or off. This system helps cool
and dehumidify the air inside the cabin and defog the windows.
10 DUAL KEY
Touch to turn the passenger’s side temperature controls on or off. When the system
is on, the indicator light will illuminate. This function will allow the passenger’s side
temperature to be adjusted independently from the driver’s side by pressing the
passenger’s side temperature control buttons
3.
11 DEFROSTING/DEFOGGING FRONT AND SIDE WINDOWS
Press the defroster button
to turn the system on. The A/C automatically turns
on when the defroster mode is selected. This feature removes humidity from the air.
To defrost the front and side windows, set the driver’s side temperature controls
2 and
fan speed controls 4 to their maximum settings.
12
DEFROSTING REAR WINDOW AND OUTSIDE MIRRORS
Push the rear window and outside mirror defroster switch
to turn the system
on or off.
This function automatically turns off after approximately 15 minutes.
13 ON/OFF BUTTON
Press the ON/OFF button to turn the climate control system on or off.
For more information, refer to the “Instruments and controls (section 2)” of your Owner’s Manual and the “Heater and air
conditioner (section 3)” of your InTouch Owner’s Manual.
