TECHNICAL SPECIFICATIONS
Items CapacityFord part name or
equivalentFord part number / Ford
specification
Brake fluid
1
Between MAX and
MIN on reservoirMotorcraft DOT 4 Low
Viscosity High Performance
Motor Vehicle Brake FluidPM-20 /
WSS-M6C65-A2
Door latch, hood
latch, auxiliary
hood latch, seat
tracks, trunk and
liftgate latches—Multi-Purpose Grease
(Lithium grease)XL-5 / ESA-M1C93-B
Lock cylinders —Motorcraft Penetrating and
Lock LubricantXL-1 / None
Automatic
transmission
fluid
2,3
6F50 transmission
10.9 quarts (10.3L)
Motorcraft
MERCON LVXT-10-QLVC (U.S.);
CXT-10-LV12 (Canada) /
WSS-M2C938-A
MERCON LV 6F55 transmission
11.6 quarts (11.0L)
Rear differential
fluid (All Wheel
Drive)2.43 pt
(1.15L)Motorcraft SAE 80W-90
Premium Rear Axle
LubricantXY-80W90-QL /
WSP-M2C197-A
Power Transfer
Unit (PTU) fluid
(All Wheel Drive)
4
18 oz (0.53L)Motorcraft SAE 75W-140
Synthetic Rear Axle
LubricantXY-75W140-QL (U.S.);
CXY-75W140-1L (Canada) /
WSL-M2C192-A
362Capacities and Specifications
2015 Flex(471)
Owners Guide gf, 1st Printing, October 2014
USA(fus)
